| General information | |
|---|---|
| Brand | Opel |
| Model | Ascona |
| Generation | Ascona A Voyage |
| Type (Engine) | 1.6 N (68 Hp) |
| Start of production | November, 1970 year |
| End of production | December, 1974 year |
| Powertrain Architecture | Internal Combustion engine |
| Body type | Station wagon (estate) |
| Seats | 5 |
| Doors | 3 |
| Performance specs | |
| Fuel consumption (economy) – combined | 10.2 l/100 km 23.1 US mpg 27.7 UK mpg 9.8 km/l |
| Fuel Type | Petrol (Gasoline) |
| Acceleration 0 – 100 km/h | 20 sec |
| Acceleration 0 – 62 mph | 20 sec |
| Acceleration 0 – 60 mph (Calculated by Auto-Data.net) | 19 sec |
| Maximum speed | 145 km/h 90.1 mph |
| Weight-to-power ratio | 14.6 kg/Hp, 68.3 Hp/tonne |
| Weight-to-torque ratio | 9 kg/Nm, 110.6 Nm/tonne |
| Engine specs | |
| Power | 68 Hp @ 5200 rpm. |
| Power per litre | 42.9 Hp/l |
| Torque | 110 Nm @ 3400 rpm. 81.13 lb.-ft. @ 3400 rpm. |
| Engine layout | Front, Longitudinal |
| Engine Model/Code | 16N |
| Engine displacement | 1584 cm3 96.66 cu. in. |
| Number of cylinders | 4 |
| Engine configuration | Inline |
| Cylinder Bore | 85 mm 3.35 in. |
| Piston Stroke | 69.8 mm 2.75 in. |
| Compression ratio | 8.2:1 |
| Number of valves per cylinder | 2 |
| Fuel injection system | Carburettor |
| Engine aspiration | Naturally aspirated engine |
| Valvetrain | CIH |
| Engine oil capacity | 3.8 l 4.02 US qt | 3.34 UK qt |
| Engine oil specification |  Log in to see. |
| Coolant | 6.5 l 6.87 US qt | 5.72 UK qt |
|
|
|
| Space, Volume and weights | |
| Kerb Weight | 995 kg 2193.6 lbs. |
| Max. weight | 1505 kg 3317.96 lbs. |
| Max load | 510 kg 1124.36 lbs. |
| Fuel tank capacity | 46 l 12.15 US gal | 10.12 UK gal |
| Permitted trailer load with brakes (12%) | 1000 kg 2204.62 lbs. |
| Permitted trailer load without brakes | 500 kg 1102.31 lbs. |
| Dimensions | |
| Length | 4180 mm 164.57 in. |
| Width | 1632 mm 64.25 in. |
| Height | 1400 mm 55.12 in. |
| Wheelbase | 2430 mm 95.67 in. |
| Front track | 1331 mm 52.4 in. |
| Rear (Back) track | 1320 mm 51.97 in. |
| Ride height (ground clearance) | 134 mm 5.28 in. |
| Drag coefficient (Cd) | 0.50 |
| Minimum turning circle (turning diameter) | 9.76 m 32.02 ft. |
| Drivetrain, brakes and suspension specs | |
| Drivetrain Architecture | The Internal combustion engine (ICE) drives the rear wheels of the vehicle. |
| Drive wheel | Rear wheel drive |
| Number of gears and type of gearbox | 4 gears, manual transmission |
| Front suspension | Coil spring, Independent coil spring, Transverse stabilizer |
| Rear suspension | Rigid axle suspension, Transverse stabilizer, Trailing arm, Coil spring |
| Front brakes | Disc |
| Rear brakes | Drum |
| Steering type | Steering rack and pinion |
| Tires size | 155/80 R13; 165/80 R13; 185/70 R13 |
| Wheel rims size | 5J x 13; 5.5J x 13 |
| What is the body type, Opel Ascona A Voyage? | Station wagon (estate), 3 Doors, 5 Seats |
|---|---|
| What is the fuel economy, Opel Ascona A Voyage 1.6 N (68 Hp)? | 10.2 l/100 km 23.1 US mpg 27.7 UK mpg 9.8 km/l |
| How fast is the car, 1970 Ascona A Voyage 1.6 N (68 Hp)? | 145 km/h | 90.1 mph 0-100 km/h: 20 sec 0-60 mph: 19 sec |
| How much power, Opel Ascona Station wagon (estate) 1970 1.6 N (68 Hp)? | 68 Hp, 110 Nm 81.13 lb.-ft. |
| What is the engine size, Opel Ascona Station wagon (estate) 1970 1.6 N (68 Hp)? | 1.6 l 1584 cm3 96.66 cu. in. |
| How many cylinders, 1970 Opel 1.6 N (68 Hp)? | 4, Inline |
| What is the drivetrain, Opel Ascona A Voyage Station wagon (estate) 1970 1.6 N (68 Hp)? | Rear wheel drive. Internal Combustion engine. The Internal combustion engine (ICE) drives the rear wheels of the vehicle. |
| How long is this vehicle, 1970 Opel Ascona Station wagon (estate)? | 4180 mm 164.57 in. |
| How wide is the vehicle, 1970 Opel Ascona Station wagon (estate)? | 1632 mm 64.25 in. |
| What is the curb weight, 1970 Opel Ascona A Voyage 1.6 N (68 Hp)? | 995 kg 2193.6 lbs. |
| What is the gross weight, 1970 Opel Ascona A Voyage 1.6 N (68 Hp)? | 1505 kg 3317.96 lbs. |
| How many gears, What type is the gearbox, 1970 Opel Ascona A Voyage 1.6 N (68 Hp)? | 4, manual transmission |
