| General information | |
|---|---|
| Brand | RAM |
| Model | 1500 |
| Generation | 1500 Crew Cab (DT, facelift 2024) |
| Type (Engine) | Ramcharger 3.6 V6 91.8 kWh (647 Hp) Range Extender 4×4 |
| Start of production | 2025 year |
| Powertrain Architecture | PHEV (Plug-in Hybrid Electric Vehicle) |
| Body type | Pick-up |
| Seats | 5-6 |
| Doors | 4 |
| Performance specs | |
| Fuel consumption (economy) – combined (EPA) | 11.8 l/100 km 19.9 US mpg 23.9 UK mpg 8.5 km/l |
| Fuel Type | Petrol / electricity |
| Acceleration 0 – 60 mph | 4.5 sec |
| Maximum speed | 183 km/h, Electronically limited 113.71 mph |
| Weight-to-power ratio | 5.3 kg/Hp, 190 Hp/tonne |
| Weight-to-torque ratio | 4.1 kg/Nm, 242.9 Nm/tonne |
| Electric cars and hybrids specs | |
| Gross battery capacity | 91.8 kWh |
| Net (usable) battery capacity | 69.7 kWh |
| Battery voltage | 400 V |
| Battery technology | Lithium nickel manganese cobalt oxides (Li-NMC) |
| Battery weight | 550 kg 1212.54 lbs. |
| Battery location | Below the floor |
| All-electric range (EPA) | 233 km 144.78 mi |
| Average Energy consumption (EPA) | 35 kWh/100 km
56.33 kWh/100 mi |
| Charging ports |  Log in to see. |
| Electric motor 1 | |
| Electric motor power | 340 Hp |
| Electric motor Torque | 420 Nm
309.78 lb.-ft. |
| Electric motor location | Front axle, Transverse |
| Electric motor type | Synchronous |
| Electric motor 2 | |
| Electric motor power | 337 Hp |
| Electric motor Torque | 420 Nm
309.78 lb.-ft. |
| Electric motor location | Rear axle, Transverse |
| Electric motor type | Synchronous |
| System power | 647 Hp |
| System torque | 827 Nm 609.96 lb.-ft. |
| Internal combustion engine specs | |
| Power | 271 Hp @ 5800 rpm. |
| Power per litre | 75.2 Hp/l |
| Torque | 311 Nm @ 4100 rpm. 229.38 lb.-ft. @ 4100 rpm. |
| Maximum engine speed | 5800 rpm. |
| Engine layout | Front, Longitudinal |
| Engine Model/Code | Pentastar |
| Engine displacement | 3604 cm3 219.93 cu. in. |
| Number of cylinders | 6 |
| Engine configuration | V-engine |
| Cylinder Bore | 96 mm 3.78 in. |
| Piston Stroke | 83 mm 3.27 in. |
| Compression ratio | 11.3:1 |
| Number of valves per cylinder | 4 |
| Fuel injection system | Multi-port manifold injection |
| Engine aspiration | Naturally aspirated engine |
| Valvetrain | DOHC, VVT |
| Engine oil capacity | 4.73 l 5 US qt | 4.16 UK qt |
| Coolant | 13.25 l 14 US qt | 11.66 UK qt |
|
|
|
| Space, Volume and weights | |
| Kerb Weight | 3405 kg 7506.74 lbs. |
| Max. weight | 4596 kg 10132.45 lbs. |
| Max load | 1191 kg 2625.71 lbs. |
| Trunk (boot) space – minimum | 1523 l 53.78 cu. ft. |
| Fuel tank capacity | 102 l 26.95 US gal | 22.44 UK gal |
| Permitted trailer load with brakes (12%) | 6350 kg 13999.35 lbs. |
| Dimensions | |
| Length | 5903 mm 232.4 in. |
| Width | 2062 mm 81.18 in. |
| Height | 1963-1968 mm 77.28 – 77.48 in. |
| Wheelbase | 3672 mm 144.57 in. |
| Front track | 1740 mm 68.5 in. |
| Rear (Back) track | 1727 mm 67.99 in. |
| Ride height (ground clearance) | 216-228 mm 8.5 – 8.98 in. |
| Drag coefficient (Cd) | 0.352 |
