| General information | |
|---|---|
| Brand | Opel |
| Model | Insignia |
| Generation | Insignia Sports Tourer (A, facelift 2013) |
| Type (Engine) | OPC 2.8 V6 (325 Hp) AWD Turbo Ecotec |
| Start of production | September, 2013 year |
| End of production | January, 2017 year |
| Powertrain Architecture | Internal Combustion engine |
| Body type | Station wagon (estate) |
| Seats | 5 |
| Doors | 5 |
| Performance specs | |
| Fuel consumption (economy) – urban | 16 l/100 km 14.7 US mpg 17.7 UK mpg 6.3 km/l |
| Fuel consumption (economy) – extra urban | 7.9 l/100 km 29.8 US mpg 35.8 UK mpg 12.7 km/l |
| Fuel consumption (economy) – combined | 10.9 l/100 km 21.6 US mpg 25.9 UK mpg 9.2 km/l |
| CO2 emissions | 255 g/km |
| Fuel Type | Petrol (Gasoline) |
| Acceleration 0 – 100 km/h | 6 sec |
| Acceleration 0 – 62 mph | 6 sec |
| Acceleration 0 – 60 mph (Calculated by Auto-Data.net) | 5.7 sec |
| Maximum speed | 250 km/h 155.34 mph |
| Emission standard | Euro 5 |
| Weight-to-power ratio | 5.7 kg/Hp, 174.3 Hp/tonne |
| Weight-to-torque ratio | 4.3 kg/Nm, 233.2 Nm/tonne |
| Engine specs | |
| Power | 325 Hp @ 5250 rpm. |
| Power per litre | 116.4 Hp/l |
| Torque | 435 Nm @ 5250 rpm. 320.84 lb.-ft. @ 5250 rpm. |
| Engine layout | Front, Transverse |
| Engine Model/Code | A28NER, B28NER |
| Engine displacement | 2792 cm3 170.38 cu. in. |
| Number of cylinders | 6 |
| Engine configuration | V-engine |
| Cylinder Bore | 89 mm 3.5 in. |
| Piston Stroke | 74.8 mm 2.94 in. |
| Compression ratio | 9.5:1 |
| Fuel injection system | Multi-port manifold injection |
| Engine aspiration | Turbocharger, Intercooler |
| Engine oil capacity | 6.3 l 6.66 US qt | 5.54 UK qt |
| Engine oil specification |  Log in to see. |
| Coolant | 6.7 l 7.08 US qt | 5.9 UK qt |
|
|
|
| Space, Volume and weights | |
| Kerb Weight | 1865 kg 4111.62 lbs. |
| Max. weight | 2475 kg 5456.44 lbs. |
| Max load | 610 kg 1344.82 lbs. |
| Trunk (boot) space – minimum | 540 l 19.07 cu. ft. |
| Trunk (boot) space – maximum | 1530 l 54.03 cu. ft. |
| Fuel tank capacity | 70 l 18.49 US gal | 15.4 UK gal |
| Max. roof load | 100 kg 220.46 lbs. |
| Permitted trailer load with brakes (12%) | 2000 kg 4409.25 lbs. |
| Permitted trailer load without brakes | 750 kg 1653.47 lbs. |
| Dimensions | |
| Length | 4908 mm 193.23 in. |
| Width | 1858 mm 73.15 in. |
| Width including mirrors | 2084 mm 82.05 in. |
| Height | 1520 mm 59.84 in. |
| Wheelbase | 2737 mm 107.76 in. |
| Front track | 1585 mm 62.4 in. |
| Rear (Back) track | 1587 mm 62.48 in. |
| Minimum turning circle (turning diameter) | 11.4 m 37.4 ft. |
| Drivetrain, brakes and suspension specs | |
| Drive wheel | All wheel drive (4×4) |
| Number of gears and type of gearbox | 6 gears, manual transmission |
| Front brakes | Ventilated discs |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Power steering | Electric Steering |
| What is the body type, Opel Insignia Sports Tourer (A, facelift 2013)? | Station wagon (estate), 5 Doors, 5 Seats |
|---|---|
| What is the fuel economy, Opel Insignia Sports Tourer (A, facelift 2013) OPC 2.8 V6 (325 Hp) AWD Turbo Ecotec? | 10.9 l/100 km 21.6 US mpg 25.9 UK mpg 9.2 km/l |
| How ECO is the car, Opel Insignia OPC 2.8 V6 (325 Hp) AWD Turbo Ecotec? | 255 g/km CO2 Euro 5 |
| How fast is the car, 2013 Insignia Sports Tourer (A, facelift 2013) OPC 2.8 V6 (325 Hp) AWD Turbo Ecotec? | 250 km/h | 155.34 mph 0-100 km/h: 6 sec 0-60 mph: 5.7 sec |
| How much power, Opel Insignia Station wagon (estate) 2013 OPC 2.8 V6 (325 Hp) AWD Turbo Ecotec? | 325 Hp, 435 Nm 320.84 lb.-ft. |
| What is the engine size, Opel Insignia Station wagon (estate) 2013 OPC 2.8 V6 (325 Hp) AWD Turbo Ecotec? | 2.8 l 2792 cm3 170.38 cu. in. |
| How many cylinders, 2013 Opel OPC 2.8 V6 (325 Hp) AWD Turbo Ecotec? | 6, V-engine |
| What is the drivetrain, Opel Insignia Sports Tourer (A, facelift 2013) Station wagon (estate) 2013 OPC 2.8 V6 (325 Hp) AWD Turbo Ecotec? | All wheel drive (4×4). Internal Combustion engine. |
| How long is this vehicle, 2013 Opel Insignia Station wagon (estate)? | 4908 mm 193.23 in. |
| How wide is the vehicle, 2013 Opel Insignia Station wagon (estate)? | 1858 mm 73.15 in. |
| What is the curb weight, 2013 Opel Insignia Sports Tourer (A, facelift 2013) OPC 2.8 V6 (325 Hp) AWD Turbo Ecotec? | 1865 kg 4111.62 lbs. |
| What is the gross weight, 2013 Opel Insignia Sports Tourer (A, facelift 2013) OPC 2.8 V6 (325 Hp) AWD Turbo Ecotec? | 2475 kg 5456.44 lbs. |
| How much trunk (boot) space, 2013 Opel Insignia Station wagon (estate)? | 540 – 1530 l 19.07 – 54.03 cu. ft. |
| How many gears, What type is the gearbox, 2013 Opel Insignia Sports Tourer (A, facelift 2013) OPC 2.8 V6 (325 Hp) AWD Turbo Ecotec? | 6, manual transmission |
