| General information | |
|---|---|
| Brand | Mercedes-Benz |
| Model | EQC |
| Generation | EQC (N293) |
| Type (Engine) | EQC 400 85 kWh (408 Hp) 4MATIC |
| Start of production | May, 2019 year |
| End of production | 2023 year |
| Powertrain Architecture | BEV (Electric Vehicle) |
| Body type | SUV |
| Seats | 5 |
| Doors | 5 |
| Performance specs | |
| Fuel Type | Electricity |
| Acceleration 0 – 100 km/h | 5.1 sec |
| Acceleration 0 – 62 mph | 5.1 sec |
| Acceleration 0 – 60 mph (Calculated by Auto-Data.net) | 4.8 sec |
| Maximum speed | 180 km/h, Electronically limited 111.85 mph |
| Weight-to-power ratio | 5.9 kg/Hp, 168.6 Hp/tonne |
| Weight-to-torque ratio | 3.2 kg/Nm, 314 Nm/tonne |
| Electric cars and hybrids specs | |
| Gross battery capacity | 85 kWh |
| Net (usable) battery capacity | 80 kWh |
| Battery voltage | 405 V |
| Battery technology | Lithium-ion (Li-Ion) |
| Battery weight | 652 kg 1437.41 lbs. |
| Battery location | Below the floor |
| All-electric range (WLTP) | 373-437 km 231.77 – 271.54 mi |
| All-electric range (NEDC) | 436-495 km 270.92 – 307.58 mi |
| Average Energy consumption (WLTP) | 21.3-25 kWh/100 km
34.28 – 40.23 kWh/100 mi |
| Average Energy consumption (NEDC) | 19.4-21.9 kWh/100 km
31.22 – 35.24 kWh/100 mi |
| Charging ports |  Log in to see. |
| Electric motor 1 | |
| Electric motor location | Rear axle, Transverse |
| Electric motor 2 | |
| Electric motor location | Front axle, Transverse |
| System power | 408 Hp |
| System torque | 760 Nm 560.55 lb.-ft. |
|
|
|
| Space, Volume and weights | |
| Kerb Weight | 2420 kg 5335.19 lbs. |
| Max. weight | 2940 kg 6481.59 lbs. |
| Max load | 520 kg 1146.4 lbs. |
| Trunk (boot) space – minimum | 500 l 17.66 cu. ft. |
| Trunk (boot) space – maximum | 1460 l 51.56 cu. ft. |
| Max. roof load | 75 kg 165.35 lbs. |
| Permitted trailer load with brakes (12%) | 1800 kg 3968.32 lbs. |
| Permitted trailer load without brakes | 750 kg 1653.47 lbs. |
| Permitted towbar download | 72 kg 158.73 lbs. |
| Dimensions | |
| Length | 4762 mm 187.48 in. |
| Width | 1884 mm 74.17 in. |
| Width including mirrors | 2096 mm 82.52 in. |
| Height | 1624 mm 63.94 in. |
| Wheelbase | 2873 mm 113.11 in. |
| Front track | 1624 mm 63.94 in. |
| Rear (Back) track | 1615 mm 63.58 in. |
| Front overhang | 867 mm 34.13 in. |
| Rear overhang | 1022 mm 40.24 in. |
| Drag coefficient (Cd) | 0.29 |
| Minimum turning circle (turning diameter) | 11.8 m 38.71 ft. |
| Approach angle | 17.5° |
| Departure angle | 19.5° |
| Ramp-over (brakeover) angle | 9.7° |
| Drivetrain, brakes and suspension specs | |
| Drivetrain Architecture | One electric motor drives the front wheels, one electric motor drives the rear wheels. |
| Drive wheel | All wheel drive (4×4) |
| Number of gears and type of gearbox | 1 gears, automatic transmission |
| Front suspension | Double wishbone |
| Rear suspension | Independent multi-link suspension |
| Front brakes | Ventilated discs |
| Rear brakes | Ventilated discs |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Power steering | Electric Steering |
| Tires size | Front wheel tires: 235/55 R19; 235/50 R20; 235/45 R21 Rear wheel tires: 235/55 R19; 255/50 R19; 255/45 R20; 255/40 R21 |
| Wheel rims size | Front wheel rims: 7.5J x 19; 8J x 19; 7.5J x 20; 8J x 21 Rear wheel rims: 8J x 19; 8.5J x 20; 9J x 21 |
| What is the body type, Mercedes-Benz EQC (N293)? | SUV, 5 Doors, 5 Seats |
|---|---|
| What is the range of pure electric driving, EQC 400 85 kWh (408 Hp) 4MATIC? | 373-437 km 231.77 – 271.54 mi |
| What is electricity consumption, Mercedes-Benz EQC (N293) EQC 400 85 kWh (408 Hp) 4MATIC? | 21.3-25 kWh/100 km 34.28 – 40.23 kWh/100 mi 98 – 84 MPGe 4.7 – 4 km/kWh 2.9 – 2.5 mi/kWh |
| How fast is the car, 2019 EQC (N293) EQC 400 85 kWh (408 Hp) 4MATIC? | 180 km/h | 111.85 mph 0-100 km/h: 5.1 sec 0-60 mph: 4.8 sec |
| How much power, Mercedes-Benz EQC SUV 2019 EQC 400 85 kWh (408 Hp) 4MATIC? | 408 Hp, 760 Nm 560.55 lb.-ft. |
| What is the drivetrain, Mercedes-Benz EQC (N293) SUV 2019 EQC 400 85 kWh (408 Hp) 4MATIC? | All wheel drive (4×4). BEV (Electric Vehicle). One electric motor drives the front wheels, one electric motor drives the rear wheels. |
| How long is this vehicle, 2019 Mercedes-Benz EQC SUV? | 4762 mm 187.48 in. |
| How wide is the vehicle, 2019 Mercedes-Benz EQC SUV? | 1884 mm 74.17 in. |
| What is the curb weight, 2019 Mercedes-Benz EQC (N293) EQC 400 85 kWh (408 Hp) 4MATIC? | 2420 kg 5335.19 lbs. |
| What is the gross weight, 2019 Mercedes-Benz EQC (N293) EQC 400 85 kWh (408 Hp) 4MATIC? | 2940 kg 6481.59 lbs. |
| How much trunk (boot) space, 2019 Mercedes-Benz EQC SUV? | 500 – 1460 l 17.66 – 51.56 cu. ft. |
| How many gears, What type is the gearbox, 2019 Mercedes-Benz EQC (N293) EQC 400 85 kWh (408 Hp) 4MATIC? | 1, automatic transmission |
