| General information | |
|---|---|
| Brand | Mercedes-Benz |
| Model | E-class |
| Generation | E-class T-modell (S211) |
| Type (Engine) | E 320 V6 (224 Hp) 4MATIC 5G-TRONIC |
| Start of production | 2003 year |
| End of production | 2004 year |
| Powertrain Architecture | Internal Combustion engine |
| Body type | Station wagon (estate) |
| Seats | 5 |
| Doors | 5 |
| Performance specs | |
| Fuel consumption (economy) – urban (NEDC) | 15.4 l/100 km 15.3 US mpg 18.3 UK mpg 6.5 km/l |
| Fuel consumption (economy) – extra urban (NEDC) | 8.2 l/100 km 28.7 US mpg 34.4 UK mpg 12.2 km/l |
| Fuel consumption (economy) – combined (NEDC) | 10.6 l/100 km 22.2 US mpg 26.6 UK mpg 9.4 km/l |
| CO2 emissions (NEDC) | 254 g/km |
| Fuel Type | Petrol (Gasoline) |
| Acceleration 0 – 100 km/h | 9 sec |
| Acceleration 0 – 62 mph | 9 sec |
| Acceleration 0 – 60 mph (Calculated by Auto-Data.net) | 8.6 sec |
| Maximum speed | 233 km/h 144.78 mph |
| Emission standard | Euro 4 |
| Weight-to-power ratio | 8 kg/Hp, 124.8 Hp/tonne |
| Weight-to-torque ratio | 5.7 kg/Nm, 175.5 Nm/tonne |
| Engine specs | |
| Power | 224 Hp @ 5600 rpm. |
| Power per litre | 70 Hp/l |
| Torque | 315 Nm @ 3000-4800 rpm. 232.33 lb.-ft. @ 3000-4800 rpm. |
| Engine layout | Front, Longitudinal |
| Engine Model/Code | M 112.954 |
| Engine displacement | 3199 cm3 195.21 cu. in. |
| Number of cylinders | 6 |
| Engine configuration | V-engine |
| Cylinder Bore | 89.9 mm 3.54 in. |
| Piston Stroke | 84 mm 3.31 in. |
| Compression ratio | 10:1 |
| Number of valves per cylinder | 3 |
| Fuel injection system | Multi-port manifold injection |
| Engine aspiration | Naturally aspirated engine |
| Valvetrain | SOHC |
| Engine oil capacity | 8 l 8.45 US qt | 7.04 UK qt |
| Engine oil specification |  Log in to see. |
| Coolant | 10 l 10.57 US qt | 8.8 UK qt |
|
|
|
| Space, Volume and weights | |
| Kerb Weight | 1795 kg 3957.3 lbs. |
| Max. weight | 2445 kg 5390.3 lbs. |
| Max load | 650 kg 1433 lbs. |
| Trunk (boot) space – minimum | 690 l 24.37 cu. ft. |
| Trunk (boot) space – maximum | 1950 l 68.86 cu. ft. |
| Fuel tank capacity | 80 l 21.13 US gal | 17.6 UK gal |
| Permitted trailer load with brakes (12%) | 2100 kg 4629.71 lbs. |
| Permitted trailer load without brakes | 750 kg 1653.47 lbs. |
| Dimensions | |
| Length | 4850 mm 190.94 in. |
| Width | 1822 mm 71.73 in. |
| Width including mirrors | 1990 mm 78.35 in. |
| Height | 1495 mm 58.86 in. |
| Wheelbase | 2854 mm 112.36 in. |
| Front track | 1559 mm 61.38 in. |
| Rear (Back) track | 1552 mm 61.1 in. |
| Front overhang | 831 mm 32.72 in. |
| Rear overhang | 1165 mm 45.87 in. |
| Drag coefficient (Cd) | 0.30 |
| Minimum turning circle (turning diameter) | 11.4 m 37.4 ft. |
| Drivetrain, brakes and suspension specs | |
| Drivetrain Architecture | The Internal combustion engine (ICE) drives permanently the four wheels of the vehicle. |
| Drive wheel | All wheel drive (4×4) |
| Number of gears and type of gearbox | 5 gears, automatic transmission |
| Front suspension | Coil spring, Double wishbone, Transverse stabilizer, Air Suspension – Optional |
| Rear suspension | Independent multi-link suspension, Air suspension, Transverse stabilizer |
| Front brakes | Ventilated discs |
| Rear brakes | Disc |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Power steering | Hydraulic Steering |
| Tires size | 225/55 R16; 245/45 R17 |
| Wheel rims size | 7.5J x 16; 8J x 17; 8.5J x 17 |
| What is the body type, Mercedes-Benz E-class T-modell (S211)? | Station wagon (estate), 5 Doors, 5 Seats |
|---|---|
| What is the fuel economy, Mercedes-Benz E-class T-modell (S211) E 320 V6 (224 Hp) 4MATIC 5G-TRONIC? | 10.6 l/100 km 22.2 US mpg 26.6 UK mpg 9.4 km/l |
| How ECO is the car, Mercedes-Benz E-class E 320 V6 (224 Hp) 4MATIC 5G-TRONIC? | 254 g/km CO2 Euro 4 |
| How fast is the car, 2003 E-class T-modell (S211) E 320 V6 (224 Hp) 4MATIC 5G-TRONIC? | 233 km/h | 144.78 mph 0-100 km/h: 9 sec 0-60 mph: 8.6 sec |
| How much power, Mercedes-Benz E-class Station wagon (estate) 2003 E 320 V6 (224 Hp) 4MATIC 5G-TRONIC? | 224 Hp, 315 Nm 232.33 lb.-ft. |
| What is the engine size, Mercedes-Benz E-class Station wagon (estate) 2003 E 320 V6 (224 Hp) 4MATIC 5G-TRONIC? | 3.2 l 3199 cm3 195.21 cu. in. |
| How many cylinders, 2003 Mercedes-Benz E 320 V6 (224 Hp) 4MATIC 5G-TRONIC? | 6, V-engine |
| What is the drivetrain, Mercedes-Benz E-class T-modell (S211) Station wagon (estate) 2003 E 320 V6 (224 Hp) 4MATIC 5G-TRONIC? | All wheel drive (4×4). Internal Combustion engine. The Internal combustion engine (ICE) drives permanently the four wheels of the vehicle. |
| How long is this vehicle, 2003 Mercedes-Benz E-class Station wagon (estate)? | 4850 mm 190.94 in. |
| How wide is the vehicle, 2003 Mercedes-Benz E-class Station wagon (estate)? | 1822 mm 71.73 in. |
| What is the curb weight, 2003 Mercedes-Benz E-class T-modell (S211) E 320 V6 (224 Hp) 4MATIC 5G-TRONIC? | 1795 kg 3957.3 lbs. |
| What is the gross weight, 2003 Mercedes-Benz E-class T-modell (S211) E 320 V6 (224 Hp) 4MATIC 5G-TRONIC? | 2445 kg 5390.3 lbs. |
| How much trunk (boot) space, 2003 Mercedes-Benz E-class Station wagon (estate)? | 690 – 1950 l 24.37 – 68.86 cu. ft. |
| How many gears, What type is the gearbox, 2003 Mercedes-Benz E-class T-modell (S211) E 320 V6 (224 Hp) 4MATIC 5G-TRONIC? | 5, automatic transmission |
