| General information | |
|---|---|
| Brand | Mercedes-Benz |
| Model | EQB |
| Generation | EQB (X243, facelift 2023) |
| Type (Engine) | EQB 250+ 73.9 kWh (190 Hp) |
| Start of production | October, 2023 year |
| End of production | September, 2025 year |
| Powertrain Architecture | BEV (Electric Vehicle) |
| Body type | SUV |
| Seats | 5 |
| Doors | 5 |
| Performance specs | |
| Fuel Type | Electricity |
| Acceleration 0 – 100 km/h | 8.9 sec |
| Acceleration 0 – 62 mph | 8.9 sec |
| Acceleration 0 – 60 mph (Calculated by Auto-Data.net) | 8.5 sec |
| Maximum speed | 160 km/h, Electronically limited 99.42 mph |
| Weight-to-power ratio | 10.7 kg/Hp, 93.6 Hp/tonne |
| Weight-to-torque ratio | 5.3 kg/Nm, 189.7 Nm/tonne |
| Electric cars and hybrids specs | |
| Gross battery capacity | 73.9 kWh |
| Net (usable) battery capacity | 70.5 kWh |
| Battery voltage | 400 V |
| Battery technology | Lithium-ion (Li-Ion) |
| Battery location | Below the floor |
| All-electric range (WLTP) | 463-536 km 287.69 – 333.05 mi |
| Average Energy consumption (WLTP) | 15.2-17.5 kWh/100 km
24.46 – 28.16 kWh/100 mi |
| Charging ports |  Log in to see. |
| Electric motor 1 | |
| Electric motor power | 190 Hp |
| Electric motor Torque | 385 Nm
283.96 lb.-ft. |
| Electric motor model/code | EM0026 |
| Electric motor location | Front axle, Transverse |
| Electric motor type | Synchronous |
| System power | 190 Hp |
| System torque | 385 Nm 283.96 lb.-ft. |
|
|
|
| Space, Volume and weights | |
| Kerb Weight | 2030 kg 4475.38 lbs. |
| Max. weight | 2540 kg 5599.74 lbs. |
| Max load | 510 kg 1124.36 lbs. |
| Trunk (boot) space – minimum | 495 l 17.48 cu. ft. |
| Trunk (boot) space – maximum | 1710 l 60.39 cu. ft. |
| Max. roof load | 75 kg 165.35 lbs. |
| Permitted trailer load with brakes (12%) | 1400 kg 3086.47 lbs. |
| Permitted trailer load without brakes | 750 kg 1653.47 lbs. |
| Permitted towbar download | 100 kg 220.46 lbs. |
| Dimensions | |
| Length | 4684 mm 184.41 in. |
| Width | 1834 mm 72.2 in. |
| Width including mirrors | 2020 mm 79.53 in. |
| Height | 1654 mm 65.12 in. |
| Wheelbase | 2829 mm 111.38 in. |
| Front track | 1584-1589 mm 62.36 – 62.56 in. |
| Rear (Back) track | 1580-1593 mm 62.2 – 62.72 in. |
| Front overhang | 913 mm 35.94 in. |
| Rear overhang | 942 mm 37.09 in. |
| Minimum turning circle (turning diameter) | 11.7 m 38.39 ft. |
| Approach angle | 19° |
| Departure angle | 18.6° |
| Ramp-over (brakeover) angle | 12.1° |
| Drivetrain, brakes and suspension specs | |
| Drivetrain Architecture | One electric motor drives the front wheels. |
| Drive wheel | Front wheel drive |
| Number of gears and type of gearbox | 1 gears, automatic transmission |
| Front suspension | Independent, type McPherson with coil spring and anti-roll bar |
| Rear suspension | Independent multi-link spring suspension with stabilizer |
| Front brakes | Ventilated discs |
| Rear brakes | Disc |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Power steering | Electric Steering |
| Tires size | 215/60 R18; 235/55 R18; 235/50 R19; 235/45 R20 |
| Wheel rims size | 6.5J x 18; 7.5J x 18; 7.5J x 19; 8.5J x 20 |
| What is the body type, Mercedes-Benz EQB (X243, facelift 2023)? | SUV, 5 Doors, 5 Seats |
|---|---|
| What is the range of pure electric driving, EQB 250+ 73.9 kWh (190 Hp)? | 463-536 km 287.69 – 333.05 mi |
| What is electricity consumption, Mercedes-Benz EQB (X243, facelift 2023) EQB 250+ 73.9 kWh (190 Hp)? | 15.2-17.5 kWh/100 km 24.46 – 28.16 kWh/100 mi 138 – 120 MPGe 6.6 – 5.7 km/kWh 4.1 – 3.6 mi/kWh |
| How fast is the car, 2023 EQB (X243, facelift 2023) EQB 250+ 73.9 kWh (190 Hp)? | 160 km/h | 99.42 mph 0-100 km/h: 8.9 sec 0-60 mph: 8.5 sec |
| How much power, Mercedes-Benz EQB SUV 2023 EQB 250+ 73.9 kWh (190 Hp)? | 190 Hp, 385 Nm 283.96 lb.-ft. |
| What is the drivetrain, Mercedes-Benz EQB (X243, facelift 2023) SUV 2023 EQB 250+ 73.9 kWh (190 Hp)? | Front wheel drive. BEV (Electric Vehicle). One electric motor drives the front wheels. |
| How long is this vehicle, 2023 Mercedes-Benz EQB SUV? | 4684 mm 184.41 in. |
| How wide is the vehicle, 2023 Mercedes-Benz EQB SUV? | 1834 mm 72.2 in. |
| What is the curb weight, 2023 Mercedes-Benz EQB (X243, facelift 2023) EQB 250+ 73.9 kWh (190 Hp)? | 2030 kg 4475.38 lbs. |
| What is the gross weight, 2023 Mercedes-Benz EQB (X243, facelift 2023) EQB 250+ 73.9 kWh (190 Hp)? | 2540 kg 5599.74 lbs. |
| How much trunk (boot) space, 2023 Mercedes-Benz EQB SUV? | 495 – 1710 l 17.48 – 60.39 cu. ft. |
| How many gears, What type is the gearbox, 2023 Mercedes-Benz EQB (X243, facelift 2023) EQB 250+ 73.9 kWh (190 Hp)? | 1, automatic transmission |
