| General information | |
|---|---|
| Brand | Mercedes-Benz |
| Model | M-class |
| Generation | M-class (W164, facelift 2008) |
| Type (Engine) | ML 500 V8 (388 Hp) 4MATIC 7G-TRONIC |
| Start of production | 2008 year |
| End of production | 2009 year |
| Powertrain Architecture | Internal Combustion engine |
| Body type | SUV |
| Seats | 5 |
| Doors | 5 |
| Performance specs | |
| Fuel consumption (economy) – urban (NEDC) | 17.6 l/100 km 13.4 US mpg 16.1 UK mpg 5.7 km/l |
| Fuel consumption (economy) – extra urban (NEDC) | 10 l/100 km 23.5 US mpg 28.2 UK mpg 10 km/l |
| Fuel consumption (economy) – combined (NEDC) | 12.8 l/100 km 18.4 US mpg 22.1 UK mpg 7.8 km/l |
| CO2 emissions (NEDC) | 304 g/km |
| Fuel Type | Petrol (Gasoline) |
| Acceleration 0 – 100 km/h | 5.8 sec |
| Acceleration 0 – 62 mph | 5.8 sec |
| Acceleration 0 – 60 mph (Calculated by Auto-Data.net) | 5.5 sec |
| Maximum speed | 250 km/h, Electronically limited 155.34 mph |
| Emission standard | Euro 4 |
| Weight-to-power ratio | 5.4 kg/Hp, 183.9 Hp/tonne |
| Weight-to-torque ratio | 4 kg/Nm, 251.2 Nm/tonne |
| Engine specs | |
| Power | 388 Hp @ 6000 rpm. |
| Power per litre | 71 Hp/l |
| Torque | 530 Nm @ 2800-4800 rpm. 390.91 lb.-ft. @ 2800-4800 rpm. |
| Engine layout | Front, Longitudinal |
| Engine Model/Code | M 273.963 |
| Engine displacement | 5461 cm3 333.25 cu. in. |
| Number of cylinders | 8 |
| Engine configuration | V-engine |
| Cylinder Bore | 98 mm 3.86 in. |
| Piston Stroke | 90.5 mm 3.56 in. |
| Number of valves per cylinder | 4 |
| Fuel injection system | Multi-port manifold injection |
| Engine aspiration | Naturally aspirated engine |
| Valvetrain | DOHC |
| Engine oil capacity | 9 l 9.51 US qt | 7.92 UK qt |
| Engine oil specification |  Log in to see. |
| Coolant | 12 l 12.68 US qt | 10.56 UK qt |
|
|
|
| Space, Volume and weights | |
| Kerb Weight | 2110 kg 4651.75 lbs. |
| Max. weight | 2830 kg 6239.08 lbs. |
| Max load | 720 kg 1587.33 lbs. |
| Trunk (boot) space – minimum | 833 l 29.42 cu. ft. |
| Trunk (boot) space – maximum | 2050 l 72.4 cu. ft. |
| Fuel tank capacity | 95 l 25.1 US gal | 20.9 UK gal |
| Permitted trailer load with brakes (12%) | 3500 kg 7716.18 lbs. |
| Permitted trailer load without brakes | 750 kg 1653.47 lbs. |
| Dimensions | |
| Length | 4781 mm 188.23 in. |
| Width | 1911 mm 75.24 in. |
| Width including mirrors | 2124 mm 83.62 in. |
| Height | 1815 mm 71.46 in. |
| Wheelbase | 2915 mm 114.76 in. |
| Front track | 1636 mm 64.41 in. |
| Rear (Back) track | 1639 mm 64.53 in. |
| Front overhang | 866 mm 34.09 in. |
| Rear overhang | 1000 mm 39.37 in. |
| Ride height (ground clearance) | 186-261 mm 7.32 – 10.28 in. |
| Drag coefficient (Cd) | 0.37 |
| Minimum turning circle (turning diameter) | 11.6 m 38.06 ft. |
| Approach angle | 25-31° |
| Departure angle | 24-29° |
