| General information | |
|---|---|
| Brand | Renault |
| Model | Espace |
| Generation | Grand Espace IV (Phase IV, 2012) |
| Type (Engine) | 2.0 TCe (170 Hp) |
| Start of production | 2012 year |
| End of production | 2013 year |
| Powertrain Architecture | Internal Combustion engine |
| Body type | Minivan, MPV |
| Seats | 7 |
| Doors | 5 |
| Performance specs | |
| Fuel consumption (economy) – urban | 11.3 l/100 km 20.8 US mpg 25 UK mpg 8.8 km/l |
| Fuel consumption (economy) – extra urban | 6.9 l/100 km 34.1 US mpg 40.9 UK mpg 14.5 km/l |
| Fuel consumption (economy) – combined | 8.5 l/100 km 27.7 US mpg 33.2 UK mpg 11.8 km/l |
| CO2 emissions | 198 g/km |
| Fuel Type | Petrol (Gasoline) |
| Acceleration 0 – 100 km/h | 9.7 sec |
| Acceleration 0 – 62 mph | 9.7 sec |
| Acceleration 0 – 60 mph (Calculated by Auto-Data.net) | 9.2 sec |
| Maximum speed | 205 km/h 127.38 mph |
| Emission standard | Euro 5 |
| Weight-to-power ratio | 10.4 kg/Hp, 96.5 Hp/tonne |
| Weight-to-torque ratio | 6.5 kg/Nm, 153.2 Nm/tonne |
| Engine specs | |
| Power | 170 Hp @ 5000 rpm. |
| Power per litre | 85.1 Hp/l |
| Torque | 270 Nm @ 3250 rpm. 199.14 lb.-ft. @ 3250 rpm. |
| Engine layout | Front, Transverse |
| Engine Model/Code | F4R |
| Engine displacement | 1998 cm3 121.93 cu. in. |
| Number of cylinders | 4 |
| Engine configuration | Inline |
| Cylinder Bore | 82.7 mm 3.26 in. |
| Piston Stroke | 93 mm 3.66 in. |
| Compression ratio | 9.8:1 |
| Number of valves per cylinder | 4 |
| Fuel injection system | Multi-port manifold injection |
| Engine aspiration | Turbocharger, Intercooler |
| Valvetrain | DOHC |
| Engine oil capacity | 5.4 l 5.71 US qt | 4.75 UK qt |
| Engine oil specification |  Log in to see. |
| Coolant | 9.3 l 9.83 US qt | 8.18 UK qt |
|
|
|
| Space, Volume and weights | |
| Kerb Weight | 1762 kg 3884.55 lbs. |
| Max. weight | 2544 kg 5608.56 lbs. |
| Max load | 782 kg 1724.01 lbs. |
| Trunk (boot) space – minimum | 456 l 16.1 cu. ft. |
| Trunk (boot) space – maximum | 3050 l 107.71 cu. ft. |
| Fuel tank capacity | 83 l 21.93 US gal | 18.26 UK gal |
| Permitted trailer load with brakes (12%) | 2000 kg 4409.25 lbs. |
| Permitted trailer load without brakes | 750 kg 1653.47 lbs. |
| Dimensions | |
| Length | 4855 mm 191.14 in. |
| Width including mirrors | 1894 mm 74.57 in. |
| Height | 1801 mm 70.91 in. |
| Wheelbase | 2868 mm 112.91 in. |
| Front overhang | 1020 mm 40.16 in. |
| Rear overhang | 967 mm 38.07 in. |
| Ride height (ground clearance) | 120 mm 4.72 in. |
| Minimum turning circle (turning diameter) | 11.8 m 38.71 ft. |
| Drivetrain, brakes and suspension specs | |
| Drivetrain Architecture | The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
| Drive wheel | Front wheel drive |
| Number of gears and type of gearbox | 6 gears, manual transmission |
| Front suspension | Independent type McPherson |
| Rear suspension | Semi-independent, coil spring |
| Front brakes | Ventilated discs |
| Rear brakes | Disc |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Power steering | Electric Steering |
| Tires size | 225/55 R17 |
| Wheel rims size | 17 |
| What is the body type, Renault Grand Espace IV (Phase IV, 2012)? | Minivan, MPV, 5 Doors, 7 Seats |
|---|---|
| What is the fuel economy, Renault Grand Espace IV (Phase IV, 2012) 2.0 TCe (170 Hp)? | 8.5 l/100 km 27.7 US mpg 33.2 UK mpg 11.8 km/l |
| How ECO is the car, Renault Espace 2.0 TCe (170 Hp)? | 198 g/km CO2 Euro 5 |
| How fast is the car, 2012 Grand Espace IV (Phase IV, 2012) 2.0 TCe (170 Hp)? | 205 km/h | 127.38 mph 0-100 km/h: 9.7 sec 0-60 mph: 9.2 sec |
| How much power, Renault Espace Minivan, MPV 2012 2.0 TCe (170 Hp)? | 170 Hp, 270 Nm 199.14 lb.-ft. |
| What is the engine size, Renault Espace Minivan, MPV 2012 2.0 TCe (170 Hp)? | 2.0 l 1998 cm3 121.93 cu. in. |
| How many cylinders, 2012 Renault 2.0 TCe (170 Hp)? | 4, Inline |
| What is the drivetrain, Renault Grand Espace IV (Phase IV, 2012) Minivan, MPV 2012 2.0 TCe (170 Hp)? | Front wheel drive. Internal Combustion engine. The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
| How long is this vehicle, 2012 Renault Espace Minivan, MPV? | 4855 mm 191.14 in. |
| How wide is the vehicle, 2012 Renault Espace Minivan, MPV? | 1894 mm 74.57 in. |
| What is the curb weight, 2012 Renault Grand Espace IV (Phase IV, 2012) 2.0 TCe (170 Hp)? | 1762 kg 3884.55 lbs. |
| What is the gross weight, 2012 Renault Grand Espace IV (Phase IV, 2012) 2.0 TCe (170 Hp)? | 2544 kg 5608.56 lbs. |
| How much trunk (boot) space, 2012 Renault Espace Minivan, MPV? | 456 – 3050 l 16.1 – 107.71 cu. ft. |
| How many gears, What type is the gearbox, 2012 Renault Grand Espace IV (Phase IV, 2012) 2.0 TCe (170 Hp)? | 6, manual transmission |
