| General information | |
|---|---|
| Brand | Opel |
| Model | Insignia |
| Generation | Insignia Grand Sport (B, facelift 2020) |
| Type (Engine) | 1.5d (122 Hp) Automatic |
| Start of production | March, 2020 year |
| Powertrain Architecture | Internal Combustion engine |
| Body type | Liftback |
| Seats | 5 |
| Doors | 5 |
| Performance specs | |
| Fuel consumption at Low speed (WLTP) | 7.3-7.9 l/100 km 32.2 – 29.8 US mpg 38.7 – 35.8 UK mpg 13.7 – 12.7 km/l |
| Fuel consumption at Medium speed (WLTP) | 5.2-5.8 l/100 km 45.2 – 40.6 US mpg 54.3 – 48.7 UK mpg 19.2 – 17.2 km/l |
| Fuel consumption at high speed (WLTP) | 4.1-4.8 l/100 km 57.4 – 49 US mpg 68.9 – 58.9 UK mpg 24.4 – 20.8 km/l |
| Fuel consumption at very high speed (WLTP) | 4.9-6 l/100 km 48 – 39.2 US mpg 57.6 – 47.1 UK mpg 20.4 – 16.7 km/l |
| Combined fuel consumption (WLTP) | 5-5.8 l/100 km 47 – 40.6 US mpg 56.5 – 48.7 UK mpg 20 – 17.2 km/l |
| CO2 emissions (WLTP) | 132-153 g/km |
| Fuel Type | Diesel |
| Acceleration 0 – 100 km/h | 12.2 sec |
| Acceleration 0 – 62 mph | 12.2 sec |
| Acceleration 0 – 60 mph (Calculated by Auto-Data.net) | 11.6 sec |
| Maximum speed | 200 km/h 124.27 mph |
| Emission standard | Euro 6d |
| Weight-to-power ratio | 12.5 kg/Hp, 80.3 Hp/tonne |
| Weight-to-torque ratio | 5.3 kg/Nm, 187.5 Nm/tonne |
| Engine specs | |
| Power | 122 Hp @ 3250 rpm. |
| Power per litre | 81.6 Hp/l |
| Torque | 285 Nm @ 1750-2750 rpm. 210.21 lb.-ft. @ 1750-2750 rpm. |
| Engine layout | Front, Transverse |
| Engine Model/Code | F15DVH |
| Engine displacement | 1496 cm3 91.29 cu. in. |
| Number of cylinders | 3 |
| Engine configuration | Inline |
| Number of valves per cylinder | 4 |
| Fuel injection system | Diesel Commonrail |
| Engine aspiration | Turbocharger, Intercooler |
| Engine oil capacity | 4.25 l 4.49 US qt | 3.74 UK qt |
| Engine oil specification |  Log in to see. |
| Engine systems | Start & Stop System Particulate filter |
|
|
|
| Space, Volume and weights | |
| Kerb Weight | 1520 kg 3351.03 lbs. |
| Max. weight | 2140 kg 4717.89 lbs. |
| Max load | 620 kg 1366.87 lbs. |
| Trunk (boot) space – minimum | 490 l 17.3 cu. ft. |
| Trunk (boot) space – maximum | 1450 l 51.21 cu. ft. |
| Fuel tank capacity | 62 l 16.38 US gal | 13.64 UK gal |
| Max. roof load | 60 kg 132.28 lbs. |
| Permitted trailer load with brakes (12%) | 1500 kg 3306.93 lbs. |
| Permitted trailer load without brakes | 730 kg 1609.37 lbs. |
| Permitted towbar download | 75 kg 165.35 lbs. |
| Dimensions | |
| Length | 4897 mm 192.8 in. |
| Width | 1863 mm 73.35 in. |
| Width with mirrors folded | 1941 mm 76.42 in. |
| Width including mirrors | 2093 mm 82.4 in. |
| Height | 1455 mm 57.28 in. |
| Wheelbase | 2829 mm 111.38 in. |
| Front track | 1607 mm 63.27 in. |
| Rear (Back) track | 1610 mm 63.39 in. |
| Front overhang | 990 mm 38.98 in. |
| Rear overhang | 1078 mm 42.44 in. |
| Minimum turning circle (turning diameter) | 11.74 m 38.52 ft. |
| Drivetrain, brakes and suspension specs | |
| Drivetrain Architecture | The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
| Drive wheel | Front wheel drive |
| Number of gears and type of gearbox | 8 gears, automatic transmission |
| Front brakes | Ventilated discs |
| Rear brakes | Disc |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Power steering | Electric Steering |
| Tires size | 215/55 R17; 245/45 R18; 245/35 R20 |
| Wheel rims size | 7J x 17; 8.5J x 18; 8.5J x 20 |
| What is the body type, Opel Insignia Grand Sport (B, facelift 2020)? | Liftback, 5 Doors, 5 Seats |
|---|---|
| What is the fuel economy, Opel Insignia Grand Sport (B, facelift 2020) 1.5d (122 Hp) Automatic? | 5-5.8 l/100 km 47 – 40.6 US mpg 56.5 – 48.7 UK mpg 20 – 17.2 km/l |
| How ECO is the car, Opel Insignia 1.5d (122 Hp) Automatic? | 132-153 g/km CO2 Euro 6d |
| How fast is the car, 2020 Insignia Grand Sport (B, facelift 2020) 1.5d (122 Hp) Automatic? | 200 km/h | 124.27 mph 0-100 km/h: 12.2 sec 0-60 mph: 11.6 sec |
| How much power, Opel Insignia Liftback 2020 1.5d (122 Hp) Automatic? | 122 Hp, 285 Nm 210.21 lb.-ft. |
| What is the engine size, Opel Insignia Liftback 2020 1.5d (122 Hp) Automatic? | 1.5 l 1496 cm3 91.29 cu. in. |
| How many cylinders, 2020 Opel 1.5d (122 Hp) Automatic? | 3, Inline |
| What is the drivetrain, Opel Insignia Grand Sport (B, facelift 2020) Liftback 2020 1.5d (122 Hp) Automatic? | Front wheel drive. Internal Combustion engine. The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
| How long is this vehicle, 2020 Opel Insignia Liftback? | 4897 mm 192.8 in. |
| How wide is the vehicle, 2020 Opel Insignia Liftback? | 1863 mm 73.35 in. |
| What is the curb weight, 2020 Opel Insignia Grand Sport (B, facelift 2020) 1.5d (122 Hp) Automatic? | 1520 kg 3351.03 lbs. |
| What is the gross weight, 2020 Opel Insignia Grand Sport (B, facelift 2020) 1.5d (122 Hp) Automatic? | 2140 kg 4717.89 lbs. |
| How much trunk (boot) space, 2020 Opel Insignia Liftback? | 490 – 1450 l 17.3 – 51.21 cu. ft. |
| How many gears, What type is the gearbox, 2020 Opel Insignia Grand Sport (B, facelift 2020) 1.5d (122 Hp) Automatic? | 8, automatic transmission |
