| General information | |
|---|---|
| Brand | Mercedes-Benz |
| Model | G-class |
| Generation | G-class (W463) |
| Type (Engine) | G 230 (126 Hp) 4MATIC Automatic |
| Start of production | September, 1993 year |
| End of production | July, 1994 year |
| Powertrain Architecture | Internal Combustion engine |
| Body type | Off-road vehicle |
| Seats | 5 |
| Doors | 3 |
| Performance specs | |
| Fuel consumption (economy) – urban | 16.4 l/100 km 14.3 US mpg 17.2 UK mpg 6.1 km/l |
| Fuel consumption (economy) – extra urban | 12.7 l/100 km 18.5 US mpg 22.2 UK mpg 7.9 km/l |
| Fuel Type | Petrol (Gasoline) |
| Acceleration 0 – 100 km/h | 18.4 sec |
| Acceleration 0 – 62 mph | 18.4 sec |
| Acceleration 0 – 60 mph (Calculated by Auto-Data.net) | 17.5 sec |
| Maximum speed | 145 km/h 90.1 mph |
| Weight-to-power ratio | 16.3 kg/Hp, 61.2 Hp/tonne |
| Weight-to-torque ratio | 10.8 kg/Nm, 92.2 Nm/tonne |
| Engine specs | |
| Power | 126 Hp @ 5000 rpm. |
| Power per litre | 54.8 Hp/l |
| Torque | 190 Nm @ 4000 rpm. 140.14 lb.-ft. @ 4000 rpm. |
| Engine layout | Front, Longitudinal |
| Engine Model/Code | M 102.989 |
| Engine displacement | 2298 cm3 140.23 cu. in. |
| Number of cylinders | 4 |
| Engine configuration | Inline |
| Cylinder Bore | 95.5 mm 3.76 in. |
| Piston Stroke | 80.2 mm 3.16 in. |
| Compression ratio | 9:1 |
| Number of valves per cylinder | 2 |
| Fuel injection system | Multi-port manifold injection |
| Engine aspiration | Naturally aspirated engine |
| Valvetrain | SOHC |
| Engine oil capacity | 6 l 6.34 US qt | 5.28 UK qt |
| Engine oil specification |  Log in to see. |
| Coolant | 5 l 5.28 US qt | 4.4 UK qt |
|
|
|
| Space, Volume and weights | |
| Kerb Weight | 2060 kg 4541.52 lbs. |
| Max. weight | 2620 kg 5776.11 lbs. |
| Max load | 560 kg 1234.59 lbs. |
| Fuel tank capacity | 96 l 25.36 US gal | 21.12 UK gal |
| Dimensions | |
| Length | 4185 mm 164.76 in. |
| Width | 1690 mm 66.54 in. |
| Height | 1908 mm 75.12 in. |
| Wheelbase | 2400 mm 94.49 in. |
| Front track | 1425 mm 56.1 in. |
| Rear (Back) track | 1425 mm 56.1 in. |
| Drivetrain, brakes and suspension specs | |
| Drivetrain Architecture | The Internal combustion engine (ICE) drives permanently the four wheels of the vehicle. |
| Drive wheel | All wheel drive (4×4) |
| Number of gears and type of gearbox | 4 gears, automatic transmission |
| Front suspension | Coil spring, Rigid axle suspension, Trailing arm |
| Rear suspension | Rigid axle suspension, Trailing arm, Coil spring |
| Front brakes | Disc |
| Rear brakes | Drum |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Cone worm with recirculation balls |
| Power steering | Hydraulic Steering |
| Tires size | 205/80 R16 |
| Wheel rims size | 6J x 16 |
| What is the body type, Mercedes-Benz G-class (W463)? | Off-road vehicle, 3 Doors, 5 Seats |
|---|---|
| How fast is the car, 1993 G-class (W463) G 230 (126 Hp) 4MATIC Automatic? | 145 km/h | 90.1 mph 0-100 km/h: 18.4 sec 0-60 mph: 17.5 sec |
| How much power, Mercedes-Benz G-class Off-road vehicle 1993 G 230 (126 Hp) 4MATIC Automatic? | 126 Hp, 190 Nm 140.14 lb.-ft. |
| What is the engine size, Mercedes-Benz G-class Off-road vehicle 1993 G 230 (126 Hp) 4MATIC Automatic? | 2.3 l 2298 cm3 140.23 cu. in. |
| How many cylinders, 1993 Mercedes-Benz G 230 (126 Hp) 4MATIC Automatic? | 4, Inline |
| What is the drivetrain, Mercedes-Benz G-class (W463) Off-road vehicle 1993 G 230 (126 Hp) 4MATIC Automatic? | All wheel drive (4×4). Internal Combustion engine. The Internal combustion engine (ICE) drives permanently the four wheels of the vehicle. |
| How long is this vehicle, 1993 Mercedes-Benz G-class Off-road vehicle? | 4185 mm 164.76 in. |
| How wide is the vehicle, 1993 Mercedes-Benz G-class Off-road vehicle? | 1690 mm 66.54 in. |
| What is the curb weight, 1993 Mercedes-Benz G-class (W463) G 230 (126 Hp) 4MATIC Automatic? | 2060 kg 4541.52 lbs. |
| What is the gross weight, 1993 Mercedes-Benz G-class (W463) G 230 (126 Hp) 4MATIC Automatic? | 2620 kg 5776.11 lbs. |
| How many gears, What type is the gearbox, 1993 Mercedes-Benz G-class (W463) G 230 (126 Hp) 4MATIC Automatic? | 4, automatic transmission |
