| General information | |
|---|---|
| Brand | Renault |
| Model | Scenic |
| Generation | Grand Scenic III (Phase I) |
| Type (Engine) | 1.6 16V (110 Hp) Ethanol |
| Start of production | 2009 year |
| End of production | 2010 year |
| Powertrain Architecture | Internal Combustion engine |
| Body type | Minivan |
| Seats | 5 |
| Doors | 5 |
| Performance specs | |
| Fuel consumption (economy) – urban | 9.9 l/100 km 23.8 US mpg 28.5 UK mpg 10.1 km/l |
| Fuel consumption (economy) – extra urban | 6.1 l/100 km 38.6 US mpg 46.3 UK mpg 16.4 km/l |
| Fuel consumption (economy) – combined | 7.8 l/100 km 30.2 US mpg 36.2 UK mpg 12.8 km/l |
| CO2 emissions | 177 g/km |
| Fuel Type | Petrol / Ethanol – E85 |
| Acceleration 0 – 100 km/h | 12 sec |
| Acceleration 0 – 62 mph | 12 sec |
| Acceleration 0 – 60 mph (Calculated by Auto-Data.net) | 11.4 sec |
| Maximum speed | 185 km/h 114.95 mph |
| Emission standard | Euro 4 |
| Weight-to-power ratio | 12.8 kg/Hp, 78.2 Hp/tonne |
| Weight-to-torque ratio | 9.3 kg/Nm, 107.3 Nm/tonne |
| Engine specs | |
| Power | 110 Hp @ 6000 rpm. |
| Power per litre | 68.8 Hp/l |
| Torque | 151 Nm @ 3750 rpm. 111.37 lb.-ft. @ 3750 rpm. |
| Engine layout | Front, Transverse |
| Engine Model/Code | K4M |
| Engine displacement | 1598 cm3 97.52 cu. in. |
| Number of cylinders | 4 |
| Engine configuration | Inline |
| Cylinder Bore | 79.5 mm 3.13 in. |
| Piston Stroke | 80.5 mm 3.17 in. |
| Compression ratio | 9.7:1 |
| Number of valves per cylinder | 4 |
| Fuel injection system | Multi-port manifold injection |
| Engine aspiration | Naturally aspirated engine |
| Engine oil capacity | 5 l 5.28 US qt | 4.4 UK qt |
| Engine oil specification |  Log in to see. |
| Coolant | 5.3 l 5.6 US qt | 4.66 UK qt |
|
|
|
| Space, Volume and weights | |
| Kerb Weight | 1407 kg 3101.9 lbs. |
| Max. weight | 2067 kg 4556.95 lbs. |
| Max load | 660 kg 1455.05 lbs. |
| Trunk (boot) space – minimum | 564-702 l 19.92 – 24.79 cu. ft. |
| Trunk (boot) space – maximum | 1863 l 65.79 cu. ft. |
| Fuel tank capacity | 60 l 15.85 US gal | 13.2 UK gal |
| Max. roof load | 80 kg 176.37 lbs. |
| Permitted trailer load with brakes (12%) | 1300 kg 2866.01 lbs. |
| Permitted trailer load without brakes | 740 kg 1631.42 lbs. |
| Permitted towbar download | 75 kg 165.35 lbs. |
| Dimensions | |
| Length | 4560 mm 179.53 in. |
| Width | 1845 mm 72.64 in. |
| Width including mirrors | 2077 mm 81.77 in. |
| Height | 1675 mm 65.94 in. |
| Wheelbase | 2769 mm 109.02 in. |
| Front track | 1536 mm 60.47 in. |
| Rear (Back) track | 1539 mm 60.59 in. |
| Front overhang | 888 mm 34.96 in. |
| Rear overhang | 903 mm 35.55 in. |
| Ride height (ground clearance) | 120 mm 4.72 in. |
| Minimum turning circle (turning diameter) | 11.29 m 37.04 ft. |
| Drivetrain, brakes and suspension specs | |
| Drivetrain Architecture | The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
| Drive wheel | Front wheel drive |
| Number of gears and type of gearbox | 6 gears, manual transmission |
| Front suspension | Independent type McPherson |
| Rear suspension | Elastic beam |
| Front brakes | Ventilated discs, 296 mm |
| Rear brakes | Disc, 274 mm |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Power steering | Electric Steering |
| Tires size | 205/ 60 R16 |
| Wheel rims size | 16 |
| What is the body type, Renault Grand Scenic III (Phase I)? | Minivan, 5 Doors, 5 Seats |
|---|---|
| What is the fuel economy, Renault Grand Scenic III (Phase I) 1.6 16V (110 Hp) Ethanol? | 7.8 l/100 km 30.2 US mpg 36.2 UK mpg 12.8 km/l |
| How ECO is the car, Renault Scenic 1.6 16V (110 Hp) Ethanol? | 177 g/km CO2 Euro 4 |
| How fast is the car, 2009 Grand Scenic III (Phase I) 1.6 16V (110 Hp) Ethanol? | 185 km/h | 114.95 mph 0-100 km/h: 12 sec 0-60 mph: 11.4 sec |
| How much power, Renault Scenic Minivan 2009 1.6 16V (110 Hp) Ethanol? | 110 Hp, 151 Nm 111.37 lb.-ft. |
| What is the engine size, Renault Scenic Minivan 2009 1.6 16V (110 Hp) Ethanol? | 1.6 l 1598 cm3 97.52 cu. in. |
| How many cylinders, 2009 Renault 1.6 16V (110 Hp) Ethanol? | 4, Inline |
| What is the drivetrain, Renault Grand Scenic III (Phase I) Minivan 2009 1.6 16V (110 Hp) Ethanol? | Front wheel drive. Internal Combustion engine. The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
| How long is this vehicle, 2009 Renault Scenic Minivan? | 4560 mm 179.53 in. |
| How wide is the vehicle, 2009 Renault Scenic Minivan? | 1845 mm 72.64 in. |
| What is the curb weight, 2009 Renault Grand Scenic III (Phase I) 1.6 16V (110 Hp) Ethanol? | 1407 kg 3101.9 lbs. |
| What is the gross weight, 2009 Renault Grand Scenic III (Phase I) 1.6 16V (110 Hp) Ethanol? | 2067 kg 4556.95 lbs. |
| How much trunk (boot) space, 2009 Renault Scenic Minivan? | 564 – 1863 l 19.92 – 65.79 cu. ft. |
| How many gears, What type is the gearbox, 2009 Renault Grand Scenic III (Phase I) 1.6 16V (110 Hp) Ethanol? | 6, manual transmission |
