Saturn LS 2.2i 16V (139 Hp)

The Saturn LS, produced from 1999 to 2004, was a mid-size sedan representing a significant step forward for the then-young Saturn brand. Positioned above the SL and SC models, the LS aimed to provide a more refined and spacious offering in the competitive American family sedan market. While Saturn ultimately ceased operations in 2010, the LS remains a notable example of the brand’s attempt to establish a unique identity through innovative design and a customer-focused sales experience. The 2.2i 16V model, equipped with a 2.2-liter inline-four engine producing 139 horsepower, was a mainstay of the LS lineup.

Saturn LS 2.2i 16V: Overview and Market Position

The Saturn LS was designed to appeal to buyers seeking a comfortable, reliable, and reasonably priced sedan. It competed directly with established models like the Honda Accord, Toyota Camry, and Ford Taurus. The LS distinguished itself with its polymer body panels – a hallmark of Saturn vehicles – which were dent-resistant and offered a unique aesthetic. The 2.2i 16V variant, with its 16-valve engine, provided a balance of fuel efficiency and adequate performance for everyday driving. The LS was exclusively sold in North America, representing a key component of General Motors’ strategy to offer a distinct brand with a different approach to car sales and ownership.

Engine & Performance

The heart of the Saturn LS 2.2i 16V is a 2.2-liter (2198 cm3 or 134.13 cu. in.) inline-four cylinder engine. This naturally aspirated engine, designated the L61, produces 139 horsepower at 5200 rpm and 193 Nm (142.35 lb.-ft.) of torque at 4400 rpm. The engine features multi-port fuel injection and a double overhead camshaft (DOHC) valvetrain, contributing to its relatively efficient operation. Power is delivered to the front wheels via a 5-speed manual transmission. Acceleration from 0 to 60 mph is achieved in approximately 9 seconds, while 0-100 km/h takes 9.5 seconds. The LS 2.2i 16V has a top speed of 170 km/h (105.63 mph). The engine’s power-to-weight ratio is 9.6 kg/Hp, and the torque-to-weight ratio is 6.9 kg/Nm. Fuel economy figures are rated at 9.4 l/100 km (25 US mpg) in urban conditions, 7.1 l/100 km (33.1 US mpg) on the highway, and 8.1 l/100 km (29 US mpg) combined.

Design & Features

The Saturn LS is a four-door sedan with a relatively conservative, yet modern, design for its time. The body features the signature Saturn polymer panels, which were colorfast and resistant to minor dents and scratches. The interior offers seating for five passengers and provides a comfortable and functional cabin. Standard features included air conditioning, power windows and locks, and an AM/FM stereo. Safety features, increasingly important in the early 2000s, included an anti-lock braking system (ABS). The LS offered a trunk capacity of 495 liters (17.48 cu. ft.), providing ample space for luggage and cargo. The vehicle’s dimensions are: length 4835 mm (190.35 in), width 1755 mm (69.09 in), height 1430 mm (56.3 in), and wheelbase 2705 mm (106.5 in). The LS utilized a steering rack and pinion system with hydraulic power steering for responsive handling.

Technical Specifications

General Information
BrandSaturn
ModelLS
GenerationLS
Type (Engine)2.2i 16V (139 Hp)
Start of productionMay, 1999
End of productionJune, 2004
Powertrain ArchitectureInternal Combustion engine
Body typeSedan
Seats5
Doors4
Performance Specs
Fuel consumption (urban)9.4 l/100 km (25 US mpg)
Fuel consumption (extra urban)7.1 l/100 km (33.1 US mpg)
Fuel consumption (combined)8.1 l/100 km (29 US mpg)
Fuel TypePetrol (Gasoline)
Acceleration 0 – 100 km/h9.5 sec
Acceleration 0 – 62 mph9.5 sec
Acceleration 0 – 60 mph9 sec
Maximum speed170 km/h (105.63 mph)
Weight-to-power ratio9.6 kg/Hp
Weight-to-torque ratio6.9 kg/Nm
Engine Specs
Power139 Hp @ 5200 rpm
Power per litre63.2 Hp/l
Torque193 Nm @ 4400 rpm (142.35 lb.-ft. @ 4400 rpm)
Engine layoutFront, Transverse
Engine Model/CodeL61
Engine displacement2198 cm3 (134.13 cu. in.)
Number of cylinders4
Engine configurationInline
Cylinder Bore86 mm (3.39 in.)
Piston Stroke94.6 mm (3.72 in.)
Compression ratio9.5:1
Number of valves per cylinder4
Fuel injection systemMulti-port manifold injection
Engine aspirationNaturally aspirated
ValvetrainDOHC
Engine oil capacity4.7 l (4.97 US qt | 4.14 UK qt)
Coolant capacity7 l (7.4 US qt | 6.16 UK qt)
Space, Volume and Weights
Kerb Weight1335 kg (2943.17 lbs.)
Trunk (boot) space (minimum)495 l (17.48 cu. ft.)
Fuel tank capacity60 l (15.85 US gal | 13.2 UK gal)
Dimensions
Length4835 mm (190.35 in.)
Width1755 mm (69.09 in.)
Height1430 mm (56.3 in.)
Wheelbase2705 mm (106.5 in.)
Front track1520 mm (59.84 in.)
Rear track1510 mm (59.45 in.)
Drivetrain, Brakes and Suspension
Drivetrain ArchitectureFront wheel drive, Internal Combustion engine
Drive wheelFront wheel drive
Number of gears and type of gearbox5 gears, manual transmission
Front suspensionSpring Strut
Rear suspensionCoil spring
Front brakesVentilated discs
Rear brakesDrum
Assisting systemsABS (Anti-lock braking system)
Steering typeSteering rack and pinion
Power steeringHydraulic Steering
Tires size195/60 R15
