| General information | |
|---|---|
| Brand | Rivian |
| Model | R1T |
| Generation | R1T |
| Type (Engine) | Large Pack 135 kWh (835 Hp) AWD Quad Motor |
| Start of production | September, 2021 year |
| Powertrain Architecture | BEV (Electric Vehicle) |
| Body type | Pick-up |
| Seats | 5 |
| Doors | 4 |
| Performance specs | |
| Fuel Type | Electricity |
| Acceleration 0 – 60 mph | 3 sec |
| Maximum speed | 201 km/h 124.9 mph |
| Weight-to-power ratio | 3.2 kg/Hp, 312.7 Hp/tonne |
| Weight-to-torque ratio | 2.2 kg/Nm, 461 Nm/tonne |
| Electric cars and hybrids specs | |
| Gross battery capacity | 135 kWh |
| Battery voltage | 400 V |
| Battery technology | Lithium-ion (Li-Ion) |
| Battery location | Below the floor |
| All-electric range (EPA) | 528 km 328.08 mi |
| Charging ports |  Log in to see. |
| Electric motor 1 | |
| Electric motor location | Front axle, Transverse |
| Electric motor type | Synchronous |
| Electric motor 2 | |
| Electric motor location | Front axle, Transverse |
| Electric motor type | Synchronous |
| Electric motor 3 | |
| Electric motor location | Rear axle, Transverse |
| Electric motor type | Synchronous |
| Electric motor 4 | |
| Electric motor location | Rear axle, Transverse |
| Electric motor type | Synchronous |
| System power | 835 Hp |
| System torque | 1231 Nm 907.94 lb.-ft. |
|
|
|
| Space, Volume and weights | |
| Kerb Weight | 2670 kg 5886.34 lbs. |
| Max. weight | 3470 kg 7650.04 lbs. |
| Max load | 800 kg 1763.7 lbs. |
| Trunk (boot) space – minimum | 1756 l 62.01 cu. ft. |
| Permitted trailer load with brakes (12%) | 5000 kg 11023.11 lbs. |
| Dimensions | |
| Length | 5514 mm 217.09 in. |
| Width with mirrors folded | 2078 mm 81.81 in. |
| Height | 1986 mm 78.19 in. |
| Wheelbase | 3450 mm 135.83 in. |
| Ride height (ground clearance) | 200-378 mm 7.87 – 14.88 in. |
| Approach angle | 35.5° |
| Departure angle | 30° |
| Ramp-over (brakeover) angle | 26.4° |
| Climb angle | 45° |
| Wading depth | 1095 mm 43.11 in. |
| Drivetrain, brakes and suspension specs | |
| Drivetrain Architecture | Four electric motors drive each wheel individually. |
| Drive wheel | All wheel drive (4×4) |
| Number of gears and type of gearbox | 1 gears, automatic transmission |
| Front suspension | Double wishbone, Air suspension |
| Rear suspension | Independent multi-link suspension, Air suspension |
| Front brakes | Ventilated discs |
| Rear brakes | Ventilated discs |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Power steering | Electric Steering |
| Tires size | 275/65 R20; 275/55 R21; 275/50 R22 |
| Wheel rims size | 20; 21; 22 |
| What is the body type, Rivian R1T? | Pick-up, 4 Doors, 5 Seats |
|---|---|
| What is the range of pure electric driving, Large Pack 135 kWh (835 Hp) AWD Quad Motor? | 528 km 328.08 mi |
| How fast is the car, 2021 R1T Large Pack 135 kWh (835 Hp) AWD Quad Motor? | 201 km/h | 124.9 mph 0-60 mph: 3 sec |
| How much power, Rivian R1T Pick-up 2021 Large Pack 135 kWh (835 Hp) AWD Quad Motor? | 835 Hp, 1231 Nm 907.94 lb.-ft. |
| What is the drivetrain, Rivian R1T Pick-up 2021 Large Pack 135 kWh (835 Hp) AWD Quad Motor? | All wheel drive (4×4). BEV (Electric Vehicle). Four electric motors drive each wheel individually. |
| How long is this vehicle, 2021 Rivian R1T Pick-up? | 5514 mm 217.09 in. |
| How wide is the vehicle, 2021 Rivian R1T Pick-up? | 2078 mm 81.81 in. |
| What is the curb weight, 2021 Rivian R1T Large Pack 135 kWh (835 Hp) AWD Quad Motor? | 2670 kg 5886.34 lbs. |
| What is the gross weight, 2021 Rivian R1T Large Pack 135 kWh (835 Hp) AWD Quad Motor? | 3470 kg 7650.04 lbs. |
| How much trunk (boot) space, 2021 Rivian R1T Pick-up? | 1756 l 62.01 cu. ft. |
| How many gears, What type is the gearbox, 2021 Rivian R1T Large Pack 135 kWh (835 Hp) AWD Quad Motor? | 1, automatic transmission |
