| General information | |
|---|---|
| Brand | Scion |
| Model | iM |
| Generation | iM |
| Type (Engine) | 1.8 (137 Hp) |
| Start of production | 2015 year |
| End of production | 2016 year |
| Powertrain Architecture | Internal Combustion engine |
| Body type | Hatchback |
| Seats | 5 |
| Doors | 5 |
| Performance specs | |
| Fuel consumption (economy) – urban | 8.7 l/100 km 27 US mpg 32.5 UK mpg 11.5 km/l |
| Fuel consumption (economy) – extra urban | 6.5 l/100 km 36.2 US mpg 43.5 UK mpg 15.4 km/l |
| Fuel consumption (economy) – combined | 7.6 l/100 km 30.9 US mpg 37.2 UK mpg 13.2 km/l |
| Fuel Type | Petrol (Gasoline) |
| Weight-to-power ratio | 9.7 kg/Hp, 102.6 Hp/tonne |
| Weight-to-torque ratio | 7.8 kg/Nm, 128.1 Nm/tonne |
| Engine specs | |
| Power | 137 Hp @ 6100 rpm. |
| Power per litre | 76.2 Hp/l |
| Torque | 171 Nm @ 4000 rpm. 126.12 lb.-ft. @ 4000 rpm. |
| Engine layout | Front, Transverse |
| Engine Model/Code | 2ZR-FAE |
| Engine displacement | 1798 cm3 109.72 cu. in. |
| Number of cylinders | 4 |
| Engine configuration | Inline |
| Cylinder Bore | 80.5 mm 3.17 in. |
| Piston Stroke | 88.3 mm 3.48 in. |
| Compression ratio | 10.6:1 |
| Number of valves per cylinder | 4 |
| Fuel injection system | Multi-port manifold injection |
| Engine aspiration | Naturally aspirated engine |
| Valvetrain | DOHC |
| Engine oil capacity | 4.2 l 4.44 US qt | 3.7 UK qt |
| Engine oil specification |  Log in to see. |
| Coolant | 5.6 l 5.92 US qt | 4.93 UK qt |
|
|
|
| Space, Volume and weights | |
| Kerb Weight | 1335 kg 2943.17 lbs. |
| Trunk (boot) space – minimum | 589 l 20.8 cu. ft. |
| Fuel tank capacity | 53 l 14 US gal | 11.66 UK gal |
| Dimensions | |
| Length | 4331 mm 170.51 in. |
| Width | 1760 mm 69.29 in. |
| Height | 1405 mm 55.31 in. |
| Wheelbase | 2601 mm 102.4 in. |
| Front track | 1514 mm 59.61 in. |
| Rear (Back) track | 1506 mm 59.29 in. |
| Ride height (ground clearance) | 140 mm 5.51 in. |
| Drag coefficient (Cd) | 0.30 |
| Minimum turning circle (turning diameter) | 11.4 m 37.4 ft. |
| Drivetrain, brakes and suspension specs | |
| Drivetrain Architecture | The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
| Drive wheel | Front wheel drive |
| Number of gears and type of gearbox | 6 gears, manual transmission |
| Front suspension | Independent type McPherson |
| Rear suspension | Double wishbone |
| Front brakes | Ventilated discs |
| Rear brakes | Disc |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Power steering | Electric Steering |
| Tires size | 225/45 R17 |
| Wheel rims size | 7.0J x 17 |
| What is the body type, Scion iM? | Hatchback, 5 Doors, 5 Seats |
|---|---|
| What is the fuel economy, Scion iM 1.8 (137 Hp)? | 7.6 l/100 km 30.9 US mpg 37.2 UK mpg 13.2 km/l |
| How much power, Scion iM Hatchback 2015 1.8 (137 Hp)? | 137 Hp, 171 Nm 126.12 lb.-ft. |
| What is the engine size, Scion iM Hatchback 2015 1.8 (137 Hp)? | 1.8 l 1798 cm3 109.72 cu. in. |
| How many cylinders, 2015 Scion 1.8 (137 Hp)? | 4, Inline |
| What is the drivetrain, Scion iM Hatchback 2015 1.8 (137 Hp)? | Front wheel drive. Internal Combustion engine. The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
| How long is this vehicle, 2015 Scion iM Hatchback? | 4331 mm 170.51 in. |
| How wide is the vehicle, 2015 Scion iM Hatchback? | 1760 mm 69.29 in. |
| What is the curb weight, 2015 Scion iM 1.8 (137 Hp)? | 1335 kg 2943.17 lbs. |
| How much trunk (boot) space, 2015 Scion iM Hatchback? | 589 l 20.8 cu. ft. |
| How many gears, What type is the gearbox, 2015 Scion iM 1.8 (137 Hp)? | 6, manual transmission |
