| General information | |
|---|---|
| Brand | Mercedes-Benz |
| Model | GLE |
| Generation | GLE SUV (W166) |
| Type (Engine) | GLE 500e V6 (442 Hp) Plug-in Hybrid 4MATIC 7G-TRONIC PLUS |
| Start of production | 2015 year |
| End of production | 2018 year |
| Powertrain Architecture | PHEV (Plug-in Hybrid Electric Vehicle) |
| Body type | SUV |
| Seats | 5 |
| Doors | 5 |
| Performance specs | |
| Fuel consumption (economy) – combined (NEDC) | 3.3-3.7 l/100 km 71.3 – 63.6 US mpg 85.6 – 76.3 UK mpg 30.3 – 27 km/l |
| CO2 emissions (NEDC) | 78-84 g/km |
| Fuel Type | Petrol / electricity |
| Acceleration 0 – 100 km/h | 5.3 sec |
| Acceleration 0 – 62 mph | 5.3 sec |
| Acceleration 0 – 60 mph (Calculated by Auto-Data.net) | 5 sec |
| Maximum speed | 245 km/h 152.24 mph |
| Emission standard | Euro 6 |
| Weight-to-power ratio | 5.4 kg/Hp, 184.9 Hp/tonne |
| Weight-to-torque ratio | 3.7 kg/Nm, 272 Nm/tonne |
| Electric cars and hybrids specs | |
| Gross battery capacity | 8.8 kWh |
| Net (usable) battery capacity | 7.2 kWh |
| Battery technology | Lithium-ion (Li-Ion) |
| Battery location | Inside the trunk |
| All-electric range (NEDC) | 30 km 18.64 mi |
| Average Energy consumption (NEDC) | 16.7 kWh/100 km
26.88 kWh/100 mi |
| Max speed (electric) | 130 km/h
80.78 mph |
| Charging ports |  Log in to see. |
| Electric motor 1 | |
| Electric motor power | 116 Hp @ 3500 rpm. |
| Electric motor Torque | 340 Nm @ 0-2000 rpm.
250.77 lb.-ft. @ 0-2000 rpm. |
| Electric motor location | Between the combustion engine and the transmission |
| System power | 442 Hp @ 5250-5500 rpm. |
| System torque | 650 Nm 479.42 lb.-ft. |
| Internal combustion engine specs | |
| Power | 333 Hp @ 5250-6000 rpm. |
| Power per litre | 111.1 Hp/l |
| Torque | 480 Nm @ 1600-4000 rpm. 354.03 lb.-ft. @ 1600-4000 rpm. |
| Engine layout | Front, Longitudinal |
| Engine Model/Code | M 276.821 |
| Engine displacement | 2996 cm3 182.83 cu. in. |
| Number of cylinders | 6 |
| Engine configuration | V-engine |
| Cylinder Bore | 88 mm 3.46 in. |
| Piston Stroke | 82.1 mm 3.23 in. |
| Compression ratio | 10.5:1 |
| Number of valves per cylinder | 4 |
| Fuel injection system | Direct injection |
| Engine aspiration | BiTurbo, Intercooler |
| Valvetrain | DOHC |
| Engine oil capacity | 7 l 7.4 US qt | 6.16 UK qt |
| Engine oil specification | Log in to see. |
| Coolant | 9.7 l 10.25 US qt | 8.53 UK qt |
| Engine systems | Start & Stop System |
|
|
|
| Space, Volume and weights | |
| Kerb Weight | 2390 kg 5269.05 lbs. |
| Max. weight | 3050 kg 6724.1 lbs. |
| Max load | 660 kg 1455.05 lbs. |
| Trunk (boot) space – minimum | 480 l 16.95 cu. ft. |
| Trunk (boot) space – maximum | 1800 l 63.57 cu. ft. |
| Fuel tank capacity | 80 l 21.13 US gal | 17.6 UK gal |
| Max. roof load | 100 kg 220.46 lbs. |
| Permitted trailer load with brakes (12%) | 2000 kg 4409.25 lbs. |
| Permitted trailer load without brakes | 750 kg 1653.47 lbs. |
| Permitted towbar download | 160 kg 352.74 lbs. |
| Dimensions | |
| Length | 4819 mm 189.72 in. |
| Width | 1935 mm 76.18 in. |
| Width including mirrors | 2141 mm 84.29 in. |
| Height | 1796 mm 70.71 in. |
| Wheelbase | 2915 mm 114.76 in. |
| Front track | 1648 mm 64.88 in. |
| Rear (Back) track | 1663 mm 65.47 in. |
| Front overhang | 890 mm 35.04 in. |
