| General information | |
|---|---|
| Brand | Renault |
| Model | Master |
| Generation | Master III (Phase II, 2014) Combi |
| Type (Engine) | 2.3 dCi (110 Hp) L1H1 9 Seat |
| Start of production | 2017 year |
| End of production | 2018 year |
| Powertrain Architecture | Internal Combustion engine |
| Body type | Minivan, MPV |
| Seats | 9 |
| Doors | 4 |
| Performance specs | |
| Fuel consumption (economy) – combined (NEDC) | 6.8 l/100 km 34.6 US mpg 41.5 UK mpg 14.7 km/l |
| CO2 emissions (NEDC) | 176 g/km |
| Fuel Type | Diesel |
| Maximum speed | 140 km/h 86.99 mph |
| Emission standard | Euro 6 |
| Weight-to-power ratio | 18.7 kg/Hp, 53.3 Hp/tonne |
| Weight-to-torque ratio | 7.2 kg/Nm, 138.2 Nm/tonne |
| Engine specs | |
| Power | 110 Hp @ 3500 rpm. |
| Power per litre | 47.9 Hp/l |
| Torque | 285 Nm @ 1500 rpm. 210.21 lb.-ft. @ 1500 rpm. |
| Engine Model/Code | M9T |
| Engine displacement | 2298 cm3 140.23 cu. in. |
| Number of cylinders | 4 |
| Engine configuration | Inline |
| Cylinder Bore | 85 mm 3.35 in. |
| Piston Stroke | 101.3 mm 3.99 in. |
| Number of valves per cylinder | 4 |
| Fuel injection system | Diesel Commonrail |
| Engine aspiration | Turbocharger, Intercooler |
| Engine oil capacity | 8 l 8.45 US qt | 7.04 UK qt |
| Engine oil specification |  Log in to see. |
| Coolant | 11 l 11.62 US qt | 9.68 UK qt |
| Engine systems | Particulate filter |
|
|
|
| Space, Volume and weights | |
| Kerb Weight | 2062 kg 4545.93 lbs. |
| Max. weight | 3000 kg 6613.87 lbs. |
| Max load | 938 kg 2067.94 lbs. |
| Trunk (boot) space – maximum | 2800 l 98.88 cu. ft. |
| Fuel tank capacity | 80 l 21.13 US gal | 17.6 UK gal |
| AdBlue tank | 20 l 5.28 US gal | 4.4 UK gal |
| Permitted trailer load with brakes (12%) | 2500 kg 5511.56 lbs. |
| Permitted trailer load without brakes | 750 kg 1653.47 lbs. |
| Permitted towbar download | 100 kg 220.46 lbs. |
| Dimensions | |
| Length | 5048 mm 198.74 in. |
| Width | 2070 mm 81.5 in. |
| Width including mirrors | 2470 mm 97.24 in. |
| Height | 2303 mm 90.67 in. |
| Wheelbase | 3182 mm 125.28 in. |
| Front track | 1750 mm 68.9 in. |
| Rear (Back) track | 1730 mm 68.11 in. |
| Front overhang | 842 mm 33.15 in. |
| Rear overhang | 1024 mm 40.31 in. |
| Minimum turning circle (turning diameter) | 12.5 m 41.01 ft. |
| Drivetrain, brakes and suspension specs | |
| Drivetrain Architecture | The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
| Drive wheel | Front wheel drive |
| Number of gears and type of gearbox | 6 gears, manual transmission |
| Front suspension | Independent, type McPherson with coil spring and anti-roll bar |
| Rear suspension | Leaf spring |
| Front brakes | Ventilated discs, 302 mm |
| Rear brakes | Disc, 305 mm |
| Tires size | 215/65 R16 |
| Wheel rims size | 16 |
| What is the body type, Renault Master III (Phase II, 2014) Combi? | Minivan, MPV, 4 Doors, 9 Seats |
|---|---|
| What is the fuel economy, Renault Master III (Phase II, 2014) Combi 2.3 dCi (110 Hp) L1H1 9 Seat? | 6.8 l/100 km 34.6 US mpg 41.5 UK mpg 14.7 km/l |
| How ECO is the car, Renault Master 2.3 dCi (110 Hp) L1H1 9 Seat? | 176 g/km CO2 Euro 6 |
| How fast is the car, 2017 Master III (Phase II, 2014) Combi 2.3 dCi (110 Hp) L1H1 9 Seat? | 140 km/h | 86.99 mph |
| How much power, Renault Master Minivan, MPV 2017 2.3 dCi (110 Hp) L1H1 9 Seat? | 110 Hp, 285 Nm 210.21 lb.-ft. |
| What is the engine size, Renault Master Minivan, MPV 2017 2.3 dCi (110 Hp) L1H1 9 Seat? | 2.3 l 2298 cm3 140.23 cu. in. |
| How many cylinders, 2017 Renault 2.3 dCi (110 Hp) L1H1 9 Seat? | 4, Inline |
| What is the drivetrain, Renault Master III (Phase II, 2014) Combi Minivan, MPV 2017 2.3 dCi (110 Hp) L1H1 9 Seat? | Front wheel drive. Internal Combustion engine. The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
| How long is this vehicle, 2017 Renault Master Minivan, MPV? | 5048 mm 198.74 in. |
| How wide is the vehicle, 2017 Renault Master Minivan, MPV? | 2070 mm 81.5 in. |
| What is the curb weight, 2017 Renault Master III (Phase II, 2014) Combi 2.3 dCi (110 Hp) L1H1 9 Seat? | 2062 kg 4545.93 lbs. |
| What is the gross weight, 2017 Renault Master III (Phase II, 2014) Combi 2.3 dCi (110 Hp) L1H1 9 Seat? | 3000 kg 6613.87 lbs. |
| How much trunk (boot) space, 2017 Renault Master Minivan, MPV? | 2800 l 98.88 cu. ft. |
| How many gears, What type is the gearbox, 2017 Renault Master III (Phase II, 2014) Combi 2.3 dCi (110 Hp) L1H1 9 Seat? | 6, manual transmission |
