| General information | |
|---|---|
| Brand | SsangYong |
| Model | Korando Sports |
| Generation | Korando Sports |
| Type (Engine) | 2.2 eXDi 220 VGT (178 Hp) 4WD AISIN |
| Start of production | 2017 year |
| End of production | 2023 year |
| Powertrain Architecture | Internal Combustion engine |
| Body type | Pick-up |
| Seats | 5 |
| Doors | 4 |
| Performance specs | |
| Fuel consumption (economy) – urban | 6.5 l/100 km 36.2 US mpg 43.5 UK mpg 15.4 km/l |
| Fuel consumption (economy) – extra urban | 9.9 l/100 km 23.8 US mpg 28.5 UK mpg 10.1 km/l |
| Fuel consumption (economy) – combined | 7.7 l/100 km 30.5 US mpg 36.7 UK mpg 13 km/l |
| CO2 emissions | 202 g/km |
| Fuel Type | Diesel |
| Maximum speed | 174 km/h 108.12 mph |
| Emission standard | Euro 6 |
| Weight-to-power ratio | 11.2 kg/Hp, 89.2 Hp/tonne |
| Weight-to-torque ratio | 5 kg/Nm, 200.5 Nm/tonne |
| Engine specs | |
| Power | 178 Hp @ 4000 rpm. |
| Power per litre | 82.5 Hp/l |
| Torque | 400 Nm @ 1400-2800 rpm. 295.02 lb.-ft. @ 1400-2800 rpm. |
| Engine layout | Front, Longitudinal |
| Engine Model/Code | D22DTR |
| Engine displacement | 2157 cm3 131.63 cu. in. |
| Number of cylinders | 4 |
| Engine configuration | Inline |
| Cylinder Bore | 86.2 mm 3.39 in. |
| Piston Stroke | 92.4 mm 3.64 in. |
| Compression ratio | 15.5:1 |
| Number of valves per cylinder | 4 |
| Fuel injection system | Diesel Commonrail |
| Engine aspiration | Turbocharger, Intercooler |
| Valvetrain | DOHC |
| Engine oil capacity | 6 l 6.34 US qt | 5.28 UK qt |
| Engine oil specification |  Log in to see. |
| Coolant | 8.5 l 8.98 US qt | 7.48 UK qt |
| Engine systems | Particulate filter |
|
|
|
| Space, Volume and weights | |
| Kerb Weight | 1995-2059 kg 4398.22 – 4539.32 lbs. |
| Max. weight | 2740 kg 6040.67 lbs. |
| Max load | 681-745 kg 1501.35 – 1642.44 lbs. |
| Fuel tank capacity | 75 l 19.81 US gal | 16.5 UK gal |
| Permitted trailer load with brakes (12%) | 2300 kg 5070.63 lbs. |
| Permitted trailer load without brakes | 750 kg 1653.47 lbs. |
| Dimensions | |
| Length | 4990 mm 196.46 in. |
| Width | 1910 mm 75.2 in. |
| Height | 1780-1790 mm 70.08 – 70.47 in. |
| Wheelbase | 3060 mm 120.47 in. |
| Front track | 1570 mm 61.81 in. |
| Rear (Back) track | 1570 mm 61.81 in. |
| Front overhang | 860 mm 33.86 in. |
| Rear overhang | 1070 mm 42.13 in. |
| Ride height (ground clearance) | 188-212 mm 7.4 – 8.35 in. |
| Minimum turning circle (turning diameter) | 11.9 m 39.04 ft. |
| Approach angle | 25° |
| Departure angle | 25° |
| Ramp-over (brakeover) angle | 20° |
| Drivetrain, brakes and suspension specs | |
| Drivetrain Architecture | The Internal combustion engine (ICE) drives the rear wheels permanently, and the front wheels are driven through an electrically or mechanically operated clutch if necessary. |
| Drive wheel | All wheel drive (4×4) |
| Number of gears and type of gearbox | 6 gears, automatic transmission AISIN |
| Front suspension | Double wishbone, Transverse stabilizer |
| Rear suspension | Independent multi-link spring suspension with stabilizer |
| Front brakes | Ventilated discs |
| Rear brakes | Disc |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Power steering | Hydraulic Steering |
| Tires size | 225/75 R16; 255/60 R18 |
| Wheel rims size | 7.0J x 16; 7.5J x 18 |
| What is the body type, SsangYong Korando Sports? | Pick-up, 4 Doors, 5 Seats |
|---|---|
| What is the fuel economy, SsangYong Korando Sports 2.2 eXDi 220 VGT (178 Hp) 4WD AISIN? | 7.7 l/100 km 30.5 US mpg 36.7 UK mpg 13 km/l |
| How ECO is the car, SsangYong Korando Sports 2.2 eXDi 220 VGT (178 Hp) 4WD AISIN? | 202 g/km CO2 Euro 6 |
| How fast is the car, 2017 Korando Sports 2.2 eXDi 220 VGT (178 Hp) 4WD AISIN? | 174 km/h | 108.12 mph |
| How much power, SsangYong Korando Sports Pick-up 2017 2.2 eXDi 220 VGT (178 Hp) 4WD AISIN? | 178 Hp, 400 Nm 295.02 lb.-ft. |
| What is the engine size, SsangYong Korando Sports Pick-up 2017 2.2 eXDi 220 VGT (178 Hp) 4WD AISIN? | 2.2 l 2157 cm3 131.63 cu. in. |
| How many cylinders, 2017 SsangYong 2.2 eXDi 220 VGT (178 Hp) 4WD AISIN? | 4, Inline |
| What is the drivetrain, SsangYong Korando Sports Pick-up 2017 2.2 eXDi 220 VGT (178 Hp) 4WD AISIN? | All wheel drive (4×4). Internal Combustion engine. The Internal combustion engine (ICE) drives the rear wheels permanently, and the front wheels are driven through an electrically or mechanically operated clutch if necessary. |
| How long is this vehicle, 2017 SsangYong Korando Sports Pick-up? | 4990 mm 196.46 in. |
| How wide is the vehicle, 2017 SsangYong Korando Sports Pick-up? | 1910 mm 75.2 in. |
| What is the curb weight, 2017 SsangYong Korando Sports 2.2 eXDi 220 VGT (178 Hp) 4WD AISIN? | 1995-2059 kg 4398.22 – 4539.32 lbs. |
| What is the gross weight, 2017 SsangYong Korando Sports 2.2 eXDi 220 VGT (178 Hp) 4WD AISIN? | 2740 kg 6040.67 lbs. |
| How many gears, What type is the gearbox, 2017 SsangYong Korando Sports 2.2 eXDi 220 VGT (178 Hp) 4WD AISIN? | 6, automatic transmission AISIN |
