| General information | |
|---|---|
| Brand | Seat |
| Model | Altea |
| Generation | Altea XL (facelift 2009) |
| Type (Engine) | 1.6 (102 Hp) LPG |
| Start of production | 2009 year |
| End of production | August, 2015 year |
| Powertrain Architecture | Internal Combustion engine |
| Body type | MPV |
| Seats | 5 |
| Doors | 5 |
| Performance specs | |
| Fuel consumption (economy) – urban | 10.0 l/100 km 23.5 US mpg 28.2 UK mpg 10 km/l |
| Fuel consumption (economy) – urban (LPG) | 13.1 l/100 km |
| Fuel consumption (economy) – extra urban | 6.1 l/100 km 38.6 US mpg 46.3 UK mpg 16.4 km/l |
| Fuel consumption (economy) – extra urban (LPG) | 7.8 l/100 km |
| Fuel consumption (economy) – combined | 7.5 l/100 km 31.4 US mpg 37.7 UK mpg 13.3 km/l |
| Fuel consumption (economy) – combined (LPG) | 9.8 l/100 km |
| CO2 emissions | 174 g/km |
| CO2 emissions (LPG) | 159 g/km |
| Fuel Type | Petrol / LPG |
| Acceleration 0 – 100 km/h | 13.4 sec |
| Acceleration 0 – 62 mph | 13.4 sec |
| Acceleration 0 – 100 km/h (LPG) | 14.0 sec |
| Acceleration 0 – 60 mph (Calculated by Auto-Data.net) | 12.7 sec |
| Maximum speed | 181 km/h 112.47 mph |
| Maximum speed (LPG) | 178 km/h |
| Emission standard | Euro 5 |
| Weight-to-power ratio | 14.7 kg/Hp, 68.2 Hp/tonne |
| Weight-to-torque ratio | 10.1 kg/Nm, 99 Nm/tonne |
| Engine specs | |
| Power | 102 Hp @ 5600 rpm. |
| Power per litre | 63.9 Hp/l |
| Torque | 148 Nm @ 3800 rpm. 109.16 lb.-ft. @ 3800 rpm. |
| Engine layout | Front, Transverse |
| Engine Model/Code | CHGA |
| Engine displacement | 1595 cm3 97.33 cu. in. |
| Number of cylinders | 4 |
| Engine configuration | Inline |
| Cylinder Bore | 81 mm 3.19 in. |
| Piston Stroke | 77.4 mm 3.05 in. |
| Compression ratio | 10.3:1 |
| Number of valves per cylinder | 2 |
| Fuel injection system | Multi-port manifold injection |
| Engine aspiration | Naturally aspirated engine |
| Engine oil capacity | 4.5 l 4.76 US qt | 3.96 UK qt |
| Engine oil specification |  Log in to see. |
|
|
|
| Space, Volume and weights | |
| Kerb Weight | 1495 kg 3295.91 lbs. |
| Max. weight | 2039 kg 4495.23 lbs. |
| Max load | 544 kg 1199.31 lbs. |
| Trunk (boot) space – minimum | 446 l 15.75 cu. ft. |
| Fuel tank capacity | 55 l 14.53 US gal | 12.1 UK gal |
| Fuel tank capacity (LPG) | 49 l |
| Dimensions | |
| Length | 4469 mm 175.94 in. |
| Width | 1768 mm 69.61 in. |
| Height | 1581 mm 62.24 in. |
| Wheelbase | 2578 mm 101.5 in. |
| Front track | 1527-1541 mm 60.12 – 60.67 in. |
| Rear (Back) track | 1503-1517 mm 59.17 – 59.72 in. |
| Minimum turning circle (turning diameter) | 10.7 m 35.1 ft. |
| Drivetrain, brakes and suspension specs | |
| Drivetrain Architecture | The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
| Drive wheel | Front wheel drive |
| Number of gears and type of gearbox | 5 gears, manual transmission |
| Front suspension | Independent, type McPherson with coil spring and anti-roll bar |
| Rear suspension | Independent multi-link suspension |
| Front brakes | Ventilated discs |
| Rear brakes | Disc |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Tires size | 195/65 R15 91H; 205/55 R16 91V; 225/45 R17 91W 225/40 R18 92Y |
| Wheel rims size | 6J x 15 ET47; 6.5J x 16 ET50; 7J x 17 ET54; 7.5J x 18 ET51 |
| What is the body type, Seat Altea XL (facelift 2009)? | MPV, 5 Doors, 5 Seats |
|---|---|
| What is the fuel economy, Seat Altea XL (facelift 2009) 1.6 (102 Hp) LPG? | 7.5 l/100 km 31.4 US mpg 37.7 UK mpg 13.3 km/l |
| How ECO is the car, Seat Altea 1.6 (102 Hp) LPG? | 174 g/km CO2 Euro 5 |
| How fast is the car, 2009 Altea XL (facelift 2009) 1.6 (102 Hp) LPG? | 181 km/h | 112.47 mph 0-100 km/h: 13.4 sec 0-60 mph: 12.7 sec |
| How much power, Seat Altea MPV 2009 1.6 (102 Hp) LPG? | 102 Hp, 148 Nm 109.16 lb.-ft. |
| What is the engine size, Seat Altea MPV 2009 1.6 (102 Hp) LPG? | 1.6 l 1595 cm3 97.33 cu. in. |
| How many cylinders, 2009 Seat 1.6 (102 Hp) LPG? | 4, Inline |
| What is the drivetrain, Seat Altea XL (facelift 2009) MPV 2009 1.6 (102 Hp) LPG? | Front wheel drive. Internal Combustion engine. The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
| How long is this vehicle, 2009 Seat Altea MPV? | 4469 mm 175.94 in. |
| How wide is the vehicle, 2009 Seat Altea MPV? | 1768 mm 69.61 in. |
| What is the curb weight, 2009 Seat Altea XL (facelift 2009) 1.6 (102 Hp) LPG? | 1495 kg 3295.91 lbs. |
| What is the gross weight, 2009 Seat Altea XL (facelift 2009) 1.6 (102 Hp) LPG? | 2039 kg 4495.23 lbs. |
| How much trunk (boot) space, 2009 Seat Altea MPV? | 446 l 15.75 cu. ft. |
| How many gears, What type is the gearbox, 2009 Seat Altea XL (facelift 2009) 1.6 (102 Hp) LPG? | 5, manual transmission |
