| General information | |
|---|---|
| Brand | Mercedes-Benz |
| Model | Vaneo |
| Generation | Vaneo (W414) |
| Type (Engine) | 1.6i (102 Hp) Automatic |
| Start of production | 2001 year |
| End of production | 2005 year |
| Powertrain Architecture | Internal Combustion engine |
| Body type | Minivan |
| Seats | 5 |
| Doors | 5 |
| Performance specs | |
| Fuel consumption (economy) – urban | 11.1 l/100 km 21.2 US mpg 25.4 UK mpg 9 km/l |
| Fuel consumption (economy) – extra urban | 6.6 l/100 km 35.6 US mpg 42.8 UK mpg 15.2 km/l |
| Fuel consumption (economy) – combined | 8.3 l/100 km 28.3 US mpg 34 UK mpg 12 km/l |
| Fuel Type | Petrol (Gasoline) |
| Acceleration 0 – 100 km/h | 14.3 sec |
| Acceleration 0 – 62 mph | 14.3 sec |
| Acceleration 0 – 60 mph (Calculated by Auto-Data.net) | 13.6 sec |
| Maximum speed | 163 km/h 101.28 mph |
| Weight-to-power ratio | 12.6 kg/Hp, 79.1 Hp/tonne |
| Weight-to-torque ratio | 8.6 kg/Nm, 116.3 Nm/tonne |
| Engine specs | |
| Power | 102 Hp @ 5250 rpm. |
| Power per litre | 63.8 Hp/l |
| Torque | 150 Nm @ 4000 rpm. 110.63 lb.-ft. @ 4000 rpm. |
| Engine layout | Front, Transverse |
| Engine Model/Code | M 166 E 16/166.960 |
| Engine displacement | 1598 cm3 97.52 cu. in. |
| Number of cylinders | 4 |
| Engine configuration | Inline |
| Cylinder Bore | 80 mm 3.15 in. |
| Piston Stroke | 79.5 mm 3.13 in. |
| Compression ratio | 11:1 |
| Number of valves per cylinder | 2 |
| Fuel injection system | Multi-port manifold injection |
| Engine aspiration | Naturally aspirated engine |
| Valvetrain | OHC |
| Engine oil capacity | 5 l 5.28 US qt | 4.4 UK qt |
| Engine oil specification |  Log in to see. |
| Coolant | 6 l 6.34 US qt | 5.28 UK qt |
|
|
|
| Space, Volume and weights | |
| Kerb Weight | 1290 kg 2843.96 lbs. |
| Max. weight | 1910 kg 4210.83 lbs. |
| Max load | 620 kg 1366.87 lbs. |
| Trunk (boot) space – minimum | 150 l 5.3 cu. ft. |
| Trunk (boot) space – maximum | 3000 l 105.94 cu. ft. |
| Fuel tank capacity | 54 l 14.27 US gal | 11.88 UK gal |
| Dimensions | |
| Length | 4190 mm 164.96 in. |
| Width | 1740 mm 68.5 in. |
| Height | 1830 mm 72.05 in. |
| Wheelbase | 2900 mm 114.17 in. |
| Front track | 1525 mm 60.04 in. |
| Rear (Back) track | 1475 mm 58.07 in. |
| Drivetrain, brakes and suspension specs | |
| Drivetrain Architecture | The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
| Drive wheel | Front wheel drive |
| Number of gears and type of gearbox | 5 gears, automatic transmission |
| Front suspension | Spring Strut |
| Rear suspension | Coil spring |
| Front brakes | Ventilated discs |
| Rear brakes | Disc |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Power steering | Hydraulic Steering |
| Tires size | 185/60 R15 |
| Wheel rims size | 15 |
| What is the body type, Mercedes-Benz Vaneo (W414)? | Minivan, 5 Doors, 5 Seats |
|---|---|
| What is the fuel economy, Mercedes-Benz Vaneo (W414) 1.6i (102 Hp) Automatic? | 8.3 l/100 km 28.3 US mpg 34 UK mpg 12 km/l |
| How fast is the car, 2001 Vaneo (W414) 1.6i (102 Hp) Automatic? | 163 km/h | 101.28 mph 0-100 km/h: 14.3 sec 0-60 mph: 13.6 sec |
| How much power, Mercedes-Benz Vaneo Minivan 2001 1.6i (102 Hp) Automatic? | 102 Hp, 150 Nm 110.63 lb.-ft. |
| What is the engine size, Mercedes-Benz Vaneo Minivan 2001 1.6i (102 Hp) Automatic? | 1.6 l 1598 cm3 97.52 cu. in. |
| How many cylinders, 2001 Mercedes-Benz 1.6i (102 Hp) Automatic? | 4, Inline |
| What is the drivetrain, Mercedes-Benz Vaneo (W414) Minivan 2001 1.6i (102 Hp) Automatic? | Front wheel drive. Internal Combustion engine. The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
| How long is this vehicle, 2001 Mercedes-Benz Vaneo Minivan? | 4190 mm 164.96 in. |
| How wide is the vehicle, 2001 Mercedes-Benz Vaneo Minivan? | 1740 mm 68.5 in. |
| What is the curb weight, 2001 Mercedes-Benz Vaneo (W414) 1.6i (102 Hp) Automatic? | 1290 kg 2843.96 lbs. |
| What is the gross weight, 2001 Mercedes-Benz Vaneo (W414) 1.6i (102 Hp) Automatic? | 1910 kg 4210.83 lbs. |
| How much trunk (boot) space, 2001 Mercedes-Benz Vaneo Minivan? | 150 – 3000 l 5.3 – 105.94 cu. ft. |
| How many gears, What type is the gearbox, 2001 Mercedes-Benz Vaneo (W414) 1.6i (102 Hp) Automatic? | 5, automatic transmission |
