The Mercedes-Benz E 200 Kompressor, produced between March 1997 and July 1999, was a significant variant within the W210 E-Class range. Positioned as a mid-range offering, it bridged the gap between the base E 200 and the more powerful E 230 and E 280 models. This version, equipped with a supercharged 2.0-liter inline-four engine and a five-speed automatic transmission, aimed to deliver a balance of performance and fuel efficiency, appealing to buyers seeking a comfortable and refined executive sedan. The W210 generation, launched in 1995, represented a substantial leap forward for Mercedes-Benz in terms of technology, safety, and overall build quality, and the E 200 Kompressor played a key role in its market success.
Technical Specifications
| Brand | Mercedes-Benz |
| Model | E-class |
| Generation | E-class (W210) |
| Type | E 200 Kompressor (192 Hp) Automatic |
| Start of production | March, 1997 |
| End of production | July, 1999 |
| Powertrain Architecture | Internal Combustion engine |
| Body type | Sedan |
| Seats | 5 |
| Doors | 4 |
| Fuel consumption (urban) | 15 l/100 km (15.7 US mpg, 18.8 UK mpg, 6.7 km/l) |
| Fuel consumption (extra urban) | 8 l/100 km (29.4 US mpg, 35.3 UK mpg, 12.5 km/l) |
| Fuel consumption (combined) | 10.5 l/100 km (22.4 US mpg, 26.9 UK mpg, 9.5 km/l) |
| Fuel Type | Petrol (Gasoline) |
| Acceleration 0 – 100 km/h | 8.9 sec |
| Acceleration 0 – 62 mph | 8.9 sec |
| Acceleration 0 – 60 mph | 8.5 sec |
| Maximum speed | 226 km/h (140.43 mph) |
| Weight-to-power ratio | 7.9 kg/Hp, 127.2 Hp/tonne |
| Weight-to-torque ratio | 5.6 kg/Nm, 178.8 Nm/tonne |
| Power | 192 Hp @ 5300 rpm |
| Power per litre | 96.1 Hp/l |
| Torque | 270 Nm @ 2500-4800 rpm (199.14 lb.-ft. @ 2500-4800 rpm) |
| Engine layout | Front, Longitudinal |
| Engine Model/Code | M 111 E 20 ML / 111.947 |
| Engine displacement | 1998 cm3 (121.93 cu. in.) |
| Number of cylinders | 4 |
| Engine configuration | Inline |
| Cylinder Bore | 89.9 mm (3.54 in.) |
| Piston Stroke | 78.7 mm (3.1 in.) |
| Compression ratio | 8.5:1 |
| Number of valves per cylinder | 4 |
| Fuel injection system | Multi-port manifold injection |
| Engine aspiration | Supercharger, Intercooler |
| Valvetrain | DOHC |
| Engine oil capacity | 5.5 l (5.81 US qt | 4.84 UK qt) |
| Coolant | 8.5 l (8.98 US qt | 7.48 UK qt) |
| Kerb Weight | 1510 kg (3328.98 lbs.) |
| Max. weight | 2010 kg (4431.29 lbs.) |
| Max load | 500 kg (1102.31 lbs.) |
| Fuel tank capacity | 65 l (17.17 US gal | 14.3 UK gal) |
| Length | 4795 mm (188.78 in.) |
| Width | 1799 mm (70.83 in.) |
| Height | 1436 mm (56.54 in.) |
| Wheelbase | 2833 mm (111.54 in.) |
| Front track | 1542 mm (60.71 in.) |
| Rear track | 1536 mm (60.47 in.) |
| Drivetrain Architecture | Rear wheel drive |
| Drive wheel | Rear wheel drive |
| Number of gears | 5 gears, automatic transmission |
| Front suspension | Double wishbone |
| Rear suspension | Independent multi-link spring suspension with stabilizer |
| Front brakes | Ventilated discs |
| Rear brakes | Disc |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Power steering | Hydraulic Steering |
| Tires size | 215/55 R16 |
| Wheel rims size | 7.5J x 16 |
Powertrain & Engine Architecture
The heart of the E 200 Kompressor was the M111 E 20 ML engine, a 1998cc inline-four cylinder powerplant. This engine was a key component of Mercedes-Benz’s move towards forced induction in the late 1990s. The “Kompressor” designation signified the presence of a mechanically driven supercharger, specifically a Lysholm-type unit. This supercharger, coupled with an intercooler, boosted power output significantly compared to naturally aspirated versions of the same engine. The M111 featured multi-port fuel injection and a double overhead camshaft (DOHC) valvetrain with four valves per cylinder, contributing to its relatively high specific output. The five-speed automatic transmission (typically the 5G-Tronic) was chosen for its smooth operation and suitability for the luxury market. This transmission featured electronically controlled shifting and adaptive learning, adjusting to the driver’s style over time.