| Minimum turning circle (turning diameter) | 15.1 m 49.54 ft. |
| Approach angle | 19.9° |
| Departure angle | 19.8° |
| Drivetrain, brakes and suspension specs | |
| Drivetrain Architecture | The Internal combustion engine (ICE) drives the generator only, with no mechanical connection to the drive. Two electric motors drive the front and rear wheels. |
| Drive wheel | All wheel drive (4×4) |
| Number of gears and type of gearbox | 1 gears, automatic transmission |
| Front suspension | Double wishbone, Air suspension |
| Rear suspension | Independent multi-link suspension, Air suspension |
| Front brakes | Ventilated discs, 359.9×39.1 mm |
| Rear brakes | Ventilated discs, 357.9×34 mm |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Power steering | Electric Steering |
| Tires size | 275/60 R20; 275/50 R22 |
| Wheel rims size | 20; 22 |
| What is the body type, RAM 1500 Crew Cab (DT, facelift 2024)? | Pick-up, 4 Doors, 5-6 Seats |
|---|---|
| What is the fuel economy, RAM 1500 Crew Cab (DT, facelift 2024) Ramcharger 3.6 V6 91.8 kWh (647 Hp) Range Extender 4×4? | 11.8 l/100 km 19.9 US mpg 23.9 UK mpg 8.5 km/l |
| What is the range of pure electric driving, Ramcharger 3.6 V6 91.8 kWh (647 Hp) Range Extender 4×4? | 233 km 144.78 mi |
| What is electricity consumption, RAM 1500 Crew Cab (DT, facelift 2024) Ramcharger 3.6 V6 91.8 kWh (647 Hp) Range Extender 4×4? | 35 kWh/100 km 56.33 kWh/100 mi 60 MPGe 2.9 km/kWh 1.8 mi/kWh |
| How fast is the car, 2025 1500 Crew Cab (DT, facelift 2024) Ramcharger 3.6 V6 91.8 kWh (647 Hp) Range Extender 4×4? | 183 km/h | 113.71 mph 0-60 mph: 4.5 sec |
| How much power, RAM 1500 Pick-up 2025 Ramcharger 3.6 V6 91.8 kWh (647 Hp) Range Extender 4×4? | 647 Hp, 827 Nm 609.96 lb.-ft. |
| What is the engine size, RAM 1500 Pick-up 2025 Ramcharger 3.6 V6 91.8 kWh (647 Hp) Range Extender 4×4? | 3.6 l 3604 cm3 219.93 cu. in. |
| How many cylinders, 2025 RAM Ramcharger 3.6 V6 91.8 kWh (647 Hp) Range Extender 4×4? | 6, V-engine |
| What is the drivetrain, RAM 1500 Crew Cab (DT, facelift 2024) Pick-up 2025 Ramcharger 3.6 V6 91.8 kWh (647 Hp) Range Extender 4×4? | All wheel drive (4×4). PHEV (Plug-in Hybrid Electric Vehicle). The Internal combustion engine (ICE) drives the generator only, with no mechanical connection to the drive. Two electric motors drive the front and rear wheels. |
| How long is this vehicle, 2025 RAM 1500 Pick-up? | 5903 mm 232.4 in. |
| How wide is the vehicle, 2025 RAM 1500 Pick-up? | 2062 mm 81.18 in. |
| What is the curb weight, 2025 RAM 1500 Crew Cab (DT, facelift 2024) Ramcharger 3.6 V6 91.8 kWh (647 Hp) Range Extender 4×4? | 3405 kg 7506.74 lbs. |
| What is the gross weight, 2025 RAM 1500 Crew Cab (DT, facelift 2024) Ramcharger 3.6 V6 91.8 kWh (647 Hp) Range Extender 4×4? | 4596 kg 10132.45 lbs. |
| How much trunk (boot) space, 2025 RAM 1500 Pick-up? | 1523 l 53.78 cu. ft. |
| How many gears, What type is the gearbox, 2025 RAM 1500 Crew Cab (DT, facelift 2024) Ramcharger 3.6 V6 91.8 kWh (647 Hp) Range Extender 4×4? | 1, automatic transmission |
