| General information | |
|---|---|
| Brand | Mercedes-Benz |
| Model | Sprinter |
| Generation | eSprinter Panel Van (W907/W910) |
| Type (Engine) | 41 kWh (116 Hp) |
| Start of production | December, 2019 year |
| Powertrain Architecture | BEV (Electric Vehicle) |
| Body type | Van |
| Seats | 3 |
| Doors | 4 |
| Performance specs | |
| Fuel Type | Electricity |
| Maximum speed | 120 km/h, Electronically limited 74.56 mph |
| Weight-to-power ratio | 20.9 kg/Hp, 47.9 Hp/tonne |
| Weight-to-torque ratio | 8.2 kg/Nm, 121.7 Nm/tonne |
| Electric cars and hybrids specs | |
| Gross battery capacity | 41 kWh |
| Net (usable) battery capacity | 35 kWh |
| Battery voltage | 365 V |
| Battery technology | Lithium-ion (Li-Ion) |
| Battery location | Below the floor |
| All-electric range (NEDC) | 120 km 74.56 mi |
| Average Energy consumption (WLTP) | 33.9 kWh/100 km
54.56 kWh/100 mi |
| Average Energy consumption (NEDC) | 37.1 kWh/100 km
59.71 kWh/100 mi |
| Charging ports |  Log in to see. |
| Electric motor 1 | |
| Electric motor power | 116 Hp @ 9001 rpm. |
| Electric motor Torque | 295 Nm @ 203 rpm.
217.58 lb.-ft. @ 203 rpm. |
| Electric motor model/code | EM6000 |
| Electric motor location | Front axle, Transverse |
| System power | 116 Hp @ 9001 rpm. |
| System torque | 295 Nm @ 203 rpm. 217.58 lb.-ft. @ 203 rpm. |
|
|
|
| Space, Volume and weights | |
| Kerb Weight | 2424 kg 5344.01 lbs. |
| Max. weight | 3500 kg 7716.18 lbs. |
| Max load | 1076 kg 2372.17 lbs. |
| Trunk (boot) space – minimum | 11000 l 388.46 cu. ft. |
| Max. roof load | 150 kg 330.69 lbs. |
| Dimensions | |
| Length | 6088 mm 239.69 in. |
| Width | 2020 mm 79.53 in. |
| Height | 2687 mm 105.79 in. |
| Wheelbase | 3924 mm 154.49 in. |
| Front overhang | 1021 mm 40.2 in. |
| Rear overhang | 1152 mm 45.35 in. |
| Minimum turning circle (turning diameter) | 15.7 m 51.51 ft. |
| Drivetrain, brakes and suspension specs | |
| Drivetrain Architecture | One electric motor drives the front wheels. |
| Drive wheel | Front wheel drive |
| Number of gears and type of gearbox | 1 gears, automatic transmission |
| Front suspension | Leaf spring |
| Rear suspension | Leaf spring |
| Assisting systems | ABS (Anti-lock braking system) |
| Tires size | 225/75 R16 |
| Wheel rims size | 6.5J x 16 |
| What is the body type, Mercedes-Benz eSprinter Panel Van (W907/W910)? | Van, 4 Doors, 3 Seats |
|---|---|
| What is the range of pure electric driving, 41 kWh (116 Hp)? | 120 km 74.56 mi |
| What is electricity consumption, Mercedes-Benz eSprinter Panel Van (W907/W910) 41 kWh (116 Hp)? | 33.9 kWh/100 km 54.56 kWh/100 mi 62 MPGe 2.9 km/kWh 1.8 mi/kWh |
| How fast is the car, 2019 eSprinter Panel Van (W907/W910) 41 kWh (116 Hp)? | 120 km/h | 74.56 mph |
| How much power, Mercedes-Benz Sprinter Van 2019 41 kWh (116 Hp)? | 116 Hp, 295 Nm 217.58 lb.-ft. |
| What is the drivetrain, Mercedes-Benz eSprinter Panel Van (W907/W910) Van 2019 41 kWh (116 Hp)? | Front wheel drive. BEV (Electric Vehicle). One electric motor drives the front wheels. |
| How long is this vehicle, 2019 Mercedes-Benz Sprinter Van? | 6088 mm 239.69 in. |
| How wide is the vehicle, 2019 Mercedes-Benz Sprinter Van? | 2020 mm 79.53 in. |
| What is the curb weight, 2019 Mercedes-Benz eSprinter Panel Van (W907/W910) 41 kWh (116 Hp)? | 2424 kg 5344.01 lbs. |
| What is the gross weight, 2019 Mercedes-Benz eSprinter Panel Van (W907/W910) 41 kWh (116 Hp)? | 3500 kg 7716.18 lbs. |
| How much trunk (boot) space, 2019 Mercedes-Benz Sprinter Van? | 11000 l 388.46 cu. ft. |
| How many gears, What type is the gearbox, 2019 Mercedes-Benz eSprinter Panel Van (W907/W910) 41 kWh (116 Hp)? | 1, automatic transmission |
