| General information | |
|---|---|
| Brand | Seat |
| Model | Ibiza |
| Generation | Ibiza III |
| Type (Engine) | 1.9 TDi (101 Hp) |
| Start of production | 2002 year |
| End of production | 2006 year |
| Powertrain Architecture | Internal Combustion engine |
| Body type | Hatchback |
| Seats | 5 |
| Doors | 3-5 |
| Performance specs | |
| Fuel consumption (economy) – urban | 6.4 l/100 km 36.8 US mpg 44.1 UK mpg 15.6 km/l |
| Fuel consumption (economy) – extra urban | 4 l/100 km 58.8 US mpg 70.6 UK mpg 25 km/l |
| Fuel consumption (economy) – combined | 4.9 l/100 km 48 US mpg 57.6 UK mpg 20.4 km/l |
| Fuel Type | Diesel |
| Acceleration 0 – 100 km/h | 8.9 sec |
| Acceleration 0 – 62 mph | 8.9 sec |
| Acceleration 0 – 60 mph (Calculated by Auto-Data.net) | 8.5 sec |
| Maximum speed | 190 km/h 118.06 mph |
| Weight-to-power ratio | 11.3 kg/Hp, 88.6 Hp/tonne |
| Weight-to-torque ratio | 4.8 kg/Nm, 210.5 Nm/tonne |
| Engine specs | |
| Power | 101 Hp @ 4000 rpm. |
| Power per litre | 53.3 Hp/l |
| Torque | 240 Nm @ 1800 rpm. 177.01 lb.-ft. @ 1800 rpm. |
| Engine layout | Front, Transverse |
| Engine Model/Code | ATD, AXR |
| Engine displacement | 1896 cm3 115.7 cu. in. |
| Number of cylinders | 4 |
| Engine configuration | Inline |
| Cylinder Bore | 79.5 mm 3.13 in. |
| Piston Stroke | 95.5 mm 3.76 in. |
| Compression ratio | 19:1 |
| Number of valves per cylinder | 2 |
| Fuel injection system | Pump-nozzle (Unit Injector) |
| Engine aspiration | Turbocharger, Intercooler |
| Valvetrain | OHC |
| Engine oil capacity | 4.3 l 4.54 US qt | 3.78 UK qt |
| Engine oil specification |  Log in to see. |
| Coolant | 5 l 5.28 US qt | 4.4 UK qt |
|
|
|
| Space, Volume and weights | |
| Kerb Weight | 1140 kg 2513.27 lbs. |
| Trunk (boot) space – minimum | 265 l 9.36 cu. ft. |
| Trunk (boot) space – maximum | 1030 l 36.37 cu. ft. |
| Fuel tank capacity | 45 l 11.89 US gal | 9.9 UK gal |
| Dimensions | |
| Length | 3955 mm 155.71 in. |
| Width | 1700 mm 66.93 in. |
| Height | 1440 mm 56.69 in. |
| Wheelbase | 2460 mm 96.85 in. |
| Front track | 1435 mm 56.5 in. |
| Rear (Back) track | 1425 mm 56.1 in. |
| Drivetrain, brakes and suspension specs | |
| Drivetrain Architecture | The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
| Drive wheel | Front wheel drive |
| Number of gears and type of gearbox | 5 gears, manual transmission |
| Front suspension | Wishbone |
| Rear suspension | Spring Strut |
| Front brakes | Ventilated discs |
| Rear brakes | Disc |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Power steering | Hydraulic Steering |
| Tires size | 185/60 R14 |
| What is the body type, Seat Ibiza III? | Hatchback, 3-5 Doors, 5 Seats |
|---|---|
| What is the fuel economy, Seat Ibiza III 1.9 TDi (101 Hp)? | 4.9 l/100 km 48 US mpg 57.6 UK mpg 20.4 km/l |
| How fast is the car, 2002 Ibiza III 1.9 TDi (101 Hp)? | 190 km/h | 118.06 mph 0-100 km/h: 8.9 sec 0-60 mph: 8.5 sec |
| How much power, Seat Ibiza Hatchback 2002 1.9 TDi (101 Hp)? | 101 Hp, 240 Nm 177.01 lb.-ft. |
| What is the engine size, Seat Ibiza Hatchback 2002 1.9 TDi (101 Hp)? | 1.9 l 1896 cm3 115.7 cu. in. |
| How many cylinders, 2002 Seat 1.9 TDi (101 Hp)? | 4, Inline |
| What is the drivetrain, Seat Ibiza III Hatchback 2002 1.9 TDi (101 Hp)? | Front wheel drive. Internal Combustion engine. The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
| How long is this vehicle, 2002 Seat Ibiza Hatchback? | 3955 mm 155.71 in. |
| How wide is the vehicle, 2002 Seat Ibiza Hatchback? | 1700 mm 66.93 in. |
| What is the curb weight, 2002 Seat Ibiza III 1.9 TDi (101 Hp)? | 1140 kg 2513.27 lbs. |
| How much trunk (boot) space, 2002 Seat Ibiza Hatchback? | 265 – 1030 l 9.36 – 36.37 cu. ft. |
| How many gears, What type is the gearbox, 2002 Seat Ibiza III 1.9 TDi (101 Hp)? | 5, manual transmission |
