| General information | |
|---|---|
| Brand | Toyota |
| Model | Hilux |
| Generation | Hilux Extra Cab VII (facelift 2008) |
| Type (Engine) | 2.5 D-4D (144 Hp) 4×4 |
| Start of production | 2009 year |
| End of production | 2011 year |
| Powertrain Architecture | Internal Combustion engine |
| Body type | Pick-up |
| Seats | 4 |
| Doors | 2 |
| Performance specs | |
| Fuel consumption (economy) – combined (NEDC) | 8.3 l/100 km 28.3 US mpg 34 UK mpg 12 km/l |
| CO2 emissions (NEDC) | 219 g/km |
| Fuel Type | Diesel |
| Acceleration 0 – 100 km/h | 12.5 sec |
| Acceleration 0 – 62 mph | 12.5 sec |
| Acceleration 0 – 60 mph (Calculated by Auto-Data.net) | 11.9 sec |
| Maximum speed | 170 km/h 105.63 mph |
| Emission standard | Euro 4 |
| Weight-to-power ratio | 13.1 kg/Hp, 76.2 Hp/tonne |
| Weight-to-torque ratio | 5.5 kg/Nm, 181.5 Nm/tonne |
| Engine specs | |
| Power | 144 Hp @ 3400 rpm. |
| Power per litre | 57.7 Hp/l |
| Torque | 343 Nm @ 1600-2800 rpm. 252.98 lb.-ft. @ 1600-2800 rpm. |
| Engine layout | Front, Longitudinal |
| Engine Model/Code | 2KD-FTV |
| Engine displacement | 2494 cm3 152.19 cu. in. |
| Number of cylinders | 4 |
| Engine configuration | Inline |
| Cylinder Bore | 92 mm 3.62 in. |
| Piston Stroke | 93.8 mm 3.69 in. |
| Compression ratio | 17.4:1 |
| Number of valves per cylinder | 4 |
| Fuel injection system | Diesel Commonrail |
| Engine aspiration | Turbocharger, Intercooler |
| Valvetrain | DOHC |
| Engine oil capacity | 6.9 l 7.29 US qt | 6.07 UK qt |
| Engine oil specification |  Log in to see. |
| Coolant | 9 l 9.51 US qt | 7.92 UK qt |
|
|
|
| Space, Volume and weights | |
| Kerb Weight | 1890 kg 4166.74 lbs. |
| Max. weight | 2680 kg 5908.39 lbs. |
| Max load | 790 kg 1741.65 lbs. |
| Fuel tank capacity | 80 l 21.13 US gal | 17.6 UK gal |
| Max. roof load | 50 kg 110.23 lbs. |
| Permitted trailer load with brakes (12%) | 2250 kg 4960.4 lbs. |
| Permitted trailer load without brakes | 750 kg 1653.47 lbs. |
| Permitted towbar download | 90 kg 198.42 lbs. |
| Dimensions | |
| Length | 5255 mm 206.89 in. |
| Width | 1760 mm 69.29 in. |
| Height | 1795 mm 70.67 in. |
| Wheelbase | 3085 mm 121.46 in. |
| Front track | 1510 mm 59.45 in. |
| Rear (Back) track | 1510 mm 59.45 in. |
| Ride height (ground clearance) | 297 mm 11.69 in. |
| Minimum turning circle (turning diameter) | 13.2 m 43.31 ft. |
| Approach angle | 30° |
| Departure angle | 25° |
| Ramp-over (brakeover) angle | 19° |
| Drivetrain, brakes and suspension specs | |
| Drivetrain Architecture | The Internal combustion engine (ICE) drives the rear wheels permanently, and the front wheels are driven through an electrically or mechanically operated clutch if necessary. |
| Drive wheel | All wheel drive (4×4) |
| Number of gears and type of gearbox | 5 gears, manual transmission |
| Front suspension | Double wishbone, Transverse stabilizer |
| Rear suspension | Rigid axle suspension, Leaf spring |
| Front brakes | Ventilated discs |
| Rear brakes | Drum |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Power steering | Hydraulic Steering |
| Tires size | 205/80 R16 |
| Wheel rims size | 6J x 16 |
| What is the body type, Toyota Hilux Extra Cab VII (facelift 2008)? | Pick-up, 2 Doors, 4 Seats |
|---|---|
| What is the fuel economy, Toyota Hilux Extra Cab VII (facelift 2008) 2.5 D-4D (144 Hp) 4×4? | 8.3 l/100 km 28.3 US mpg 34 UK mpg 12 km/l |
| How ECO is the car, Toyota Hilux 2.5 D-4D (144 Hp) 4×4? | 219 g/km CO2 Euro 4 |
| How fast is the car, 2009 Hilux Extra Cab VII (facelift 2008) 2.5 D-4D (144 Hp) 4×4? | 170 km/h | 105.63 mph 0-100 km/h: 12.5 sec 0-60 mph: 11.9 sec |
| How much power, Toyota Hilux Pick-up 2009 2.5 D-4D (144 Hp) 4×4? | 144 Hp, 343 Nm 252.98 lb.-ft. |
| What is the engine size, Toyota Hilux Pick-up 2009 2.5 D-4D (144 Hp) 4×4? | 2.5 l 2494 cm3 152.19 cu. in. |
| How many cylinders, 2009 Toyota 2.5 D-4D (144 Hp) 4×4? | 4, Inline |
| What is the drivetrain, Toyota Hilux Extra Cab VII (facelift 2008) Pick-up 2009 2.5 D-4D (144 Hp) 4×4? | All wheel drive (4×4). Internal Combustion engine. The Internal combustion engine (ICE) drives the rear wheels permanently, and the front wheels are driven through an electrically or mechanically operated clutch if necessary. |
| How long is this vehicle, 2009 Toyota Hilux Pick-up? | 5255 mm 206.89 in. |
| How wide is the vehicle, 2009 Toyota Hilux Pick-up? | 1760 mm 69.29 in. |
| What is the curb weight, 2009 Toyota Hilux Extra Cab VII (facelift 2008) 2.5 D-4D (144 Hp) 4×4? | 1890 kg 4166.74 lbs. |
| What is the gross weight, 2009 Toyota Hilux Extra Cab VII (facelift 2008) 2.5 D-4D (144 Hp) 4×4? | 2680 kg 5908.39 lbs. |
| How many gears, What type is the gearbox, 2009 Toyota Hilux Extra Cab VII (facelift 2008) 2.5 D-4D (144 Hp) 4×4? | 5, manual transmission |
