| General information | |
|---|---|
| Brand | Mercedes-Benz |
| Model | GLE |
| Generation | GLE SUV (V167) |
| Type (Engine) | GLE 350de (320 Hp) Plug-in Hybrid 4MATIC 9G-TRONIC |
| Start of production | September, 2019 year |
| End of production | 2023 year |
| Powertrain Architecture | PHEV (Plug-in Hybrid Electric Vehicle) |
| Body type | SUV |
| Seats | 5 |
| Doors | 5 |
| Performance specs | |
| Combined fuel consumption (WLTP) | 0.7-1 l/100 km 336 – 235.2 US mpg 403.5 – 282.5 UK mpg 142.9 – 100 km/l |
| CO2 emissions (WLTP) | 18-25 g/km |
| Fuel consumption (economy) – combined (NEDC) | 1.1 l/100 km 213.8 US mpg 256.8 UK mpg 90.9 km/l |
| CO2 emissions (NEDC) | 29 g/km |
| Fuel Type | Diesel / electricity |
| Acceleration 0 – 100 km/h | 6.8 sec |
| Acceleration 0 – 62 mph | 6.8 sec |
| Acceleration 0 – 60 mph (Calculated by Auto-Data.net) | 6.5 sec |
| Maximum speed | 210 km/h 130.49 mph |
| Emission standard | Euro 6d ISC-FCM |
| Weight-to-power ratio | 8.1 kg/Hp, 124 Hp/tonne |
| Weight-to-torque ratio | 3.7 kg/Nm, 271.3 Nm/tonne |
| Electric cars and hybrids specs | |
| Gross battery capacity | 31.2 kWh |
| Net (usable) battery capacity | 27 kWh |
| Battery technology | Lithium-ion (Li-Ion) |
| Battery location | Under the trunk |
| All-electric range (WLTP) | 85-98 km 52.82 – 60.89 mi |
| All-electric range (NEDC) | 93-106 km 57.79 – 65.87 mi |
| Average Energy consumption (WLTP) | 23.9-26.4 kWh/100 km
38.46 – 42.49 kWh/100 mi |
| Average Energy consumption (NEDC) | 25.4 kWh/100 km
40.88 kWh/100 mi |
| Max speed (electric) | 160 km/h
99.42 mph |
| Charging ports |  Log in to see. |
| Electric motor 1 | |
| Electric motor power | 136 Hp |
| Electric motor Torque | 440 Nm @ 0-2500 rpm.
324.53 lb.-ft. @ 0-2500 rpm. |
| Electric motor location | Between the combustion engine and the transmission |
| System power | 320 Hp |
| System torque | 700 Nm 516.29 lb.-ft. |
| Internal combustion engine specs | |
| Power | 194 Hp @ 3800 rpm. |
| Power per litre | 99.5 Hp/l |
| Torque | 400 Nm @ 1600-2800 rpm. 295.02 lb.-ft. @ 1600-2800 rpm. |
| Engine layout | Front, Longitudinal |
| Engine Model/Code | OM 654.920 |
| Engine displacement | 1950 cm3 119 cu. in. |
| Number of cylinders | 4 |
| Engine configuration | Inline |
| Cylinder Bore | 82 mm 3.23 in. |
| Piston Stroke | 92.3 mm 3.63 in. |
| Compression ratio | 15.5:1 |
| Number of valves per cylinder | 4 |
| Fuel injection system | Diesel Commonrail |
| Engine aspiration | Turbocharger, Intercooler |
| Valvetrain | DOHC |
| Engine oil capacity | 6.5 l 6.87 US qt | 5.72 UK qt |
| Engine oil specification | Log in to see. |
| Engine systems | Start & Stop System Particulate filter |
|
|
|
| Space, Volume and weights | |
| Kerb Weight | 2580 kg 5687.93 lbs. |
| Max. weight | 3260 kg 7187.07 lbs. |
| Max load | 680 kg 1499.14 lbs. |
| Trunk (boot) space – minimum | 490 l 17.3 cu. ft. |
| Trunk (boot) space – maximum | 1915 l 67.63 cu. ft. |
| Fuel tank capacity | 65 l 17.17 US gal | 14.3 UK gal |
| AdBlue tank | 32 l 8.45 US gal | 7.04 UK gal |
| Max. roof load | 100 kg 220.46 lbs. |
| Permitted trailer load with brakes (12%) | 2700 kg 5952.48 lbs. |
| Permitted trailer load without brakes | 750 kg 1653.47 lbs. |
| Permitted towbar download | 108 kg 238.1 lbs. |
| Dimensions | |
| Length | 4924 mm 193.86 in. |
| Width | 1947 mm 76.65 in. |
| Width with mirrors folded | 2010 mm 79.13 in. |
| Width including mirrors | 2157 mm 84.92 in. |
| Height | 1795 mm 70.67 in. |
| Wheelbase | 2995 mm 117.91 in. |
| Front track | 1680 mm 66.14 in. |
| Rear (Back) track | 1727 mm 67.99 in. |
