| General information | |
|---|---|
| Brand | Seat |
| Model | Leon |
| Generation | Leon II (1P, facelift 2009) |
| Type (Engine) | 1.6 MPI (102/98 Hp) LPG |
| Start of production | 2009 year |
| End of production | 2012 year |
| Powertrain Architecture | Internal Combustion engine |
| Body type | Hatchback |
| Seats | 5 |
| Doors | 5 |
| Performance specs | |
| Fuel consumption (economy) – urban | 9.9 l/100 km 23.8 US mpg 28.5 UK mpg 10.1 km/l |
| Fuel consumption (economy) – urban (LPG) | 12.9 l/100 km |
| Fuel consumption (economy) – extra urban | 5.8 l/100 km 40.6 US mpg 48.7 UK mpg 17.2 km/l |
| Fuel consumption (economy) – extra urban (LPG) | 7.4 l/100 km |
| Fuel consumption (economy) – combined | 7.3 l/100 km 32.2 US mpg 38.7 UK mpg 13.7 km/l |
| Fuel consumption (economy) – combined (LPG) | 9.5 l/100 km |
| CO2 emissions | 173 g/km |
| CO2 emissions (LPG) | 153 g/km |
| Fuel Type | Petrol / LPG |
| Acceleration 0 – 100 km/h | 12.2 sec |
| Acceleration 0 – 62 mph | 12.2 sec |
| Acceleration 0 – 100 km/h (LPG) | 12.6 sec |
| Acceleration 0 – 60 mph (Calculated by Auto-Data.net) | 11.6 sec |
| Maximum speed | 184 km/h 114.33 mph |
| Maximum speed (LPG) | 181 km/h |
| Emission standard | Euro 4 |
| Weight-to-power ratio | 11.1 kg/Hp, 90.3 Hp/tonne |
| Weight-to-torque ratio | 7.6 kg/Nm, 131 Nm/tonne |
| Engine specs | |
| Power | 102 Hp @ 5600 rpm. |
| Power per litre | 63.9 Hp/l |
| Power (LPG) | 98 Hp @ 5600 rpm. |
| Power per litre (LPG) | 61.4 Hp/l |
| Torque | 148 Nm @ 3800 rpm. 109.16 lb.-ft. @ 3800 rpm. |
| Torque (LPG) | 144 Nm @ 3800 rpm. |
| Engine layout | Front, Transverse |
| Engine Model/Code | CHGA |
| Engine displacement | 1595 cm3 97.33 cu. in. |
| Number of cylinders | 4 |
| Engine configuration | Inline |
| Cylinder Bore | 81 mm 3.19 in. |
| Piston Stroke | 77.4 mm 3.05 in. |
| Compression ratio | 10.5:1 |
| Number of valves per cylinder | 2 |
| Fuel injection system | Multi-port manifold injection |
| Engine aspiration | Naturally aspirated engine |
| Engine oil capacity | 4.1 l 4.33 US qt | 3.61 UK qt |
| Engine oil specification |  Log in to see. |
| Coolant | 8 l 8.45 US qt | 7.04 UK qt |
|
|
|
| Space, Volume and weights | |
| Kerb Weight | 1130 kg 2491.22 lbs. |
| Max. weight | 1836 kg 4047.69 lbs. |
| Max load | 706 kg 1556.46 lbs. |
| Trunk (boot) space – minimum | 341 l 12.04 cu. ft. |
| Trunk (boot) space – maximum | 1166 l 41.18 cu. ft. |
| Fuel tank capacity | 55 l 14.53 US gal | 12.1 UK gal |
| Max. roof load | 75 kg 165.35 lbs. |
| Permitted trailer load with brakes (8%) | 1500 kg 3306.93 lbs. |
| Permitted trailer load with brakes (12%) | 1200 kg 2645.55 lbs. |
| Permitted trailer load without brakes | 670 kg 1477.1 lbs. |
| Dimensions | |
| Length | 4315 mm 169.88 in. |
| Width | 1768 mm 69.61 in. |
| Height | 1459 mm 57.44 in. |
| Wheelbase | 2578 mm 101.5 in. |
| Front track | 1539 mm 60.59 in. |
| Rear (Back) track | 1523 mm 59.96 in. |
| Front overhang | 949 mm 37.36 in. |
| Rear overhang | 788 mm 31.02 in. |
| Minimum turning circle (turning diameter) | 10.7 m 35.1 ft. |
| Drivetrain, brakes and suspension specs | |
| Drivetrain Architecture | The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
| Drive wheel | Front wheel drive |
| Number of gears and type of gearbox | 5 gears, manual transmission |
| Front suspension | Independent, type McPherson with coil spring and anti-roll bar |
| Rear suspension | Independent multi-link suspension |
| Front brakes | Ventilated discs |
| Rear brakes | Disc |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Power steering | Electric Steering |
| Tires size | 205/55 R16 |
| Wheel rims size | 6.5J x 16 |
