| General information | |
|---|---|
| Brand | Suda |
| Model | SA01 |
| Generation | SA01 |
| Type (Engine) | 39.5 kWh (109 Hp) BEV |
| Start of production | November, 2020 year |
| Powertrain Architecture | BEV (Electric Vehicle) |
| Body type | Sedan |
| Seats | 5 |
| Doors | 4 |
| Performance specs | |
| Fuel Type | Electricity |
| Maximum speed | 130 km/h 80.78 mph |
| Weight-to-power ratio | 12.8 kg/Hp, 78.4 Hp/tonne |
| Weight-to-torque ratio | 5.8 kg/Nm, 172.7 Nm/tonne |
| Electric cars and hybrids specs | |
| Gross battery capacity | 39.5 kWh |
| Battery voltage | 329.4 V |
| Battery technology | Lithium nickel manganese cobalt oxides (Li-NMC) |
| All-electric range (WLTP) | 180-210 km 111.85 – 130.49 mi |
| All-electric range (WLTC) | 210 km 130.49 mi |
| Charging ports |  Log in to see. |
| Electric motor 1 | |
| Electric motor power | 109 Hp |
| Electric motor Torque | 240 Nm
177.01 lb.-ft. |
| Maximum revolutions of the electric motor | 9000 rpm. |
| Electric motor location | Front, Transverse |
| Electric motor type | Synchronous |
| System power | 109 Hp |
| System torque | 240 Nm 177.01 lb.-ft. |
|
|
|
| Space, Volume and weights | |
| Kerb Weight | 1390 kg 3064.43 lbs. |
| Max. weight | 1765 kg 3891.16 lbs. |
| Max load | 375 kg 826.73 lbs. |
| Trunk (boot) space – minimum | 450 l 15.89 cu. ft. |
| Trunk (boot) space – maximum | 900 l 31.78 cu. ft. |
| Dimensions | |
| Length | 4417 mm 173.9 in. |
| Width | 1737 mm 68.39 in. |
| Height | 1576 mm 62.05 in. |
| Wheelbase | 2500 mm 98.43 in. |
| Front track | 1500 mm 59.06 in. |
| Rear (Back) track | 1495 mm 58.86 in. |
| Ride height (ground clearance) | 125 mm 4.92 in. |
| Minimum turning circle (turning diameter) | 9.6 m 31.5 ft. |
| Approach angle | 16.5° |
| Departure angle | 19.5° |
| Drivetrain, brakes and suspension specs | |
| Drivetrain Architecture | One electric motor drives the front wheels. |
| Drive wheel | Front wheel drive |
| Number of gears and type of gearbox | 1 gears, automatic transmission |
| Front suspension | Independent type McPherson |
| Rear suspension | Torsion |
| Front brakes | Ventilated discs |
| Rear brakes | Disc |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Power steering | Electric Steering |
| Tires size | 205/55 R16 |
| Wheel rims size | 16 |
| What is the body type, Suda SA01? | Sedan, 4 Doors, 5 Seats |
|---|---|
| What is the range of pure electric driving, 39.5 kWh (109 Hp) BEV? | 180-210 km 111.85 – 130.49 mi |
| How fast is the car, 2020 SA01 39.5 kWh (109 Hp) BEV? | 130 km/h | 80.78 mph |
| How much power, Suda SA01 Sedan 2020 39.5 kWh (109 Hp) BEV? | 109 Hp, 240 Nm 177.01 lb.-ft. |
| What is the drivetrain, Suda SA01 Sedan 2020 39.5 kWh (109 Hp) BEV? | Front wheel drive. BEV (Electric Vehicle). One electric motor drives the front wheels. |
| How long is this vehicle, 2020 Suda SA01 Sedan? | 4417 mm 173.9 in. |
| How wide is the vehicle, 2020 Suda SA01 Sedan? | 1737 mm 68.39 in. |
| What is the curb weight, 2020 Suda SA01 39.5 kWh (109 Hp) BEV? | 1390 kg 3064.43 lbs. |
| What is the gross weight, 2020 Suda SA01 39.5 kWh (109 Hp) BEV? | 1765 kg 3891.16 lbs. |
| How much trunk (boot) space, 2020 Suda SA01 Sedan? | 450 – 900 l 15.89 – 31.78 cu. ft. |
| How many gears, What type is the gearbox, 2020 Suda SA01 39.5 kWh (109 Hp) BEV? | 1, automatic transmission |
