| General information | |
|---|---|
| Brand | Renault |
| Model | 10 |
| Generation | 10 (Phase II, 1967) |
| Type (Engine) | 1.1 (46 Hp) Automatic |
| Start of production | 1967 year |
| End of production | 1971 year |
| Powertrain Architecture | Internal Combustion engine |
| Body type | Sedan |
| Seats | 5 |
| Doors | 4 |
| Performance specs | |
| Fuel Type | Petrol (Gasoline) |
| Engine specs | |
| Power | 46 Hp @ 4600 rpm. |
| Power per litre | 41.5 Hp/l |
| Torque | 78 Nm @ 3000 rpm. 57.53 lb.-ft. @ 3000 rpm. |
| Engine layout | Rear, Longitudinal |
| Engine Model/Code | 688.01 |
| Engine displacement | 1108 cm3 67.61 cu. in. |
| Number of cylinders | 4 |
| Engine configuration | Inline |
| Cylinder Bore | 70 mm 2.76 in. |
| Piston Stroke | 72 mm 2.83 in. |
| Compression ratio | 8.5:1 |
| Number of valves per cylinder | 2 |
| Fuel injection system | Carburettor |
| Engine aspiration | Naturally aspirated engine |
| Valvetrain | OHV |
| Engine oil capacity | 2.5 l 2.64 US qt | 2.2 UK qt |
| Engine oil specification |  Log in to see. |
| Coolant | 7.6 l 8.03 US qt | 6.69 UK qt |
|
|
|
| Space, Volume and weights | |
| Trunk (boot) space – minimum | 315 l 11.12 cu. ft. |
| Fuel tank capacity | 32 l 8.45 US gal | 7.04 UK gal |
| Dimensions | |
| Length | 4191 mm 165 in. |
| Width | 1524 mm 60 in. |
| Height | 1411 mm 55.55 in. |
| Wheelbase | 2270 mm 89.37 in. |
| Front track | 1254 mm 49.37 in. |
| Rear (Back) track | 1219 mm 47.99 in. |
| Ride height (ground clearance) | 127 mm 5 in. |
| Minimum turning circle (turning diameter) | 9.2 m 30.18 ft. |
| Drivetrain, brakes and suspension specs | |
| Drivetrain Architecture | The Internal combustion engine (ICE) drives the rear wheels of the vehicle. |
| Drive wheel | Rear wheel drive |
| Number of gears and type of gearbox | 3 gears, automatic transmission |
| Front suspension | Independent coil spring, Transverse stabilizer |
| Rear suspension | Independent coil spring |
| Front brakes | Disc, 259 mm |
| Rear brakes | Disc, 259 mm |
| Steering type | Steering rack and pinion |
| Tires size | 145/80 R15 |
| Wheel rims size | 4J x 15 |
| What is the body type, Renault 10 (Phase II, 1967)? | Sedan, 4 Doors, 5 Seats |
|---|---|
| How much power, Renault 10 Sedan 1967 1.1 (46 Hp) Automatic? | 46 Hp, 78 Nm 57.53 lb.-ft. |
| What is the engine size, Renault 10 Sedan 1967 1.1 (46 Hp) Automatic? | 1.1 l 1108 cm3 67.61 cu. in. |
| How many cylinders, 1967 Renault 1.1 (46 Hp) Automatic? | 4, Inline |
| What is the drivetrain, Renault 10 (Phase II, 1967) Sedan 1967 1.1 (46 Hp) Automatic? | Rear wheel drive. Internal Combustion engine. The Internal combustion engine (ICE) drives the rear wheels of the vehicle. |
| How long is this vehicle, 1967 Renault 10 Sedan? | 4191 mm 165 in. |
| How wide is the vehicle, 1967 Renault 10 Sedan? | 1524 mm 60 in. |
| How much trunk (boot) space, 1967 Renault 10 Sedan? | 315 l 11.12 cu. ft. |
| How many gears, What type is the gearbox, 1967 Renault 10 (Phase II, 1967) 1.1 (46 Hp) Automatic? | 3, automatic transmission |
