| General information | |
|---|---|
| Brand | Renault |
| Model | Rafale |
| Generation | Rafale |
| Type (Engine) | 1.2 (200 Hp) E-Tech Full Hybrid Multi-Mode |
| Start of production | 2024 year |
| Powertrain Architecture | FHEV (Full Hybrid Electric Vehicle) |
| Body type | Coupe, SUV |
| Seats | 5 |
| Doors | 5 |
| Performance specs | |
| Combined fuel consumption (WLTP) | 4.7 l/100 km 50 US mpg 60.1 UK mpg 21.3 km/l |
| CO2 emissions (WLTP) | 105 g/km |
| Fuel Type | Petrol (Gasoline) |
| Emission standard | Euro 6d |
| Weight-to-power ratio | 8.3 kg/Hp, 121 Hp/tonne |
| Weight-to-torque ratio | 4 kg/Nm, 248 Nm/tonne |
| Electric cars and hybrids specs | |
| Gross battery capacity | 2 kWh |
| Battery voltage | 400 V |
| Battery technology | Lithium-ion (Li-Ion) |
| Battery location | Below the floor, under the front seats |
| Max speed (electric) | 130 km/h
80.78 mph |
| Electric motor 1 | |
| Electric motor power | 68 Hp |
| Electric motor Torque | 205 Nm
151.2 lb.-ft. |
| Electric motor location | Integrated into the transmission |
| Electric motor 2 | |
| Electric motor power | 34 Hp |
| Electric motor Torque | 50 Nm
36.88 lb.-ft. |
| Electric motor location | Integrated into the transmission |
| System power | 200 Hp |
| System torque | 410 Nm 302.4 lb.-ft. |
| Internal combustion engine specs | |
| Power | 130 Hp |
| Power per litre | 108.4 Hp/l |
| Torque | 205 Nm 151.2 lb.-ft. |
| Engine layout | Front, Transverse |
| Engine Model/Code | HR12 |
| Engine displacement | 1199 cm3 73.17 cu. in. |
| Number of cylinders | 3 |
| Engine configuration | Inline |
| Number of valves per cylinder | 4 |
| Fuel injection system | Direct injection |
| Engine aspiration | Turbocharger, Intercooler |
| Engine systems | Start & Stop System Particulate filter |
|
|
|
| Space, Volume and weights | |
| Kerb Weight | 1653 kg 3644.24 lbs. |
| Trunk (boot) space – minimum | 647 l 22.85 cu. ft. |
| Dimensions | |
| Length | 4710 mm 185.43 in. |
| Width | 1860 mm 73.23 in. |
| Height | 1610 mm 63.39 in. |
| Wheelbase | 2740 mm 107.87 in. |
| Front overhang | 942 mm 37.09 in. |
| Rear overhang | 1029 mm 40.51 in. |
| Ride height (ground clearance) | 180 mm 7.09 in. |
| Minimum turning circle (turning diameter) | 10.4 m 34.12 ft. |
| Drivetrain, brakes and suspension specs | |
| Drivetrain Architecture | The Internal combustion engine (ICE) drives the front wheels of the vehicle. Two electric motors drive the front wheels. There is an ability for running in full electric or mixed mode. There are parallel and serial hybrid modes. |
| Drive wheel | Front wheel drive |
| Number of gears and type of gearbox | automatic transmission Multimode |
| Rear suspension | Independent multi-link suspension |
| Front brakes | Ventilated discs |
| Rear brakes | Disc |
| Assisting systems | ABS (Anti-lock braking system) 4-wheel steering (4WS, active rear steering) |
| Steering type | Steering rack and pinion |
| Power steering | Electric Steering |
| Wheel rims size | 20 |
| What is the body type, Renault Rafale? | Coupe, SUV, 5 Doors, 5 Seats |
|---|---|
| What is the fuel economy, Renault Rafale 1.2 (200 Hp) E-Tech Full Hybrid Multi-Mode? | 4.7 l/100 km 50 US mpg 60.1 UK mpg 21.3 km/l |
| How ECO is the car, Renault Rafale 1.2 (200 Hp) E-Tech Full Hybrid Multi-Mode? | 105 g/km CO2 Euro 6d |
| How much power, Renault Rafale Coupe, SUV 2024 1.2 (200 Hp) E-Tech Full Hybrid Multi-Mode? | 200 Hp, 410 Nm 302.4 lb.-ft. |
| What is the engine size, Renault Rafale Coupe, SUV 2024 1.2 (200 Hp) E-Tech Full Hybrid Multi-Mode? | 1.2 l 1199 cm3 73.17 cu. in. |
| How many cylinders, 2024 Renault 1.2 (200 Hp) E-Tech Full Hybrid Multi-Mode? | 3, Inline |
| What is the drivetrain, Renault Rafale Coupe, SUV 2024 1.2 (200 Hp) E-Tech Full Hybrid Multi-Mode? | Front wheel drive. FHEV (Full Hybrid Electric Vehicle). The Internal combustion engine (ICE) drives the front wheels of the vehicle. Two electric motors drive the front wheels. There is an ability for running in full electric or mixed mode. There are parallel and serial hybrid modes. |
| How long is this vehicle, 2024 Renault Rafale Coupe, SUV? | 4710 mm 185.43 in. |
| How wide is the vehicle, 2024 Renault Rafale Coupe, SUV? | 1860 mm 73.23 in. |
| What is the curb weight, 2024 Renault Rafale 1.2 (200 Hp) E-Tech Full Hybrid Multi-Mode? | 1653 kg 3644.24 lbs. |
| How much trunk (boot) space, 2024 Renault Rafale Coupe, SUV? | 647 l 22.85 cu. ft. |
| How many gears, What type is the gearbox, 2024 Renault Rafale 1.2 (200 Hp) E-Tech Full Hybrid Multi-Mode? | automatic transmission Multimode |
