The Nissan Armada III (Y63), launched in September 2024, represents the latest iteration of Nissan’s full-size SUV, primarily aimed at the North American market. Building upon the foundation of the Nissan Patrol, the Armada offers a blend of robust capability, spaciousness, and modern technology. The 3.5 V6 4WD Automatic variant positions itself as the flagship trim, offering a significant power upgrade and standard four-wheel drive for enhanced all-weather and off-road performance. This model year marks a substantial refresh for the Armada, focusing on powertrain improvements and interior refinements to remain competitive in the large SUV segment.
Technical Specifications
| Brand | Nissan |
| Model | Armada |
| Generation | Armada III (Y63) |
| Type (Engine) | 3.5 V6 (425 Hp) 4WD Automatic |
| Start of production | September, 2024 |
| Powertrain Architecture | Internal Combustion engine |
| Body type | SUV |
| Seats | 7-8 |
| Doors | 5 |
| Fuel Type | Petrol (Gasoline) |
| Emission standard | LEV4-ULEV50 |
| Weight-to-power ratio | 6.3 kg/Hp, 159.6 Hp/tonne |
| Weight-to-torque ratio | 3.8 kg/Nm, 262.9 Nm/tonne |
| Power | 425 Hp @ 5600 rpm |
| Power per litre | 121.7 Hp/l |
| Torque | 700 Nm @ 3600 rpm, 516.29 lb.-ft. @ 3600 rpm |
| Maximum engine speed | 6000 rpm |
| Engine layout | Front, Longitudinal |
| Engine Model/Code | VR35DDTT |
| Engine displacement | 3492 cm3, 213.09 cu. in. |
| Number of cylinders | 6 |
| Engine configuration | V-engine |
| Cylinder Bore | 86 mm, 3.39 in. |
| Piston Stroke | 100.2 mm, 3.94 in. |
| Compression ratio | 10.5:1 |
| Number of valves per cylinder | 4 |
| Fuel injection system | Direct injection |
| Engine aspiration | Twin-Turbo, Intercooler |
| Valvetrain | DOHC, CVTCS |
| Engine oil capacity | 5.7 l, 6.02 US qt | 5.02 UK qt |
| Kerb Weight | 2663-2772 kg, 5870.91 – 6111.21 lbs. |
| Max. weight | 3542 kg, 7808.77 lbs. |
| Max load | 770-879 kg, 1697.56 – 1937.86 lbs. |
| Trunk (boot) space – minimum | 578 l, 20.41 cu. ft. |
| Trunk (boot) space – maximum | 2750 l, 97.12 cu. ft. |
| Fuel tank capacity | 89 l, 23.51 US gal | 19.58 UK gal |
| Permitted trailer load with brakes (12%) | 3856 kg, 8501.02 lbs. |
| Permitted towbar download | 386 kg, 850.98 lbs. |
| Length | 5324 mm, 209.61 in. |
| Width with mirrors folded | 2116 mm, 83.31 in. |
| Width including mirrors | 2350 mm, 92.52 in. |
| Height | 1946-1981 mm, 76.61 – 77.99 in. |
| Wheelbase | 3076 mm, 121.1 in. |
| Ride height (ground clearance) | 244-251 mm, 9.61 – 9.88 in. |
| Approach angle | 16.5-17.3° |
| Departure angle | 21.9-22.3° |
| Ramp-over (brakeover) angle | 21.6-22.9° |
| Drivetrain Architecture | The Internal combustion engine (ICE) drives permanently the four wheels of the vehicle. |
| Drive wheel | All wheel drive (4×4) |
| Number of gears and type of gearbox | 9 gears, automatic transmission |
| Front suspension | Double wishbone, Independent coil spring, Air Suspension – Optional |
| Rear suspension | Double wishbone, Independent coil spring, Air Suspension – Optional |
| Front brakes | Ventilated discs, 350×30 mm |
| Rear brakes | Ventilated discs, 350×20 mm |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Power steering | Electric Steering |
| Tires size | 265/70 R18; 275/60 R20; 275/50 R22 |
| Wheel rims size | 18; 20; 22 |
Powertrain & Engine Architecture
The heart of the Armada III (Y63) 3.5 V6 4WD Automatic is the VR35DDTT 3.5-liter V6 engine. This engine is a significant upgrade from previous Armada generations, featuring direct injection and twin-turbocharging. The twin-turbo setup utilizes electronically controlled wastegates to optimize boost pressure and responsiveness. The engine produces 425 horsepower at 5600 rpm and 700 Nm (516.29 lb.-ft.) of torque at 3600 rpm. The engine employs a double overhead camshaft (DOHC) valvetrain with Continuously Variable Valve Timing Control System (CVTCS) for improved efficiency and performance across the rev range. The engine is longitudinally mounted, contributing to a balanced weight distribution. The engine is paired with a sophisticated 9-speed automatic transmission, designed to provide smooth and efficient gear changes. This transmission features adaptive shift logic, adjusting to driving conditions and driver input.
Driving Characteristics
The 3.5 V6 powertrain delivers a substantial improvement in performance compared to earlier Armada models. The twin-turbocharging provides strong acceleration, making highway merging and overtaking effortless. While not a sports car, the Armada offers a confident and composed driving experience. The 9-speed automatic transmission is well-tuned, providing smooth shifts and keeping the engine in its optimal power band. The four-wheel-drive system enhances traction in various conditions, making it a capable vehicle for inclement weather and light off-roading. Compared to lower-trim Armada variants with less powerful engines, the 3.5 V6 offers a more refined and responsive driving experience. The increased torque is particularly noticeable when towing or carrying a full load.
Equipment & Trim Levels
The 3.5 V6 4WD Automatic trim typically represents the highest level of equipment offered on the Armada. Standard features generally include leather upholstery, heated and ventilated front seats, a premium audio system, a large touchscreen infotainment system with navigation, and a suite of advanced driver-assistance systems (ADAS) such as adaptive cruise control, lane departure warning, and automatic emergency braking. Optional extras often include a rear-seat entertainment system, a panoramic sunroof, and upgraded interior trim materials. The interior design emphasizes comfort and spaciousness, with ample room for passengers and cargo.
Chassis & Braking
The Armada III (Y63) utilizes a robust body-on-frame construction, providing a solid and durable platform. The suspension system consists of double wishbones at both the front and rear, with optional air suspension available on higher trims. The air suspension allows for adjustable ride height and improved ride comfort. Braking duties are handled by ventilated discs at all four corners, providing ample stopping power. The braking system is augmented by ABS (Anti-lock Braking System) and electronic brake-force distribution. Steering is rack-and-pinion with electric power assistance, offering precise and responsive handling.
Market Reception & Comparison
The Nissan Armada III (Y63) 3.5 V6 4WD Automatic has been generally well-received by automotive critics. Praise has been directed towards its powerful engine, spacious interior, and comfortable ride. However, some critics have noted its relatively low fuel economy compared to some competitors. Compared to other large SUVs such as the Chevrolet Tahoe, Ford Expedition, and Toyota Sequoia, the Armada offers a competitive combination of features, performance, and value. Its towing capacity and off-road capability are also strong points.
Legacy
The VR35DDTT engine has proven to be a reliable and durable powertrain in other Nissan and Infiniti vehicles. While long-term reliability data for the Armada III (Y63) is still emerging, the engine’s established track record suggests it should provide years of dependable service. The Armada’s body-on-frame construction and robust components contribute to its potential longevity. On the used car market, the 3.5 V6 4WD Automatic trim is expected to hold its value well due to its desirable features and strong performance. The Armada continues to be a popular choice for buyers seeking a large, capable, and comfortable SUV.
