| General information | |
|---|---|
| Brand | Mercedes-Benz |
| Model | S-class |
| Generation | S-class Long (V223) |
| Type (Engine) | AMG S 63 E PERFORMANCE V8 (802 Hp) Plug-in Hybrid 4MATIC+ AMG SPEEDSHIFT MCT 9G |
| Start of production | December, 2022 year |
| End of production | 2026 year |
| Powertrain Architecture | PHEV (Plug-in Hybrid Electric Vehicle) |
| Body type | Sedan |
| Seats | 4 |
| Doors | 4 |
| Performance specs | |
| Combined fuel consumption (WLTP) | 4.4 l/100 km 53.5 US mpg 64.2 UK mpg 22.7 km/l |
| CO2 emissions (WLTP) | 100 g/km |
| Fuel Type | Petrol / electricity |
| Acceleration 0 – 100 km/h | 3.3 sec |
| Acceleration 0 – 62 mph | 3.3 sec |
| Acceleration 0 – 60 mph (Calculated by Auto-Data.net) | 3.1 sec |
| Maximum speed | 250 km/h, Electronically limited 155.34 mph |
| Weight-to-power ratio | 3.1 kg/Hp, 318.3 Hp/tonne |
| Weight-to-torque ratio | 1.8 kg/Nm, 567.5 Nm/tonne |
| Electric cars and hybrids specs | |
| Gross battery capacity | 13.1 kWh |
| Battery voltage | 400 V |
| Battery technology | Lithium-ion (Li-Ion) |
| Battery location | Under the trunk |
| All-electric range (WLTP) | 33 km 20.51 mi |
| Average Energy consumption (WLTP) | 21.4 kWh/100 km
34.44 kWh/100 mi |
| Max speed (electric) | 140 km/h
86.99 mph |
| Charging ports |  Log in to see. |
| Electric motor 1 | |
| Electric motor power | 190 Hp |
| Electric motor Torque | 320 Nm
236.02 lb.-ft. |
| Maximum revolutions of the electric motor | 13500 rpm. |
| Electric motor location | Rear axle, Transverse |
| Electric motor type | Synchronous |
| System power | 802 Hp |
| System torque | 1430 Nm 1054.71 lb.-ft. |
| Internal combustion engine specs | |
| Power | 612 Hp @ 5500-6500 rpm. |
| Power per litre | 153.7 Hp/l |
| Torque | 900 Nm @ 2500-4500 rpm. 663.81 lb.-ft. @ 2500-4500 rpm. |
| Engine layout | Front, Longitudinal |
| Engine Model/Code | M 177 |
| Engine displacement | 3982 cm3 243 cu. in. |
| Number of cylinders | 8 |
| Engine configuration | V-engine |
| Cylinder Bore | 83 mm 3.27 in. |
| Piston Stroke | 92 mm 3.62 in. |
| Compression ratio | 8.6:1 |
| Number of valves per cylinder | 4 |
| Fuel injection system | Direct injection |
| Engine aspiration | 2 x Twin-scroll turbo, Intercooler |
| Valvetrain | DOHC |
| Engine oil specification | Log in to see. |
| Engine systems | Start & Stop System Cylinder deactivation system Particulate filter |
|
|
|
| Space, Volume and weights | |
| Kerb Weight | 2520 kg 5555.65 lbs. |
| Trunk (boot) space – minimum | 305 l 10.77 cu. ft. |
| Fuel tank capacity | 76 l 20.08 US gal | 16.72 UK gal |
| Dimensions | |
| Length | 5336 mm 210.08 in. |
| Width | 1921 mm 75.63 in. |
| Height | 1515 mm 59.65 in. |
| Wheelbase | 3216 mm 126.61 in. |
| Front track | 1671 mm 65.79 in. |
| Rear (Back) track | 1642 mm 64.65 in. |
| Minimum turning circle (turning diameter) | 12.3 m 40.35 ft. |
| Drivetrain, brakes and suspension specs | |
| Drivetrain Architecture | The Internal combustion engine (ICE) and the electric motor permanently drive the rear wheels of the vehicle, capable of running in full electric or mixed mode, and if necessary through the electrically or mechanically controlled clutch, the front wheels are driven. |
| Drive wheel | All wheel drive (4×4) |
