| General information | |
|---|---|
| Brand | Mercedes-Benz |
| Model | E-class |
| Generation | E-class T-modell (S214) |
| Type (Engine) | AMG E 53 (585 Hp) Plug-in Hybrid 4MATIC+ AMG SPEEDSHIFT TCT 9G |
| Start of production | March, 2024 year |
| Powertrain Architecture | PHEV (Plug-in Hybrid Electric Vehicle) |
| Body type | Station wagon (estate) |
| Seats | 5 |
| Doors | 5 |
| Performance specs | |
| Combined fuel consumption (WLTP) | 0.9-1.1 l/100 km 261.3 – 213.8 US mpg 313.9 – 256.8 UK mpg 111.1 – 90.9 km/l |
| CO2 emissions (WLTP) | 21-24 g/km |
| Fuel Type | Petrol / electricity |
| Acceleration 0 – 100 km/h | 4.1 sec |
| Acceleration 0 – 62 mph | 4.1 sec |
| Acceleration 0 – 60 mph (Calculated by Auto-Data.net) | 3.9 sec |
| Maximum speed | 250 km/h, Electronically limited 155.34 mph |
| Emission standard | Euro 6e |
| Weight-to-power ratio | 4 kg/Hp, 247.9 Hp/tonne |
| Weight-to-torque ratio | 3.1 kg/Nm, 317.8 Nm/tonne |
| Electric cars and hybrids specs | |
| Gross battery capacity | 28.6 kWh |
| Net (usable) battery capacity | 21.2 kWh |
| Battery voltage | 400 V |
| Battery technology | Lithium-ion (Li-Ion) |
| Battery location | Under the trunk |
| Recuperation output | 120 kW |
| All-electric range (WLTP) | 90-97 km 55.92 – 60.27 mi |
| Average Energy consumption (WLTP) | 25-26.7 kWh/100 km
40.23 – 42.97 kWh/100 mi |
| Max speed (electric) | 140 km/h
86.99 mph |
| Charging ports |  Log in to see. |
| Electric motor 1 | |
| Electric motor power | 163 Hp |
| Electric motor Torque | 480 Nm @ 1 rpm.
354.03 lb.-ft. @ 1 rpm. |
| Electric motor location | Between the combustion engine and the transmission |
| Electric motor type | Synchronous |
| System power | 585 Hp |
| System torque | 750 Nm 553.17 lb.-ft. |
| Internal combustion engine specs | |
| Power | 449 Hp @ 5800-6100 rpm. |
| Power per litre | 149.7 Hp/l |
| Torque | 560 Nm @ 2200-5000 rpm. 413.03 lb.-ft. @ 2200-5000 rpm. |
| Engine layout | Front, Longitudinal |
| Engine Model/Code | M 256 |
| Engine displacement | 2999 cm3 183.01 cu. in. |
| Number of cylinders | 6 |
| Engine configuration | Inline |
| Cylinder Bore | 83 mm 3.27 in. |
| Piston Stroke | 92.4 mm 3.64 in. |
| Compression ratio | 10.5:1 |
| Number of valves per cylinder | 4 |
| Fuel injection system | Direct injection |
| Engine aspiration | Twin-scroll turbo, Intercooler |
| Valvetrain | DOHC, CAMTRONIC |
| Engine systems | Start & Stop System Particulate filter |
|
|
|
| Space, Volume and weights | |
| Kerb Weight | 2360 kg 5202.91 lbs. |
| Max. weight | 2975 kg 6558.75 lbs. |
| Max load | 615 kg 1355.84 lbs. |
| Trunk (boot) space – minimum | 460 l 16.24 cu. ft. |
| Trunk (boot) space – maximum | 1675 l 59.15 cu. ft. |
| Fuel tank capacity | 50 l 13.21 US gal | 11 UK gal |
| Max. roof load | 100 kg 220.46 lbs. |
| Permitted trailer load with brakes (12%) | 2100 kg 4629.71 lbs. |
| Permitted trailer load without brakes | 750 kg 1653.47 lbs. |
| Permitted towbar download | 84 kg 185.19 lbs. |
| Dimensions | |
| Length | 4958 mm 195.2 in. |
| Width | 1902 mm 74.88 in. |
| Width including mirrors | 2065 mm 81.3 in. |
| Height | 1483 mm 58.39 in. |
| Wheelbase | 2961 mm 116.57 in. |
| Front track | 1649 mm 64.92 in. |
| Rear (Back) track | 1608 mm 63.31 in. |
| Minimum turning circle (turning diameter) | 12.53 m 41.11 ft. |
| Drivetrain, brakes and suspension specs | |
| Drivetrain Architecture | The Internal combustion engine (ICE) and the electric motor permanently drive the rear wheels of the vehicle, capable of running in full electric or mixed mode, and if necessary through the electrically or mechanically controlled clutch, the front wheels are driven. |
