| General information | |
|---|---|
| Brand | Mercedes-Benz |
| Model | S-class |
| Generation | S-class Cabriolet (A217, facelift 2017) |
| Type (Engine) | S 560 (469 Hp) G-TRONIC |
| Start of production | 2017 year |
| End of production | 2020 year |
| Powertrain Architecture | Internal Combustion engine |
| Body type | Cabriolet |
| Seats | 4 |
| Doors | 2 |
| Performance specs | |
| Fuel consumption at Low speed (WLTP) | 10.3 l/100 km 22.8 US mpg 27.4 UK mpg 9.7 km/l |
| Fuel consumption at very high speed (WLTP) | 10.7 l/100 km 22 US mpg 26.4 UK mpg 9.3 km/l |
| CO2 emissions (WLTP) | 235-243 g/km |
| Fuel consumption (economy) – urban | 12.5-12.7 l/100 km 18.8 – 18.5 US mpg 22.6 – 22.2 UK mpg 8 – 7.9 km/l |
| Fuel consumption (economy) – extra urban | 6.5-6.8 l/100 km 36.2 – 34.6 US mpg 43.5 – 41.5 UK mpg 15.4 – 14.7 km/l |
| Fuel consumption (economy) – combined | 8.7-9.0 l/100 km 27 – 26.1 US mpg 32.5 – 31.4 UK mpg 11.5 – 11.1 km/l |
| CO2 emissions | 199-204 g/km |
| Fuel Type | Petrol (Gasoline) |
| Acceleration 0 – 100 km/h | 4.6 sec |
| Acceleration 0 – 62 mph | 4.6 sec |
| Acceleration 0 – 60 mph (Calculated by Auto-Data.net) | 4.4 sec |
| Maximum speed | 250 km/h 155.34 mph |
| Emission standard | Euro 6 |
| Weight-to-power ratio | 4.4 kg/Hp, 226 Hp/tonne |
| Weight-to-torque ratio | 3 kg/Nm, 337.3 Nm/tonne |
| Engine specs | |
| Power | 469 Hp @ 5250-5500 rpm. |
| Power per litre | 117.8 Hp/l |
| Torque | 700 Nm @ 2000-4000 rpm. 516.29 lb.-ft. @ 2000-4000 rpm. |
| Engine layout | Front, Longitudinal |
| Engine Model/Code | M 176.980 |
| Engine displacement | 3982 cm3 243 cu. in. |
| Number of cylinders | 8 |
| Engine configuration | V-engine |
| Compression ratio | 10.5:1 |
| Number of valves per cylinder | 4 |
| Fuel injection system | Direct injection |
| Engine aspiration | BiTurbo, Intercooler |
| Engine oil capacity | 9 l 9.51 US qt | 7.92 UK qt |
| Engine oil specification |  Log in to see. |
| Coolant | 14.2 l 15 US qt | 12.49 UK qt |
|
|
|
| Space, Volume and weights | |
| Kerb Weight | 2075 kg 4574.59 lbs. |
| Max. weight | 2625 kg 5787.13 lbs. |
| Max load | 550 kg 1212.54 lbs. |
| Trunk (boot) space – minimum | 350 l 12.36 cu. ft. |
| Fuel tank capacity | 80 l 21.13 US gal | 17.6 UK gal |
| Dimensions | |
| Length | 5032 mm 198.11 in. |
| Width | 1899 mm 74.76 in. |
| Width including mirrors | 2108 mm 82.99 in. |
| Height | 1417 mm 55.79 in. |
| Wheelbase | 2945 mm 115.94 in. |
| Front track | 1625 mm 63.98 in. |
| Rear (Back) track | 1649 mm 64.92 in. |
| Front overhang | 959 mm 37.76 in. |
| Rear overhang | 1128 mm 44.41 in. |
| Drag coefficient (Cd) | 0.29 |
| Minimum turning circle (turning diameter) | 11.60 m 38.06 ft. |
| Drivetrain, brakes and suspension specs | |
| Drivetrain Architecture | The Internal combustion engine (ICE) drives the rear wheels of the vehicle. |
| Drive wheel | Rear wheel drive |
| Number of gears and type of gearbox | 9 gears, automatic transmission G-TRONIC |
| Front suspension | Independent multi-link suspension |
| Rear suspension | Independent multi-link suspension |
| Front brakes | Ventilated discs |
| Rear brakes | Ventilated discs |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Power steering | Electric Steering |
| Tires size | 245/50 R18 |
| Wheel rims size | 18 |
| What is the body type, Mercedes-Benz S-class Cabriolet (A217, facelift 2017)? | Cabriolet, 2 Doors, 4 Seats |
|---|---|
| What is the fuel economy, Mercedes-Benz S-class Cabriolet (A217, facelift 2017) S 560 (469 Hp) G-TRONIC? | 8.7-9.0 l/100 km 27 – 26.1 US mpg 32.5 – 31.4 UK mpg 11.5 – 11.1 km/l |
| How ECO is the car, Mercedes-Benz S-class S 560 (469 Hp) G-TRONIC? | 235-243 g/km CO2 Euro 6 |
| How fast is the car, 2017 S-class Cabriolet (A217, facelift 2017) S 560 (469 Hp) G-TRONIC? | 250 km/h | 155.34 mph 0-100 km/h: 4.6 sec 0-60 mph: 4.4 sec |
| How much power, Mercedes-Benz S-class Cabriolet 2017 S 560 (469 Hp) G-TRONIC? | 469 Hp, 700 Nm 516.29 lb.-ft. |
| What is the engine size, Mercedes-Benz S-class Cabriolet 2017 S 560 (469 Hp) G-TRONIC? | 4.0 l 3982 cm3 243 cu. in. |
| How many cylinders, 2017 Mercedes-Benz S 560 (469 Hp) G-TRONIC? | 8, V-engine |
| What is the drivetrain, Mercedes-Benz S-class Cabriolet (A217, facelift 2017) Cabriolet 2017 S 560 (469 Hp) G-TRONIC? | Rear wheel drive. Internal Combustion engine. The Internal combustion engine (ICE) drives the rear wheels of the vehicle. |
| How long is this vehicle, 2017 Mercedes-Benz S-class Cabriolet? | 5032 mm 198.11 in. |
| How wide is the vehicle, 2017 Mercedes-Benz S-class Cabriolet? | 1899 mm 74.76 in. |
| What is the curb weight, 2017 Mercedes-Benz S-class Cabriolet (A217, facelift 2017) S 560 (469 Hp) G-TRONIC? | 2075 kg 4574.59 lbs. |
| What is the gross weight, 2017 Mercedes-Benz S-class Cabriolet (A217, facelift 2017) S 560 (469 Hp) G-TRONIC? | 2625 kg 5787.13 lbs. |
| How much trunk (boot) space, 2017 Mercedes-Benz S-class Cabriolet? | 350 l 12.36 cu. ft. |
| How many gears, What type is the gearbox, 2017 Mercedes-Benz S-class Cabriolet (A217, facelift 2017) S 560 (469 Hp) G-TRONIC? | 9, automatic transmission G-TRONIC |
