| General information | |
|---|---|
| Brand | Mercedes-Benz |
| Model | G-class |
| Generation | G-class (W463, facelift 2000) |
| Type (Engine) | G 270 CDI (156 Hp) 4MATIC Automatic |
| Start of production | December, 2001 year |
| End of production | August, 2006 year |
| Powertrain Architecture | Internal Combustion engine |
| Body type | Off-road vehicle |
| Seats | 5 |
| Doors | 3 |
| Performance specs | |
| Fuel consumption (economy) – urban (NEDC) | 13.7 l/100 km 17.2 US mpg 20.6 UK mpg 7.3 km/l |
| Fuel consumption (economy) – extra urban (NEDC) | 9.9 l/100 km 23.8 US mpg 28.5 UK mpg 10.1 km/l |
| Fuel consumption (economy) – combined (NEDC) | 11.3 l/100 km 20.8 US mpg 25 UK mpg 8.8 km/l |
| CO2 emissions (NEDC) | 289 g/km |
| Fuel Type | Diesel |
| Acceleration 0 – 100 km/h | 13.2 sec |
| Acceleration 0 – 62 mph | 13.2 sec |
| Acceleration 0 – 60 mph (Calculated by Auto-Data.net) | 12.5 sec |
| Maximum speed | 156 km/h 96.93 mph |
| Emission standard | Euro 3 |
| Weight-to-power ratio | 14.6 kg/Hp, 68.6 Hp/tonne |
| Weight-to-torque ratio | 5.7 kg/Nm, 175.8 Nm/tonne |
| Engine specs | |
| Power | 156 Hp @ 3800 rpm. |
| Power per litre | 58.1 Hp/l |
| Torque | 400 Nm @ 1800-2600 rpm. 295.02 lb.-ft. @ 1800-2600 rpm. |
| Engine layout | Front, Longitudinal |
| Engine Model/Code | OM 612.966 |
| Engine displacement | 2685 cm3 163.85 cu. in. |
| Number of cylinders | 5 |
| Engine configuration | Inline |
| Cylinder Bore | 88 mm 3.46 in. |
| Piston Stroke | 88.3 mm 3.48 in. |
| Compression ratio | 18:1 |
| Number of valves per cylinder | 4 |
| Fuel injection system | Diesel Commonrail |
| Engine aspiration | Turbocharger, Intercooler |
| Valvetrain | DOHC |
| Engine oil capacity | 7.5 l 7.93 US qt | 6.6 UK qt |
| Engine oil specification |  Log in to see. |
| Coolant | 8 l 8.45 US qt | 7.04 UK qt |
|
|
|
| Space, Volume and weights | |
| Kerb Weight | 2275 kg 5015.52 lbs. |
| Max. weight | 2850 kg 6283.17 lbs. |
| Max load | 575 kg 1267.66 lbs. |
| Trunk (boot) space – minimum | 250 l 8.83 cu. ft. |
| Trunk (boot) space – maximum | 1580 l 55.8 cu. ft. |
| Fuel tank capacity | 96 l 25.36 US gal | 21.12 UK gal |
| Max. roof load | 150 kg 330.69 lbs. |
| Permitted trailer load with brakes (12%) | 2850 kg 6283.17 lbs. |
| Permitted trailer load without brakes | 750 kg 1653.47 lbs. |
| Dimensions | |
| Length | 4230 mm 166.54 in. |
| Width | 1760 mm 69.29 in. |
| Width including mirrors | 2007 mm 79.02 in. |
| Height | 1931 mm 76.02 in. |
| Wheelbase | 2400 mm 94.49 in. |
| Front track | 1475 mm 58.07 in. |
| Rear (Back) track | 1475 mm 58.07 in. |
| Ride height (ground clearance) | 205 mm 8.07 in. |
| Drag coefficient (Cd) | 0.54 |
| Minimum turning circle (turning diameter) | 11.3 m 37.07 ft. |
| Approach angle | 36° |
| Departure angle | 27° |
| Ramp-over (brakeover) angle | 23° |
| Climb angle | 38.7° |
| Wading depth | 500 mm 19.69 in. |
| Drivetrain, brakes and suspension specs | |
| Drivetrain Architecture | The Internal combustion engine (ICE) drives permanently the four wheels of the vehicle. |
| Drive wheel | All wheel drive (4×4) |
| Number of gears and type of gearbox | 5 gears, automatic transmission |
| Front suspension | Coil spring, Rigid axle suspension, Trailing arm |
| Rear suspension | Rigid axle suspension, Trailing arm, Coil spring |
| Front brakes | Ventilated discs |
| Rear brakes | Disc |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Cone worm with recirculation balls |
| Power steering | Hydraulic Steering |
| Tires size | 265/70 R 16 |
| Wheel rims size | 7.5 J x 16 |