| Front overhang | 925 mm 36.42 in. |
| Rear overhang | 1004 mm 39.53 in. |
| Ride height (ground clearance) | 180-205 mm 7.09 – 8.07 in. |
| Drag coefficient (Cd) | 0.36 |
| Minimum turning circle (turning diameter) | 12.02 m 39.44 ft. |
| Approach angle | 23-25° |
| Departure angle | 23-25° |
| Ramp-over (brakeover) angle | 15-17° |
| Drivetrain, brakes and suspension specs | |
| Drivetrain Architecture | The Internal combustion engine (ICE) and the electric motor permanently drive the four wheels of the car with the ability to work in full electric or mixed mode. |
| Drive wheel | All wheel drive (4×4) |
| Number of gears and type of gearbox | 9 gears, automatic transmission G-TRONIC |
| Front suspension | Double wishbone |
| Rear suspension | Independent multi-link suspension |
| Front brakes | Ventilated discs |
| Rear brakes | Ventilated discs |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Power steering | Electric Steering |
| Tires size | Front wheel tires: 275/55 R19; 275/50 R20; 275/45 R21; 285/40 R22 Rear wheel tires: 275/55 R19; 275/50 R20; 315/40 R21; 325/35 R22 |
| Wheel rims size | Front wheel rims: 8.5J x 19; 8.5J x 20; 10J x 21; 10J x 22 Rear wheel rims: 8.5J x 19; 8.5J x 20; 11J x 21; 11J x 22 |
| What is the body type, Mercedes-Benz GLE SUV (V167)? | SUV, 5 Doors, 5 Seats |
|---|---|
| What is the fuel economy, Mercedes-Benz GLE SUV (V167) GLE 350de (320 Hp) Plug-in Hybrid 4MATIC 9G-TRONIC? | 0.7-1 l/100 km 336 – 235.2 US mpg 403.5 – 282.5 UK mpg 142.9 – 100 km/l |
| How ECO is the car, Mercedes-Benz GLE GLE 350de (320 Hp) Plug-in Hybrid 4MATIC 9G-TRONIC? | 18-25 g/km CO2 Euro 6d ISC-FCM |
| What is the range of pure electric driving, GLE 350de (320 Hp) Plug-in Hybrid 4MATIC 9G-TRONIC? | 85-98 km 52.82 – 60.89 mi |
| What is electricity consumption, Mercedes-Benz GLE SUV (V167) GLE 350de (320 Hp) Plug-in Hybrid 4MATIC 9G-TRONIC? | 23.9-26.4 kWh/100 km 38.46 – 42.49 kWh/100 mi 88 – 79 MPGe 4.2 – 3.8 km/kWh 2.6 – 2.4 mi/kWh |
| How fast is the car, 2019 GLE SUV (V167) GLE 350de (320 Hp) Plug-in Hybrid 4MATIC 9G-TRONIC? | 210 km/h | 130.49 mph 0-100 km/h: 6.8 sec 0-60 mph: 6.5 sec |
| How much power, Mercedes-Benz GLE SUV 2019 GLE 350de (320 Hp) Plug-in Hybrid 4MATIC 9G-TRONIC? | 320 Hp, 700 Nm 516.29 lb.-ft. |
| What is the engine size, Mercedes-Benz GLE SUV 2019 GLE 350de (320 Hp) Plug-in Hybrid 4MATIC 9G-TRONIC? | 2.0 l 1950 cm3 119 cu. in. |
| How many cylinders, 2019 Mercedes-Benz GLE 350de (320 Hp) Plug-in Hybrid 4MATIC 9G-TRONIC? | 4, Inline |
| What is the drivetrain, Mercedes-Benz GLE SUV (V167) SUV 2019 GLE 350de (320 Hp) Plug-in Hybrid 4MATIC 9G-TRONIC? | All wheel drive (4×4). PHEV (Plug-in Hybrid Electric Vehicle). The Internal combustion engine (ICE) and the electric motor permanently drive the four wheels of the car with the ability to work in full electric or mixed mode. |
| How long is this vehicle, 2019 Mercedes-Benz GLE SUV? | 4924 mm 193.86 in. |
| How wide is the vehicle, 2019 Mercedes-Benz GLE SUV? | 1947 mm 76.65 in. |
| What is the curb weight, 2019 Mercedes-Benz GLE SUV (V167) GLE 350de (320 Hp) Plug-in Hybrid 4MATIC 9G-TRONIC? | 2580 kg 5687.93 lbs. |
| What is the gross weight, 2019 Mercedes-Benz GLE SUV (V167) GLE 350de (320 Hp) Plug-in Hybrid 4MATIC 9G-TRONIC? | 3260 kg 7187.07 lbs. |
| How much trunk (boot) space, 2019 Mercedes-Benz GLE SUV? | 490 – 1915 l 17.3 – 67.63 cu. ft. |
| How many gears, What type is the gearbox, 2019 Mercedes-Benz GLE SUV (V167) GLE 350de (320 Hp) Plug-in Hybrid 4MATIC 9G-TRONIC? | 9, automatic transmission G-TRONIC |