| Number of gears and type of gearbox | 9 gears, automatic transmission AMG SPEEDSHIFT MCT |
| Front suspension | Independent multi-link suspension, Air suspension |
| Rear suspension | Independent multi-link suspension, Air suspension |
| Front brakes | Ventilated discs, 400×38 mm |
| Rear brakes | Ventilated discs, 380×32 mm |
| Assisting systems | ABS (Anti-lock braking system) 4-wheel steering (4WS, active rear steering) |
| Steering type | Steering rack and pinion |
| Power steering | Electric Steering |
| Tires size | Front wheel tires: 255/45 R20 Rear wheel tires: 285/40 R20 |
| Wheel rims size | Front wheel rims: 9.5J x 20 Rear wheel rims: 10.5J x 20 |
| What is the body type, Mercedes-Benz S-class Long (V223)? | Sedan, 4 Doors, 4 Seats |
|---|---|
| What is the fuel economy, Mercedes-Benz S-class Long (V223) AMG S 63 E PERFORMANCE V8 (802 Hp) Plug-in Hybrid 4MATIC+ AMG SPEEDSHIFT MCT 9G? | 4.4 l/100 km 53.5 US mpg 64.2 UK mpg 22.7 km/l |
| How ECO is the car, Mercedes-Benz S-class AMG S 63 E PERFORMANCE V8 (802 Hp) Plug-in Hybrid 4MATIC+ AMG SPEEDSHIFT MCT 9G? | 100 g/km CO2 |
| What is the range of pure electric driving, AMG S 63 E PERFORMANCE V8 (802 Hp) Plug-in Hybrid 4MATIC+ AMG SPEEDSHIFT MCT 9G? | 33 km 20.51 mi |
| What is electricity consumption, Mercedes-Benz S-class Long (V223) AMG S 63 E PERFORMANCE V8 (802 Hp) Plug-in Hybrid 4MATIC+ AMG SPEEDSHIFT MCT 9G? | 21.4 kWh/100 km 34.44 kWh/100 mi 98 MPGe 4.7 km/kWh 2.9 mi/kWh |
| How fast is the car, 2022 S-class Long (V223) AMG S 63 E PERFORMANCE V8 (802 Hp) Plug-in Hybrid 4MATIC+ AMG SPEEDSHIFT MCT 9G? | 250 km/h | 155.34 mph 0-100 km/h: 3.3 sec 0-60 mph: 3.1 sec |
| How much power, Mercedes-Benz S-class Sedan 2022 AMG S 63 E PERFORMANCE V8 (802 Hp) Plug-in Hybrid 4MATIC+ AMG SPEEDSHIFT MCT 9G? | 802 Hp, 1430 Nm 1054.71 lb.-ft. |
| What is the engine size, Mercedes-Benz S-class Sedan 2022 AMG S 63 E PERFORMANCE V8 (802 Hp) Plug-in Hybrid 4MATIC+ AMG SPEEDSHIFT MCT 9G? | 4.0 l 3982 cm3 243 cu. in. |
| How many cylinders, 2022 Mercedes-Benz AMG S 63 E PERFORMANCE V8 (802 Hp) Plug-in Hybrid 4MATIC+ AMG SPEEDSHIFT MCT 9G? | 8, V-engine |
| What is the drivetrain, Mercedes-Benz S-class Long (V223) Sedan 2022 AMG S 63 E PERFORMANCE V8 (802 Hp) Plug-in Hybrid 4MATIC+ AMG SPEEDSHIFT MCT 9G? | All wheel drive (4×4). PHEV (Plug-in Hybrid Electric Vehicle). The Internal combustion engine (ICE) and the electric motor permanently drive the rear wheels of the vehicle, capable of running in full electric or mixed mode, and if necessary through the electrically or mechanically controlled clutch, the front wheels are driven. |
| How long is this vehicle, 2022 Mercedes-Benz S-class Sedan? | 5336 mm 210.08 in. |
| How wide is the vehicle, 2022 Mercedes-Benz S-class Sedan? | 1921 mm 75.63 in. |
| What is the curb weight, 2022 Mercedes-Benz S-class Long (V223) AMG S 63 E PERFORMANCE V8 (802 Hp) Plug-in Hybrid 4MATIC+ AMG SPEEDSHIFT MCT 9G? | 2520 kg 5555.65 lbs. |
| How much trunk (boot) space, 2022 Mercedes-Benz S-class Sedan? | 305 l 10.77 cu. ft. |
| How many gears, What type is the gearbox, 2022 Mercedes-Benz S-class Long (V223) AMG S 63 E PERFORMANCE V8 (802 Hp) Plug-in Hybrid 4MATIC+ AMG SPEEDSHIFT MCT 9G? | 9, automatic transmission AMG SPEEDSHIFT MCT |
