| General information | |
|---|---|
| Brand | Nissan |
| Model | Patrol |
| Generation | Patrol V 5-door (Y61, facelift 2004) |
| Type (Engine) | 3.0 Di (160 Hp) 4×4 |
| Start of production | 2004 year |
| End of production | 2016 year |
| Powertrain Architecture | Internal Combustion engine |
| Body type | Off-road vehicle |
| Seats | 7 |
| Doors | 5 |
| Performance specs | |
| Fuel consumption (economy) – urban (NEDC) | 14.3 l/100 km 16.4 US mpg 19.8 UK mpg 7 km/l |
| Fuel consumption (economy) – extra urban (NEDC) | 8.8 l/100 km 26.7 US mpg 32.1 UK mpg 11.4 km/l |
| Fuel consumption (economy) – combined (NEDC) | 10.8 l/100 km 21.8 US mpg 26.2 UK mpg 9.3 km/l |
| CO2 emissions (NEDC) | 288 g/km |
| Fuel Type | Diesel |
| Acceleration 0 – 100 km/h | 15.2 sec |
| Acceleration 0 – 62 mph | 15.2 sec |
| Acceleration 0 – 60 mph (Calculated by Auto-Data.net) | 14.4 sec |
| Maximum speed | 160 km/h 99.42 mph |
| Emission standard | Euro 3 |
| Weight-to-power ratio | 14.8 kg/Hp, 67.7 Hp/tonne |
| Weight-to-torque ratio | 6.2 kg/Nm, 160.7 Nm/tonne |
| Engine specs | |
| Power | 160 Hp @ 3600 rpm. |
| Power per litre | 54.2 Hp/l |
| Torque | 380 Nm @ 2000 rpm. 280.27 lb.-ft. @ 2000 rpm. |
| Engine layout | Front, Longitudinal |
| Engine Model/Code | ZD30DDTi |
| Engine displacement | 2953 cm3 180.2 cu. in. |
| Number of cylinders | 4 |
| Engine configuration | Inline |
| Cylinder Bore | 96 mm 3.78 in. |
| Piston Stroke | 102 mm 4.02 in. |
| Compression ratio | 17.9:1 |
| Number of valves per cylinder | 4 |
| Fuel injection system | Diesel Commonrail |
| Engine aspiration | Turbocharger, Intercooler |
| Valvetrain | DOHC |
| Engine oil capacity | 8.2 l 8.66 US qt | 7.21 UK qt |
| Engine oil specification |  Log in to see. |
| Coolant | 12 l 12.68 US qt | 10.56 UK qt |
|
|
|
| Space, Volume and weights | |
| Kerb Weight | 2365-2545 kg 5213.93 – 5610.76 lbs. |
| Max. weight | 3200 kg 7054.79 lbs. |
| Max load | 655-835 kg 1444.03 – 1840.86 lbs. |
| Trunk (boot) space – minimum | 183 l 6.46 cu. ft. |
| Trunk (boot) space – maximum | 2226 l 78.61 cu. ft. |
| Fuel tank capacity | 95 l 25.1 US gal | 20.9 UK gal |
| Max. roof load | 100 kg 220.46 lbs. |
| Permitted trailer load with brakes (12%) | 3500 kg 7716.18 lbs. |
| Permitted trailer load without brakes | 750 kg 1653.47 lbs. |
| Permitted towbar download | 140 kg 308.65 lbs. |
| Dimensions | |
| Length | 5045 mm 198.62 in. |
| Width | 1840 mm 72.44 in. |
| Height | 1855 mm 73.03 in. |
| Wheelbase | 2970 mm 116.93 in. |
| Front track | 1555-1605 mm 61.22 – 63.19 in. |
| Rear (Back) track | 1575-1625 mm 62.01 – 63.98 in. |
| Front overhang | 955 mm 37.6 in. |
| Rear overhang | 1120 mm 44.09 in. |
| Ride height (ground clearance) | 220 mm 8.66 in. |
| Minimum turning circle (turning diameter) | 12.2 m 40.03 ft. |
| Approach angle | 37° |
| Departure angle | 31° |
| Ramp-over (brakeover) angle | 27° |
| Climb angle | 39° |
| Wading depth | 700 mm 27.56 in. |
| Drivetrain, brakes and suspension specs | |
| Drivetrain Architecture | The Internal combustion engine (ICE) drives the rear wheels permanently, and the front wheels are driven through an electrically or mechanically operated clutch if necessary. |
| Drive wheel | All wheel drive (4×4) |
| Number of gears and type of gearbox | 5 gears, manual transmission |
| Front suspension | Coil spring, Rigid axle suspension, Transverse stabilizer |
| Rear suspension | Rigid axle suspension, Transverse stabilizer, Coil spring |
| Front brakes | Ventilated discs |
| Rear brakes | Ventilated discs |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Cone worm with recirculation balls |
| Power steering | Hydraulic Steering |
| Tires size | 235/80 R16; 265/70 R16; 275/65 R17 |
| Wheel rims size | 6J x 16; 8J x 16; 8J x 17 |
| What is the body type, Nissan Patrol V 5-door (Y61, facelift 2004)? | Off-road vehicle, 5 Doors, 7 Seats |
|---|---|
| What is the fuel economy, Nissan Patrol V 5-door (Y61, facelift 2004) 3.0 Di (160 Hp) 4×4? | 10.8 l/100 km 21.8 US mpg 26.2 UK mpg 9.3 km/l |
| How ECO is the car, Nissan Patrol 3.0 Di (160 Hp) 4×4? | 288 g/km CO2 Euro 3 |
| How fast is the car, 2004 Patrol V 5-door (Y61, facelift 2004) 3.0 Di (160 Hp) 4×4? | 160 km/h | 99.42 mph 0-100 km/h: 15.2 sec 0-60 mph: 14.4 sec |
| How much power, Nissan Patrol Off-road vehicle 2004 3.0 Di (160 Hp) 4×4? | 160 Hp, 380 Nm 280.27 lb.-ft. |
| What is the engine size, Nissan Patrol Off-road vehicle 2004 3.0 Di (160 Hp) 4×4? | 3.0 l 2953 cm3 180.2 cu. in. |
| How many cylinders, 2004 Nissan 3.0 Di (160 Hp) 4×4? | 4, Inline |
| What is the drivetrain, Nissan Patrol V 5-door (Y61, facelift 2004) Off-road vehicle 2004 3.0 Di (160 Hp) 4×4? | All wheel drive (4×4). Internal Combustion engine. The Internal combustion engine (ICE) drives the rear wheels permanently, and the front wheels are driven through an electrically or mechanically operated clutch if necessary. |
| How long is this vehicle, 2004 Nissan Patrol Off-road vehicle? | 5045 mm 198.62 in. |
| How wide is the vehicle, 2004 Nissan Patrol Off-road vehicle? | 1840 mm 72.44 in. |
| What is the curb weight, 2004 Nissan Patrol V 5-door (Y61, facelift 2004) 3.0 Di (160 Hp) 4×4? | 2365-2545 kg 5213.93 – 5610.76 lbs. |
| What is the gross weight, 2004 Nissan Patrol V 5-door (Y61, facelift 2004) 3.0 Di (160 Hp) 4×4? | 3200 kg 7054.79 lbs. |
| How much trunk (boot) space, 2004 Nissan Patrol Off-road vehicle? | 183 – 2226 l 6.46 – 78.61 cu. ft. |
| How many gears, What type is the gearbox, 2004 Nissan Patrol V 5-door (Y61, facelift 2004) 3.0 Di (160 Hp) 4×4? | 5, manual transmission |
