| General information | |
|---|---|
| Brand | Mercedes-Benz |
| Model | W124 |
| Generation | S124 |
| Type (Engine) | 200 T (109 Hp) |
| Start of production | March, 1985 year |
| End of production | September, 1986 year |
| Powertrain Architecture | Internal Combustion engine |
| Body type | Station wagon (estate) |
| Seats | 5 |
| Doors | 5 |
| Performance specs | |
| Fuel consumption (economy) – urban | 12.1 l/100 km 19.4 US mpg 23.3 UK mpg 8.3 km/l |
| Fuel consumption (economy) – extra urban | 7.3 l/100 km 32.2 US mpg 38.7 UK mpg 13.7 km/l |
| Fuel Type | Petrol (Gasoline) |
| Acceleration 0 – 100 km/h | 13.6 sec |
| Acceleration 0 – 62 mph | 13.6 sec |
| Acceleration 0 – 60 mph (Calculated by Auto-Data.net) | 12.9 sec |
| Maximum speed | 175 km/h 108.74 mph |
| Weight-to-power ratio | 12.8 kg/Hp, 78.4 Hp/tonne |
| Weight-to-torque ratio | 8.2 kg/Nm, 122.3 Nm/tonne |
| Engine specs | |
| Power | 109 Hp @ 5200 rpm. |
| Power per litre | 54.6 Hp/l |
| Torque | 170 Nm @ 2500 rpm. 125.39 lb.-ft. @ 2500 rpm. |
| Engine layout | Front, Longitudinal |
| Engine Model/Code | M 102 V 20 / 102.922 |
| Engine displacement | 1997 cm3 121.86 cu. in. |
| Number of cylinders | 4 |
| Engine configuration | Inline |
| Cylinder Bore | 89 mm 3.5 in. |
| Piston Stroke | 80.25 mm 3.16 in. |
| Compression ratio | 9.1:1 |
| Number of valves per cylinder | 2 |
| Fuel injection system | Carburettor |
| Engine aspiration | Naturally aspirated engine |
| Valvetrain | SOHC |
| Engine oil capacity | 5 l 5.28 US qt | 4.4 UK qt |
| Engine oil specification |  Log in to see. |
| Coolant | 8.5 l 8.98 US qt | 7.48 UK qt |
|
|
|
| Space, Volume and weights | |
| Kerb Weight | 1390 kg 3064.43 lbs. |
| Max. weight | 2010 kg 4431.29 lbs. |
| Max load | 620 kg 1366.87 lbs. |
| Fuel tank capacity | 72 l 19.02 US gal | 15.84 UK gal |
| Dimensions | |
| Length | 4765 mm 187.6 in. |
| Width | 1740 mm 68.5 in. |
| Height | 1490 mm 58.66 in. |
| Wheelbase | 2800 mm 110.24 in. |
| Front track | 1497 mm 58.94 in. |
| Rear (Back) track | 1488 mm 58.58 in. |
| Drivetrain, brakes and suspension specs | |
| Drivetrain Architecture | The Internal combustion engine (ICE) drives the rear wheels of the vehicle. |
| Drive wheel | Rear wheel drive |
| Number of gears and type of gearbox | 4 gears, manual transmission |
| Front suspension | Wishbone |
| Rear suspension | Independent multi-link suspension |
| Front brakes | Disc |
| Rear brakes | Disc |
| Steering type | Cone worm with recirculation balls |
| Power steering | Hydraulic Steering |
| Tires size | Front wheel tires: 195/65 R15 Rear wheel tires: 195/65 R15 |
| Wheel rims size | Front wheel rims: 6.5J x 15 Rear wheel rims: 6.5J x 15 |
| What is the body type, Mercedes-Benz S124? | Station wagon (estate), 5 Doors, 5 Seats |
|---|---|
| How fast is the car, 1985 S124 200 T (109 Hp)? | 175 km/h | 108.74 mph 0-100 km/h: 13.6 sec 0-60 mph: 12.9 sec |
| How much power, Mercedes-Benz W124 Station wagon (estate) 1985 200 T (109 Hp)? | 109 Hp, 170 Nm 125.39 lb.-ft. |
| What is the engine size, Mercedes-Benz W124 Station wagon (estate) 1985 200 T (109 Hp)? | 2.0 l 1997 cm3 121.86 cu. in. |
| How many cylinders, 1985 Mercedes-Benz 200 T (109 Hp)? | 4, Inline |
| What is the drivetrain, Mercedes-Benz S124 Station wagon (estate) 1985 200 T (109 Hp)? | Rear wheel drive. Internal Combustion engine. The Internal combustion engine (ICE) drives the rear wheels of the vehicle. |
| How long is this vehicle, 1985 Mercedes-Benz W124 Station wagon (estate)? | 4765 mm 187.6 in. |
| How wide is the vehicle, 1985 Mercedes-Benz W124 Station wagon (estate)? | 1740 mm 68.5 in. |
| What is the curb weight, 1985 Mercedes-Benz S124 200 T (109 Hp)? | 1390 kg 3064.43 lbs. |
| What is the gross weight, 1985 Mercedes-Benz S124 200 T (109 Hp)? | 2010 kg 4431.29 lbs. |
| How many gears, What type is the gearbox, 1985 Mercedes-Benz S124 200 T (109 Hp)? | 4, manual transmission |
