| General information | |
|---|---|
| Brand | Renault |
| Model | Captur |
| Generation | Captur II |
| Type (Engine) | E-TECH 1.6 (158 Hp) Plug-in Hybrid Multimode |
| Start of production | June, 2020 year |
| End of production | May, 2022 year |
| Powertrain Architecture | PHEV (Plug-in Hybrid Electric Vehicle) |
| Body type | Crossover |
| Seats | 5 |
| Doors | 5 |
| Performance specs | |
| Combined fuel consumption (WLTP) | 1.5-1.6 l/100 km 156.8 – 147 US mpg 188.3 – 176.6 UK mpg 66.7 – 62.5 km/l |
| CO2 emissions (WLTP) | 33-36 g/km |
| Fuel Type | Petrol / electricity |
| Acceleration 0 – 100 km/h | 10.1 sec |
| Acceleration 0 – 62 mph | 10.1 sec |
| Acceleration 0 – 60 mph (Calculated by Auto-Data.net) | 9.6 sec |
| Maximum speed | 173 km/h 107.5 mph |
| Emission standard | Euro 6d |
| Weight-to-power ratio | 9.9 kg/Hp, 101 Hp/tonne |
| Weight-to-torque ratio | 10.9 kg/Nm, 92.1 Nm/tonne |
| Electric cars and hybrids specs | |
| Gross battery capacity | 10.46 kWh |
| Net (usable) battery capacity | 9.8 kWh |
| Battery voltage | 346 V |
| Battery technology | Lithium-ion (Li-Ion) |
| Battery weight | 103 kg 227.08 lbs. |
| Battery location | Below the floor, under the rear seats |
| All-electric range (WLTP) | 50 km 31.07 mi |
| Average Energy consumption (WLTP) | 17.3-18.3 kWh/100 km
27.84 – 29.45 kWh/100 mi |
| Max speed (electric) | 135 km/h
83.89 mph |
| Charging ports |  Log in to see. |
| Electric motor 1 | |
| Electric motor power | 67 Hp |
| Electric motor Torque | 205 Nm
151.2 lb.-ft. |
| Electric motor location | Integrated into the transmission |
| System power | 158 Hp |
| Internal combustion engine specs | |
| Power | 92 Hp @ 5600 rpm. |
| Power per litre | 57.6 Hp/l |
| Torque | 144 Nm @ 3200 rpm. 106.21 lb.-ft. @ 3200 rpm. |
| Engine layout | Front, Transverse |
| Engine Model/Code | H4M 630 |
| Engine displacement | 1598 cm3 97.52 cu. in. |
| Number of cylinders | 4 |
| Engine configuration | Inline |
| Cylinder Bore | 78 mm 3.07 in. |
| Piston Stroke | 83.6 mm 3.29 in. |
| Number of valves per cylinder | 4 |
| Fuel injection system | Multi-port manifold injection |
| Engine aspiration | Naturally aspirated engine |
| Valvetrain | DOHC |
| Engine oil capacity | 4.5 l 4.76 US qt | 3.96 UK qt |
| Engine oil specification | Log in to see. |
| Engine systems | Start & Stop System Particulate filter |
|
|
|
| Space, Volume and weights | |
| Kerb Weight | 1564 kg 3448.03 lbs. |
| Max. weight | 2060 kg 4541.52 lbs. |
| Max load | 496 kg 1093.49 lbs. |
| Trunk (boot) space – minimum | 265 l 9.36 cu. ft. |
| Trunk (boot) space – maximum | 1118 l 39.48 cu. ft. |
| Fuel tank capacity | 39 l 10.3 US gal | 8.58 UK gal |
| Max. roof load | 80 kg 176.37 lbs. |
| Permitted trailer load with brakes (12%) | 750 kg 1653.47 lbs. |
| Permitted trailer load without brakes | 650 kg 1433 lbs. |
| Permitted towbar download | 75 kg 165.35 lbs. |
| Dimensions | |
| Length | 4227 mm 166.42 in. |
| Width with mirrors folded | 1797 mm 70.75 in. |
| Width including mirrors | 2003 mm 78.86 in. |
| Height | 1576 mm 62.05 in. |
| Wheelbase | 2639 mm 103.9 in. |
