| General information | |
|---|---|
| Brand | Mitsubishi |
| Model | Eclipse Cross |
| Generation | Eclipse Cross I (facelift 2021) |
| Type (Engine) | 1.5 MIVEC (152 Hp) CVT |
| Start of production | 2021 year |
| Powertrain Architecture | Internal Combustion engine |
| Body type | SUV |
| Seats | 5 |
| Doors | 5 |
| Performance specs | |
| Fuel Type | Petrol (Gasoline) |
| Emission standard | TIER 3-BIN 70 (50S) LEV III – |
| Weight-to-power ratio | 9.8 kg/Hp, 102 Hp/tonne |
| Weight-to-torque ratio | 6 kg/Nm, 167.1 Nm/tonne |
| Engine specs | |
| Power | 152 Hp @ 5500 rpm. |
| Power per litre | 101.4 Hp/l |
| Torque | 249 Nm @ 2000-3500 rpm. 183.65 lb.-ft. @ 2000-3500 rpm. |
| Maximum engine speed | 6000 rpm. |
| Engine layout | Front, Transverse |
| Engine Model/Code | 4B40 |
| Engine displacement | 1499 cm3 91.47 cu. in. |
| Number of cylinders | 4 |
| Engine configuration | Inline |
| Cylinder Bore | 75 mm 2.95 in. |
| Piston Stroke | 84.8 mm 3.34 in. |
| Compression ratio | 10:1 |
| Number of valves per cylinder | 4 |
| Fuel injection system | Direct injection |
| Engine aspiration | Turbocharger, Intercooler |
| Valvetrain | DOHC |
| Engine oil capacity | 4.3 l 4.54 US qt | 3.78 UK qt |
| Engine oil specification |  Log in to see. |
| Coolant | 6 l 6.34 US qt | 5.28 UK qt |
| Engine systems | Start & Stop System |
|
|
|
| Space, Volume and weights | |
| Kerb Weight | 1490-1525 kg 3284.89 – 3362.05 lbs. |
| Max. weight | 2100 kg 4629.71 lbs. |
| Max load | 575-610 kg 1267.66 – 1344.82 lbs. |
| Trunk (boot) space – minimum | 657-663 l 23.2 – 23.41 cu. ft. |
| Trunk (boot) space – maximum | 1419 l 50.11 cu. ft. |
| Fuel tank capacity | 63 l 16.64 US gal | 13.86 UK gal |
| Permitted trailer load with brakes (12%) | 680 kg 1499.14 lbs. |
| Permitted towbar download | 68 kg 149.91 lbs. |
| Dimensions | |
| Length | 4547 mm 179.02 in. |
| Width | 1806 mm 71.1 in. |
| Height | 1684 mm 66.3 in. |
| Wheelbase | 2670 mm 105.12 in. |
| Front track | 1544 mm 60.79 in. |
| Rear (Back) track | 1544 mm 60.79 in. |
| Ride height (ground clearance) | 203 mm 7.99 in. |
| Minimum turning circle (turning diameter) | 10.7 m 35.1 ft. |
| Drivetrain, brakes and suspension specs | |
| Drivetrain Architecture | The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
| Drive wheel | Front wheel drive |
| Number of gears and type of gearbox | 8 gears, automatic transmission CVT |
| Front suspension | Independent, type McPherson with coil spring and anti-roll bar |
| Rear suspension | Independent multi-link spring suspension with stabilizer |
| Front brakes | Ventilated discs, 294.64 mm |
| Rear brakes | Disc, 302.26 mm |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Power steering | Electric Steering |
| Tires size | 215/70 R16; 225/55 R18 |
| Wheel rims size | 6.5J x 16; 7J x 18 |
| What is the body type, Mitsubishi Eclipse Cross I (facelift 2021)? | SUV, 5 Doors, 5 Seats |
|---|---|
| How ECO is the car, Mitsubishi Eclipse Cross 1.5 MIVEC (152 Hp) CVT? | TIER 3-BIN 70 (50S) LEV III – |
| How much power, Mitsubishi Eclipse Cross SUV 2021 1.5 MIVEC (152 Hp) CVT? | 152 Hp, 249 Nm 183.65 lb.-ft. |
| What is the engine size, Mitsubishi Eclipse Cross SUV 2021 1.5 MIVEC (152 Hp) CVT? | 1.5 l 1499 cm3 91.47 cu. in. |
| How many cylinders, 2021 Mitsubishi 1.5 MIVEC (152 Hp) CVT? | 4, Inline |
| What is the drivetrain, Mitsubishi Eclipse Cross I (facelift 2021) SUV 2021 1.5 MIVEC (152 Hp) CVT? | Front wheel drive. Internal Combustion engine. The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
| How long is this vehicle, 2021 Mitsubishi Eclipse Cross SUV? | 4547 mm 179.02 in. |
| How wide is the vehicle, 2021 Mitsubishi Eclipse Cross SUV? | 1806 mm 71.1 in. |
| What is the curb weight, 2021 Mitsubishi Eclipse Cross I (facelift 2021) 1.5 MIVEC (152 Hp) CVT? | 1490-1525 kg 3284.89 – 3362.05 lbs. |
| What is the gross weight, 2021 Mitsubishi Eclipse Cross I (facelift 2021) 1.5 MIVEC (152 Hp) CVT? | 2100 kg 4629.71 lbs. |
| How much trunk (boot) space, 2021 Mitsubishi Eclipse Cross SUV? | 657 – 1419 l 23.2 – 50.11 cu. ft. |
| How many gears, What type is the gearbox, 2021 Mitsubishi Eclipse Cross I (facelift 2021) 1.5 MIVEC (152 Hp) CVT? | 8, automatic transmission CVT |
