Tesla Model X Long Range 100 kWh (422 Hp) Dual Motor AWD

The Tesla Model X Long Range 100 kWh, produced from February 2019 to January 2021, represents a significant step in the electrification of the SUV segment. As Tesla’s flagship utility vehicle, the Model X combines spaciousness, performance, and advanced technology, appealing to buyers seeking a premium, all-electric experience. It’s positioned as a direct competitor to luxury SUVs with internal combustion engines, offering a compelling alternative with zero tailpipe emissions and Tesla’s signature over-the-air software updates. The Model X is not a vehicle widely sold outside of North America, Europe, and select Asian markets, where demand for electric vehicles is strongest.

Tesla Model X Long Range: An Overview

The Model X was Tesla’s second vehicle, following the Model S, and was designed to offer the practicality of an SUV with the performance and efficiency of an electric vehicle. The “Long Range” designation indicates a larger battery pack – 100 kWh – providing extended driving range compared to other variants. The dual-motor, all-wheel-drive (AWD) configuration delivers both enhanced traction and impressive acceleration. Its most distinctive feature, the Falcon Wing doors, while visually striking, also aimed to improve accessibility in tight parking spaces. The Model X is a five-door SUV with seating for up to seven passengers.

Engine & Performance

The Tesla Model X Long Range utilizes a fully electric powertrain, eschewing the traditional internal combustion engine entirely. It features two independent electric motors – one driving the front wheels and one driving the rear wheels – providing true all-wheel drive capability. The front motor produces 279 horsepower and 420 Nm (309.78 lb.-ft.) of torque, while the rear motor generates 286 horsepower and 335 Nm (247.08 lb.-ft.) of torque. Combined, these motors deliver a total system output of 422 horsepower. This translates to brisk acceleration, with a 0-60 mph time of 4.4 seconds and a 0-100 km/h time of 4.6 seconds. The vehicle has a maximum speed of 250 km/h (155.34 mph). The powertrain’s weight-to-power ratio is 5.9 kg/Hp, or 168.1 Hp/tonne, contributing to its responsive handling. The 100 kWh lithium-ion battery pack, located beneath the floor, provides a NEDC-rated range of 580 km (360.4 miles). Real-world range varies depending on driving conditions and style.

Design & Features

The Tesla Model X is a mid-size SUV characterized by its sleek, aerodynamic design. The most notable design element is the Falcon Wing doors, which open vertically, requiring less space than conventional doors and offering easier access to the second and third-row seats. The vehicle’s exterior features a minimalist aesthetic, consistent with Tesla’s design language. Inside, the Model X boasts a spacious and modern cabin dominated by a large 17-inch touchscreen display that controls most vehicle functions. The interior is available with configurations for five, six, or seven passengers.

Safety is a key aspect of the Model X, incorporating a comprehensive suite of advanced driver-assistance systems (ADAS), including ABS (Anti-lock braking system). These systems enhance safety and convenience, providing features like automatic emergency braking, lane keeping assist, and adaptive cruise control. The air suspension system provides a comfortable ride and allows for adjustable ride height. The large trunk offers significant cargo space, ranging from 357 liters (12.61 cu. ft.) with all seats in use to 2166 liters (76.49 cu. ft.) with the rear seats folded down.

Technical Specifications

Brand Tesla
Model Model X
Generation Model X
Type (Engine) Long Range 100 kWh (422 Hp) Dual Motor AWD
Start of production February, 2019
End of production January, 2021
Powertrain Architecture BEV (Electric Vehicle)
Body type SUV
Seats 7
Doors 5
Fuel Type Electricity
Acceleration 0 – 100 km/h 4.6 sec
Acceleration 0 – 62 mph 4.6 sec
Acceleration 0 – 60 mph 4.4 sec
Maximum speed 250 km/h (155.34 mph)
Weight-to-power ratio 5.9 kg/Hp, 168.1 Hp/tonne
Gross battery capacity 100 kWh
Battery voltage 350 V
Battery technology Lithium-ion (Li-Ion)
Battery location Below the floor
All-electric range (NEDC) 580 km (360.4 mi)
Average Energy consumption (NEDC) 16.8 kWh/100 km (27.04 kWh/100 mi)
Electric motor 1 power 286 Hp
Electric motor 1 Torque 335 Nm (247.08 lb.-ft.)
Electric motor 1 location Rear axle, Transverse
Electric motor 2 power 279 Hp
Electric motor 2 Torque 420 Nm (309.78 lb.-ft.)
Electric motor 2 location Front axle, Transverse
System power 422 Hp
Kerb Weight 2510 kg (5533.6 lbs.)
Max. weight 3079 kg (6788.03 lbs.)
Max load 569 kg (1254.43 lbs.)
Trunk (boot) space – minimum 357 l (12.61 cu. ft.)
Trunk (boot) space – maximum 2166 l (76.49 cu. ft.)
Permitted trailer load with brakes (12%) 2250 kg (4960.4 lbs.)
Permitted towbar download 54 kg (119.05 lbs.)
Length 5036 mm (198.27 in.)
Width 1999 mm (78.7 in.)
Width with mirrors folded 2072 mm (81.57 in.)
Width including mirrors 2271 mm (89.41 in.)
Height 1684 mm (66.3 in.)
Wheelbase 2965 mm (116.73 in.)
Front track 1705 mm (67.13 in.)
Rear (Back) track 1710 mm (67.32 in.)
Front overhang 974 mm (38.35 in.)
Rear overhang 1097 mm (43.19 in.)
Ride height (ground clearance) 183-223 mm (7.2 – 8.78 in.)
Drag coefficient (Cd) 0.25
Minimum turning circle (turning diameter) 12.4 m (40.68 ft.)
Drivetrain Architecture One electric motor drives the front wheels, one electric motor drives the rear wheels.
Drive wheel All wheel drive (4×4)
Number of gears and type of gearbox 1 gears, automatic transmission
Front suspension Double wishbone, Transverse stabilizer, Air suspension
Rear suspension Independent multi-link suspension, Air suspension, Transverse stabilizer
Front brakes Ventilated discs, 355×32 mm
Rear brakes Ventilated discs, 365×28 mm
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Power steering Electric Steering
Tires size Front 265/45 R20; 265/35 R22
Tires size Rear 275/45 R20; 285/35 R22
Wheel rims size Front 9J x 20; 9J x 22
Wheel rims size Rear 10J x 20; 10J x 22