| Front track | 1560 mm 61.42 in. |
| Rear (Back) track | 1547 mm 60.91 in. |
| Front overhang | 876 mm 34.49 in. |
| Rear overhang | 712 mm 28.03 in. |
| Ride height (ground clearance) | 142 mm 5.59 in. |
| Minimum turning circle (turning diameter) | 11.1 m 36.42 ft. |
| Drivetrain, brakes and suspension specs | |
| Drivetrain Architecture | The Internal combustion engine (ICE) and electric motor drive the front wheels of the car with the ability to work in full electric or mixed mode. |
| Drive wheel | Front wheel drive |
| Number of gears and type of gearbox | automatic transmission Multimode |
| Front suspension | Independent, type McPherson with coil spring and anti-roll bar |
| Rear suspension | Coil spring, Torsion |
| Front brakes | Ventilated discs, 296×26 mm |
| Rear brakes | Disc, 290×13 mm |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Power steering | Electric Steering |
| Tires size | 215/65 R16; 215/60 R17; 215/55 R18 |
| Wheel rims size | 16; 17; 18 |
| What is the body type, Renault Captur II? | Crossover, 5 Doors, 5 Seats |
|---|---|
| What is the fuel economy, Renault Captur II E-TECH 1.6 (158 Hp) Plug-in Hybrid Multimode? | 1.5-1.6 l/100 km 156.8 – 147 US mpg 188.3 – 176.6 UK mpg 66.7 – 62.5 km/l |
| How ECO is the car, Renault Captur E-TECH 1.6 (158 Hp) Plug-in Hybrid Multimode? | 33-36 g/km CO2 Euro 6d |
| What is the range of pure electric driving, E-TECH 1.6 (158 Hp) Plug-in Hybrid Multimode? | 50 km 31.07 mi |
| What is electricity consumption, Renault Captur II E-TECH 1.6 (158 Hp) Plug-in Hybrid Multimode? | 17.3-18.3 kWh/100 km 27.84 – 29.45 kWh/100 mi 121 – 114 MPGe 5.8 – 5.5 km/kWh 3.6 – 3.4 mi/kWh |
| How fast is the car, 2020 Captur II E-TECH 1.6 (158 Hp) Plug-in Hybrid Multimode? | 173 km/h | 107.5 mph 0-100 km/h: 10.1 sec 0-60 mph: 9.6 sec |
| How much power, Renault Captur Crossover 2020 E-TECH 1.6 (158 Hp) Plug-in Hybrid Multimode? | 158 Hp, 144 Nm 106.21 lb.-ft. |
| What is the engine size, Renault Captur Crossover 2020 E-TECH 1.6 (158 Hp) Plug-in Hybrid Multimode? | 1.6 l 1598 cm3 97.52 cu. in. |
| How many cylinders, 2020 Renault E-TECH 1.6 (158 Hp) Plug-in Hybrid Multimode? | 4, Inline |
| What is the drivetrain, Renault Captur II Crossover 2020 E-TECH 1.6 (158 Hp) Plug-in Hybrid Multimode? | Front wheel drive. PHEV (Plug-in Hybrid Electric Vehicle). The Internal combustion engine (ICE) and electric motor drive the front wheels of the car with the ability to work in full electric or mixed mode. |
| How long is this vehicle, 2020 Renault Captur Crossover? | 4227 mm 166.42 in. |
| How wide is the vehicle, 2020 Renault Captur Crossover? | 1797 mm 70.75 in. |
| What is the curb weight, 2020 Renault Captur II E-TECH 1.6 (158 Hp) Plug-in Hybrid Multimode? | 1564 kg 3448.03 lbs. |
| What is the gross weight, 2020 Renault Captur II E-TECH 1.6 (158 Hp) Plug-in Hybrid Multimode? | 2060 kg 4541.52 lbs. |
| How much trunk (boot) space, 2020 Renault Captur Crossover? | 265 – 1118 l 9.36 – 39.48 cu. ft. |
| How many gears, What type is the gearbox, 2020 Renault Captur II E-TECH 1.6 (158 Hp) Plug-in Hybrid Multimode? | automatic transmission Multimode |