| Rear overhang | 1014 mm 39.92 in. |
| Ride height (ground clearance) | 202 mm 7.95 in. |
| Drag coefficient (Cd) | 0.35 |
| Minimum turning circle (turning diameter) | 11.8 m 38.71 ft. |
| Drivetrain, brakes and suspension specs | |
| Drivetrain Architecture | The Internal combustion engine (ICE) and the electric motor permanently drive the four wheels of the car with the ability to work in full electric or mixed mode. |
| Drive wheel | All wheel drive (4×4) |
| Number of gears and type of gearbox | 7 gears, automatic transmission G-TRONIC PLUS |
| Front suspension | Double wishbone |
| Rear suspension | Independent multi-link suspension |
| Front brakes | Ventilated discs |
| Rear brakes | Ventilated discs |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Power steering | Electric Steering |
| Tires size | 255/50 R19; 265/45 R20; 265/40 R21 |
| Wheel rims size | 8.5J x 19; 9J x 20; 9J x 21 |
| What is the body type, Mercedes-Benz GLE SUV (W166)? | SUV, 5 Doors, 5 Seats |
|---|---|
| What is the fuel economy, Mercedes-Benz GLE SUV (W166) GLE 500e V6 (442 Hp) Plug-in Hybrid 4MATIC 7G-TRONIC PLUS? | 3.3-3.7 l/100 km 71.3 – 63.6 US mpg 85.6 – 76.3 UK mpg 30.3 – 27 km/l |
| How ECO is the car, Mercedes-Benz GLE GLE 500e V6 (442 Hp) Plug-in Hybrid 4MATIC 7G-TRONIC PLUS? | 78-84 g/km CO2 Euro 6 |
| What is the range of pure electric driving, GLE 500e V6 (442 Hp) Plug-in Hybrid 4MATIC 7G-TRONIC PLUS? | 30 km 18.64 mi |
| What is electricity consumption, Mercedes-Benz GLE SUV (W166) GLE 500e V6 (442 Hp) Plug-in Hybrid 4MATIC 7G-TRONIC PLUS? | 16.7 kWh/100 km 26.88 kWh/100 mi 125 MPGe 6 km/kWh 3.7 mi/kWh |
| How fast is the car, 2015 GLE SUV (W166) GLE 500e V6 (442 Hp) Plug-in Hybrid 4MATIC 7G-TRONIC PLUS? | 245 km/h | 152.24 mph 0-100 km/h: 5.3 sec 0-60 mph: 5 sec |
| How much power, Mercedes-Benz GLE SUV 2015 GLE 500e V6 (442 Hp) Plug-in Hybrid 4MATIC 7G-TRONIC PLUS? | 442 Hp, 650 Nm 479.42 lb.-ft. |
| What is the engine size, Mercedes-Benz GLE SUV 2015 GLE 500e V6 (442 Hp) Plug-in Hybrid 4MATIC 7G-TRONIC PLUS? | 3.0 l 2996 cm3 182.83 cu. in. |
| How many cylinders, 2015 Mercedes-Benz GLE 500e V6 (442 Hp) Plug-in Hybrid 4MATIC 7G-TRONIC PLUS? | 6, V-engine |
| What is the drivetrain, Mercedes-Benz GLE SUV (W166) SUV 2015 GLE 500e V6 (442 Hp) Plug-in Hybrid 4MATIC 7G-TRONIC PLUS? | All wheel drive (4×4). PHEV (Plug-in Hybrid Electric Vehicle). The Internal combustion engine (ICE) and the electric motor permanently drive the four wheels of the car with the ability to work in full electric or mixed mode. |
| How long is this vehicle, 2015 Mercedes-Benz GLE SUV? | 4819 mm 189.72 in. |
| How wide is the vehicle, 2015 Mercedes-Benz GLE SUV? | 1935 mm 76.18 in. |
| What is the curb weight, 2015 Mercedes-Benz GLE SUV (W166) GLE 500e V6 (442 Hp) Plug-in Hybrid 4MATIC 7G-TRONIC PLUS? | 2390 kg 5269.05 lbs. |
| What is the gross weight, 2015 Mercedes-Benz GLE SUV (W166) GLE 500e V6 (442 Hp) Plug-in Hybrid 4MATIC 7G-TRONIC PLUS? | 3050 kg 6724.1 lbs. |
| How much trunk (boot) space, 2015 Mercedes-Benz GLE SUV? | 480 – 1800 l 16.95 – 63.57 cu. ft. |
| How many gears, What type is the gearbox, 2015 Mercedes-Benz GLE SUV (W166) GLE 500e V6 (442 Hp) Plug-in Hybrid 4MATIC 7G-TRONIC PLUS? | 7, automatic transmission G-TRONIC PLUS |