| Drive wheel | All wheel drive (4×4) |
| Number of gears and type of gearbox | 9 gears, automatic transmission AMG SPEEDSHIFT TCT |
| Front suspension | Coil spring, Independent multi-link suspension, Transverse stabilizer |
| Rear suspension | Independent multi-link spring suspension with stabilizer |
| Front brakes | Ventilated discs, 370×36 mm |
| Rear brakes | Ventilated discs, 360×26 mm |
| Assisting systems | ABS (Anti-lock braking system) 4-wheel steering (4WS, active rear steering) |
| Steering type | Steering rack and pinion |
| Power steering | Electric Steering |
| Tires size | Front wheel tires: 255/45 ZR19 Rear wheel tires: 285/40 ZR19 |
| Wheel rims size | 19 |
| What is the body type, Mercedes-Benz E-class T-modell (S214)? | Station wagon (estate), 5 Doors, 5 Seats |
|---|---|
| What is the fuel economy, Mercedes-Benz E-class T-modell (S214) AMG E 53 (585 Hp) Plug-in Hybrid 4MATIC+ AMG SPEEDSHIFT TCT 9G? | 0.9-1.1 l/100 km 261.3 – 213.8 US mpg 313.9 – 256.8 UK mpg 111.1 – 90.9 km/l |
| How ECO is the car, Mercedes-Benz E-class AMG E 53 (585 Hp) Plug-in Hybrid 4MATIC+ AMG SPEEDSHIFT TCT 9G? | 21-24 g/km CO2 Euro 6e |
| What is the range of pure electric driving, AMG E 53 (585 Hp) Plug-in Hybrid 4MATIC+ AMG SPEEDSHIFT TCT 9G? | 90-97 km 55.92 – 60.27 mi |
| What is electricity consumption, Mercedes-Benz E-class T-modell (S214) AMG E 53 (585 Hp) Plug-in Hybrid 4MATIC+ AMG SPEEDSHIFT TCT 9G? | 25-26.7 kWh/100 km 40.23 – 42.97 kWh/100 mi 84 – 78 MPGe 4 – 3.7 km/kWh 2.5 – 2.3 mi/kWh |
| How fast is the car, 2024 E-class T-modell (S214) AMG E 53 (585 Hp) Plug-in Hybrid 4MATIC+ AMG SPEEDSHIFT TCT 9G? | 250 km/h | 155.34 mph 0-100 km/h: 4.1 sec 0-60 mph: 3.9 sec |
| How much power, Mercedes-Benz E-class Station wagon (estate) 2024 AMG E 53 (585 Hp) Plug-in Hybrid 4MATIC+ AMG SPEEDSHIFT TCT 9G? | 585 Hp, 750 Nm 553.17 lb.-ft. |
| What is the engine size, Mercedes-Benz E-class Station wagon (estate) 2024 AMG E 53 (585 Hp) Plug-in Hybrid 4MATIC+ AMG SPEEDSHIFT TCT 9G? | 3.0 l 2999 cm3 183.01 cu. in. |
| How many cylinders, 2024 Mercedes-Benz AMG E 53 (585 Hp) Plug-in Hybrid 4MATIC+ AMG SPEEDSHIFT TCT 9G? | 6, Inline |
| What is the drivetrain, Mercedes-Benz E-class T-modell (S214) Station wagon (estate) 2024 AMG E 53 (585 Hp) Plug-in Hybrid 4MATIC+ AMG SPEEDSHIFT TCT 9G? | All wheel drive (4×4). PHEV (Plug-in Hybrid Electric Vehicle). The Internal combustion engine (ICE) and the electric motor permanently drive the rear wheels of the vehicle, capable of running in full electric or mixed mode, and if necessary through the electrically or mechanically controlled clutch, the front wheels are driven. |
| How long is this vehicle, 2024 Mercedes-Benz E-class Station wagon (estate)? | 4958 mm 195.2 in. |
| How wide is the vehicle, 2024 Mercedes-Benz E-class Station wagon (estate)? | 1902 mm 74.88 in. |
| What is the curb weight, 2024 Mercedes-Benz E-class T-modell (S214) AMG E 53 (585 Hp) Plug-in Hybrid 4MATIC+ AMG SPEEDSHIFT TCT 9G? | 2360 kg 5202.91 lbs. |
| What is the gross weight, 2024 Mercedes-Benz E-class T-modell (S214) AMG E 53 (585 Hp) Plug-in Hybrid 4MATIC+ AMG SPEEDSHIFT TCT 9G? | 2975 kg 6558.75 lbs. |
| How much trunk (boot) space, 2024 Mercedes-Benz E-class Station wagon (estate)? | 460 – 1675 l 16.24 – 59.15 cu. ft. |
| How many gears, What type is the gearbox, 2024 Mercedes-Benz E-class T-modell (S214) AMG E 53 (585 Hp) Plug-in Hybrid 4MATIC+ AMG SPEEDSHIFT TCT 9G? | 9, automatic transmission AMG SPEEDSHIFT TCT |