Driving Characteristics
The E 200 Kompressor offered a noticeably more responsive driving experience than the base E 200. The supercharger provided a strong surge of torque from low engine speeds, making it feel quicker in everyday driving situations. While not a sports sedan, the 192 horsepower and 270 Nm (199 lb-ft) of torque allowed for confident acceleration and effortless cruising. The automatic transmission, while smooth, wasn’t particularly sporty, prioritizing comfort over rapid gear changes. Compared to the E 230, which offered more overall power, the E 200 Kompressor focused on providing readily available torque, making it feel lively around town. The 0-60 mph time of around 8.5 seconds was respectable for the era, and the top speed of 140 mph was more than adequate for most drivers.
Equipment & Trim Levels
The E 200 Kompressor typically came well-equipped, reflecting its position as a mid-range model. Standard features included automatic climate control, power windows and locks, central locking, and a high-quality audio system. Interior upholstery was generally cloth, although leather was available as an option. Common optional extras included a sunroof, upgraded audio systems, heated seats, and parking assistance systems. The dashboard layout was typical of the W210, featuring a classic Mercedes-Benz design with wood trim and analog gauges. Trim levels varied slightly depending on the market, but generally offered a good balance of comfort and convenience features.
Chassis & Braking
The W210 E-Class featured a robust chassis with a double wishbone front suspension and an independent multi-link rear suspension. This setup provided a comfortable ride while maintaining good handling characteristics. The E 200 Kompressor typically came equipped with ventilated disc brakes at the front and solid disc brakes at the rear. Anti-lock braking system (ABS) was standard, enhancing safety and stability during hard braking. The steering was a hydraulic power-assisted rack and pinion system, offering precise and responsive control. Stabilizer bars were fitted front and rear to reduce body roll during cornering.
Market Reception & Comparison
The E 200 Kompressor was generally well-received by automotive critics. It was praised for its smooth engine, comfortable ride, and well-appointed interior. However, some reviewers noted that the automatic transmission could feel a bit sluggish at times. Compared to the naturally aspirated E 200, the Kompressor offered a significant performance boost for a relatively modest price increase. Against the E 230, it offered a slightly less powerful but more fuel-efficient alternative. Fuel economy was reasonable for a car of its size and class, averaging around 22.4 mpg combined. Reliability was generally good, although like all cars of this era, it was susceptible to age-related issues.
Legacy
The M111 engine, particularly the supercharged variants like the one found in the E 200 Kompressor, proved to be a durable and reliable powerplant. While not as iconic as some of Mercedes-Benz’s larger engines, it established the brand’s commitment to forced induction technology. Today, the W210 E 200 Kompressor remains a popular choice among enthusiasts seeking a classic Mercedes-Benz sedan. Well-maintained examples are relatively affordable and offer a comfortable and refined driving experience. Common maintenance issues include wear and tear on suspension components, electrical glitches, and potential oil leaks. However, with proper care, these cars can provide many years of reliable service.
