| General information | |
|---|---|
| Brand | Subaru |
| Model | Legacy |
| Generation | Legacy V Station Wagon |
| Type (Engine) | 2.5i (170 Hp) AWD Lineartronic |
| Start of production | 2009 year |
| End of production | 2012 year |
| Powertrain Architecture | Internal Combustion engine |
| Body type | Station wagon (estate) |
| Seats | 5 |
| Doors | 5 |
| Performance specs | |
| Fuel consumption (economy) – urban | 11.1 l/100 km 21.2 US mpg 25.4 UK mpg 9 km/l |
| Fuel consumption (economy) – extra urban | 6.4 l/100 km 36.8 US mpg 44.1 UK mpg 15.6 km/l |
| Fuel consumption (economy) – combined | 8.1 l/100 km 29 US mpg 34.9 UK mpg 12.3 km/l |
| CO2 emissions | 188 g/km |
| Fuel Type | Petrol (Gasoline) |
| Acceleration 0 – 100 km/h | 10.3 sec |
| Acceleration 0 – 62 mph | 10.3 sec |
| Acceleration 0 – 60 mph (Calculated by Auto-Data.net) | 9.8 sec |
| Maximum speed | 205 km/h 127.38 mph |
| Emission standard | Euro 5 |
| Weight-to-power ratio | 9.3 kg/Hp, 107.3 Hp/tonne |
| Weight-to-torque ratio | 6.9 kg/Nm, 145.1 Nm/tonne |
| Engine specs | |
| Power | 170 Hp @ 5600 rpm. |
| Power per litre | 69.2 Hp/l |
| Torque | 230 Nm @ 4000 rpm. 169.64 lb.-ft. @ 4000 rpm. |
| Engine layout | Front, Longitudinal |
| Engine Model/Code | EJ253 |
| Engine displacement | 2457 cm3 149.94 cu. in. |
| Number of cylinders | 4 |
| Engine configuration | Boxer |
| Cylinder Bore | 99.5 mm 3.92 in. |
| Piston Stroke | 79 mm 3.11 in. |
| Compression ratio | 10:1 |
| Number of valves per cylinder | 4 |
| Fuel injection system | Multi-port manifold injection |
| Engine aspiration | Naturally aspirated engine |
| Valvetrain | SOHC |
| Engine oil capacity | 4.2 l 4.44 US qt | 3.7 UK qt |
| Engine oil specification |  Log in to see. |
| Coolant | 6.4 l 6.76 US qt | 5.63 UK qt |
|
|
|
| Space, Volume and weights | |
| Kerb Weight | 1585 kg 3494.33 lbs. |
| Max. weight | 2030 kg 4475.38 lbs. |
| Max load | 445 kg 981.06 lbs. |
| Trunk (boot) space – minimum | 526 l 18.58 cu. ft. |
| Trunk (boot) space – maximum | 1660 l 58.62 cu. ft. |
| Fuel tank capacity | 65 l 17.17 US gal | 14.3 UK gal |
| Max. roof load | 80 kg 176.37 lbs. |
| Permitted trailer load with brakes (12%) | 1800 kg 3968.32 lbs. |
| Permitted trailer load without brakes | 720 kg 1587.33 lbs. |
| Dimensions | |
| Length | 4775 mm 187.99 in. |
| Width | 1780 mm 70.08 in. |
| Height | 1535 mm 60.43 in. |
| Wheelbase | 2750 mm 108.27 in. |
| Front track | 1565 mm 61.61 in. |
| Rear (Back) track | 1570 mm 61.81 in. |
| Minimum turning circle (turning diameter) | 11.4 m 37.4 ft. |
| Drivetrain, brakes and suspension specs | |
| Drive wheel | All wheel drive (4×4) |
| Number of gears and type of gearbox | automatic transmission Lineartronic |
| Front suspension | Independent type McPherson |
| Rear suspension | Double wishbone |
| Front brakes | Ventilated discs |
| Rear brakes | Disc |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Tires size | 215/45 R17V |
| Wheel rims size | 7.5J x 17 |
| What is the body type, Subaru Legacy V Station Wagon? | Station wagon (estate), 5 Doors, 5 Seats |
|---|---|
| What is the fuel economy, Subaru Legacy V Station Wagon 2.5i (170 Hp) AWD Lineartronic? | 8.1 l/100 km 29 US mpg 34.9 UK mpg 12.3 km/l |
| How ECO is the car, Subaru Legacy 2.5i (170 Hp) AWD Lineartronic? | 188 g/km CO2 Euro 5 |
| How fast is the car, 2009 Legacy V Station Wagon 2.5i (170 Hp) AWD Lineartronic? | 205 km/h | 127.38 mph 0-100 km/h: 10.3 sec 0-60 mph: 9.8 sec |
| How much power, Subaru Legacy Station wagon (estate) 2009 2.5i (170 Hp) AWD Lineartronic? | 170 Hp, 230 Nm 169.64 lb.-ft. |
| What is the engine size, Subaru Legacy Station wagon (estate) 2009 2.5i (170 Hp) AWD Lineartronic? | 2.5 l 2457 cm3 149.94 cu. in. |
| How many cylinders, 2009 Subaru 2.5i (170 Hp) AWD Lineartronic? | 4, Boxer |
| What is the drivetrain, Subaru Legacy V Station Wagon Station wagon (estate) 2009 2.5i (170 Hp) AWD Lineartronic? | All wheel drive (4×4). Internal Combustion engine. |
| How long is this vehicle, 2009 Subaru Legacy Station wagon (estate)? | 4775 mm 187.99 in. |
| How wide is the vehicle, 2009 Subaru Legacy Station wagon (estate)? | 1780 mm 70.08 in. |
| What is the curb weight, 2009 Subaru Legacy V Station Wagon 2.5i (170 Hp) AWD Lineartronic? | 1585 kg 3494.33 lbs. |
| What is the gross weight, 2009 Subaru Legacy V Station Wagon 2.5i (170 Hp) AWD Lineartronic? | 2030 kg 4475.38 lbs. |
| How much trunk (boot) space, 2009 Subaru Legacy Station wagon (estate)? | 526 – 1660 l 18.58 – 58.62 cu. ft. |
| How many gears, What type is the gearbox, 2009 Subaru Legacy V Station Wagon 2.5i (170 Hp) AWD Lineartronic? | automatic transmission Lineartronic |
