| General information | |
|---|---|
| Brand | Saab |
| Model | 9-3 |
| Generation | 9-3 Sedan II (facelift 2007) |
| Type (Engine) | 1.9 TiD (150 Hp) |
| Start of production | September, 2007 year |
| End of production | December, 2010 year |
| Powertrain Architecture | Internal Combustion engine |
| Body type | Sedan |
| Seats | 5 |
| Doors | 4 |
| Performance specs | |
| Fuel consumption (economy) – urban (NEDC) | 7.7 l/100 km 30.5 US mpg 36.7 UK mpg 13 km/l |
| Fuel consumption (economy) – extra urban (NEDC) | 4.7 l/100 km 50 US mpg 60.1 UK mpg 21.3 km/l |
| Fuel consumption (economy) – combined (NEDC) | 5.8 l/100 km 40.6 US mpg 48.7 UK mpg 17.2 km/l |
| CO2 emissions (NEDC) | 157 g/km |
| Fuel Type | Diesel |
| Acceleration 0 – 100 km/h | 9.5 sec |
| Acceleration 0 – 62 mph | 9.5 sec |
| Acceleration 0 – 60 mph (Calculated by Auto-Data.net) | 9 sec |
| Maximum speed | 210 km/h 130.49 mph |
| Emission standard | Euro 4 |
| Weight-to-power ratio | 10.6 kg/Hp, 94.6 Hp/tonne |
| Weight-to-torque ratio | 5 kg/Nm, 201.9 Nm/tonne |
| Engine specs | |
| Power | 150 Hp @ 4000 rpm. |
| Power per litre | 78.5 Hp/l |
| Torque | 320 Nm @ 2000-2750 rpm. 236.02 lb.-ft. @ 2000-2750 rpm. |
| Engine layout | Front, Transverse |
| Engine Model/Code | Z19DTH |
| Engine displacement | 1910 cm3 116.56 cu. in. |
| Number of cylinders | 4 |
| Engine configuration | Inline |
| Cylinder Bore | 82 mm 3.23 in. |
| Piston Stroke | 90.4 mm 3.56 in. |
| Compression ratio | 17.5:1 |
| Number of valves per cylinder | 4 |
| Fuel injection system | Diesel Commonrail |
| Engine aspiration | Turbocharger, Intercooler |
| Valvetrain | DOHC |
| Engine oil capacity | 4.6 l 4.86 US qt | 4.05 UK qt |
| Engine oil specification |  Log in to see. |
| Coolant | 7.4 l 7.82 US qt | 6.51 UK qt |
| Engine systems | Particulate filter |
|
|
|
| Space, Volume and weights | |
| Kerb Weight | 1585 kg 3494.33 lbs. |
| Max. weight | 2030 kg 4475.38 lbs. |
| Max load | 445 kg 981.06 lbs. |
| Trunk (boot) space – minimum | 425 l 15.01 cu. ft. |
| Fuel tank capacity | 58 l 15.32 US gal | 12.76 UK gal |
| Max. roof load | 100 kg 220.46 lbs. |
| Permitted trailer load with brakes (12%) | 1600 kg 3527.4 lbs. |
| Permitted trailer load without brakes | 750 kg 1653.47 lbs. |
| Dimensions | |
| Length | 4647 mm 182.95 in. |
| Width | 1762 mm 69.37 in. |
| Width including mirrors | 2038 mm 80.24 in. |
| Height | 1450 mm 57.09 in. |
| Wheelbase | 2675 mm 105.31 in. |
| Front track | 1524 mm 60 in. |
| Rear (Back) track | 1506 mm 59.29 in. |
| Front overhang | 981 mm 38.62 in. |
| Rear overhang | 991 mm 39.02 in. |
| Ride height (ground clearance) | 127 mm 5 in. |
| Minimum turning circle (turning diameter) | 10.8 m 35.43 ft. |
| Drivetrain, brakes and suspension specs | |
| Drivetrain Architecture | The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
| Drive wheel | Front wheel drive |
| Number of gears and type of gearbox | 6 gears, manual transmission |
| Front suspension | Independent, type McPherson with coil spring and anti-roll bar |
| Rear suspension | Independent multi-link spring suspension with stabilizer |
| Front brakes | Ventilated discs, 302 mm |
| Rear brakes | Ventilated discs, 292 mm |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Power steering | Hydraulic Steering |
| Tires size | 215/65 R16; 225/50 R17; 235/45 R17; 225/45 R18; 235/45 R18; 235/40 R19 |
| Wheel rims size | 6.5J x 16; 7J x 17; 7.5J x 17; 7.5J x 18; 8J x 19 |
| What is the body type, Saab 9-3 Sedan II (facelift 2007)? | Sedan, 4 Doors, 5 Seats |
|---|---|
| What is the fuel economy, Saab 9-3 Sedan II (facelift 2007) 1.9 TiD (150 Hp)? | 5.8 l/100 km 40.6 US mpg 48.7 UK mpg 17.2 km/l |
| How ECO is the car, Saab 9-3 1.9 TiD (150 Hp)? | 157 g/km CO2 Euro 4 |
| How fast is the car, 2007 9-3 Sedan II (facelift 2007) 1.9 TiD (150 Hp)? | 210 km/h | 130.49 mph 0-100 km/h: 9.5 sec 0-60 mph: 9 sec |
| How much power, Saab 9-3 Sedan 2007 1.9 TiD (150 Hp)? | 150 Hp, 320 Nm 236.02 lb.-ft. |
| What is the engine size, Saab 9-3 Sedan 2007 1.9 TiD (150 Hp)? | 1.9 l 1910 cm3 116.56 cu. in. |
| How many cylinders, 2007 Saab 1.9 TiD (150 Hp)? | 4, Inline |
| What is the drivetrain, Saab 9-3 Sedan II (facelift 2007) Sedan 2007 1.9 TiD (150 Hp)? | Front wheel drive. Internal Combustion engine. The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
| How long is this vehicle, 2007 Saab 9-3 Sedan? | 4647 mm 182.95 in. |
| How wide is the vehicle, 2007 Saab 9-3 Sedan? | 1762 mm 69.37 in. |
| What is the curb weight, 2007 Saab 9-3 Sedan II (facelift 2007) 1.9 TiD (150 Hp)? | 1585 kg 3494.33 lbs. |
| What is the gross weight, 2007 Saab 9-3 Sedan II (facelift 2007) 1.9 TiD (150 Hp)? | 2030 kg 4475.38 lbs. |
| How much trunk (boot) space, 2007 Saab 9-3 Sedan? | 425 l 15.01 cu. ft. |
| How many gears, What type is the gearbox, 2007 Saab 9-3 Sedan II (facelift 2007) 1.9 TiD (150 Hp)? | 6, manual transmission |