| Ramp-over (brakeover) angle | 14-21° |
| Climb angle | 45° |
| Wading depth | 500 mm 19.69 in. |
| Drivetrain, brakes and suspension specs | |
| Drivetrain Architecture | The Internal combustion engine (ICE) drives permanently the four wheels of the vehicle. |
| Drive wheel | All wheel drive (4×4) |
| Number of gears and type of gearbox | 7 gears, automatic transmission G-TRONIC |
| Front suspension | Double wishbone, Transverse stabilizer, Air suspension |
| Rear suspension | Independent multi-link suspension, Air suspension, Transverse stabilizer |
| Front brakes | Ventilated discs |
| Rear brakes | Disc |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Power steering | Hydraulic Steering |
| Tires size | Front wheel tires: 255/50 R19; 265/45 R20; 265/40 R21 Rear wheel tires: 255/50 R19; 285/45 R19; 265/45 R20; 265/40 R21 |
| Wheel rims size | Front wheel rims: 8J x 19; 8.5J x 19; 8.5J x 20; 9J x 21 Rear wheel rims: 8J x 19; 9.5J x 19; 8.5J x 20; 9J x 21 |
| What is the body type, Mercedes-Benz M-class (W164, facelift 2008)? | SUV, 5 Doors, 5 Seats |
|---|---|
| What is the fuel economy, Mercedes-Benz M-class (W164, facelift 2008) ML 500 V8 (388 Hp) 4MATIC 7G-TRONIC? | 12.8 l/100 km 18.4 US mpg 22.1 UK mpg 7.8 km/l |
| How ECO is the car, Mercedes-Benz M-class ML 500 V8 (388 Hp) 4MATIC 7G-TRONIC? | 304 g/km CO2 Euro 4 |
| How fast is the car, 2008 M-class (W164, facelift 2008) ML 500 V8 (388 Hp) 4MATIC 7G-TRONIC? | 250 km/h | 155.34 mph 0-100 km/h: 5.8 sec 0-60 mph: 5.5 sec |
| How much power, Mercedes-Benz M-class SUV 2008 ML 500 V8 (388 Hp) 4MATIC 7G-TRONIC? | 388 Hp, 530 Nm 390.91 lb.-ft. |
| What is the engine size, Mercedes-Benz M-class SUV 2008 ML 500 V8 (388 Hp) 4MATIC 7G-TRONIC? | 5.5 l 5461 cm3 333.25 cu. in. |
| How many cylinders, 2008 Mercedes-Benz ML 500 V8 (388 Hp) 4MATIC 7G-TRONIC? | 8, V-engine |
| What is the drivetrain, Mercedes-Benz M-class (W164, facelift 2008) SUV 2008 ML 500 V8 (388 Hp) 4MATIC 7G-TRONIC? | All wheel drive (4×4). Internal Combustion engine. The Internal combustion engine (ICE) drives permanently the four wheels of the vehicle. |
| How long is this vehicle, 2008 Mercedes-Benz M-class SUV? | 4781 mm 188.23 in. |
| How wide is the vehicle, 2008 Mercedes-Benz M-class SUV? | 1911 mm 75.24 in. |
| What is the curb weight, 2008 Mercedes-Benz M-class (W164, facelift 2008) ML 500 V8 (388 Hp) 4MATIC 7G-TRONIC? | 2110 kg 4651.75 lbs. |
| What is the gross weight, 2008 Mercedes-Benz M-class (W164, facelift 2008) ML 500 V8 (388 Hp) 4MATIC 7G-TRONIC? | 2830 kg 6239.08 lbs. |
| How much trunk (boot) space, 2008 Mercedes-Benz M-class SUV? | 833 – 2050 l 29.42 – 72.4 cu. ft. |
| How many gears, What type is the gearbox, 2008 Mercedes-Benz M-class (W164, facelift 2008) ML 500 V8 (388 Hp) 4MATIC 7G-TRONIC? | 7, automatic transmission G-TRONIC |
