| General information | |
|---|---|
| Brand | Toyota |
| Model | iQ |
| Generation | iQ |
| Type (Engine) | 1.33 Dual VVT-i (98 Hp) |
| Start of production | May, 2009 year |
| End of production | December, 2015 year |
| Powertrain Architecture | Internal Combustion engine |
| Body type | Hatchback |
| Seats | 4 |
| Doors | 3 |
| Performance specs | |
| Fuel consumption (economy) – urban | 5.8 l/100 km 40.6 US mpg 48.7 UK mpg 17.2 km/l |
| Fuel consumption (economy) – extra urban | 4.4 l/100 km 53.5 US mpg 64.2 UK mpg 22.7 km/l |
| Fuel consumption (economy) – combined | 4.9 l/100 km 48 US mpg 57.6 UK mpg 20.4 km/l |
| Fuel Type | Petrol (Gasoline) |
| Acceleration 0 – 100 km/h | 11.8 sec |
| Acceleration 0 – 62 mph | 11.8 sec |
| Acceleration 0 – 60 mph (Calculated by Auto-Data.net) | 11.2 sec |
| Maximum speed | 170 km/h 105.63 mph |
| Emission standard | Euro 5 |
| Weight-to-power ratio | 9.5 kg/Hp, 105.4 Hp/tonne |
| Weight-to-torque ratio | 7.6 kg/Nm, 132.3 Nm/tonne |
| Engine specs | |
| Power | 98 Hp @ 6000 rpm. |
| Power per litre | 73.7 Hp/l |
| Torque | 123 Nm @ 4400 rpm. 90.72 lb.-ft. @ 4400 rpm. |
| Engine layout | Front, Transverse |
| Engine Model/Code | 1NR-FE |
| Engine displacement | 1329 cm3 81.1 cu. in. |
| Number of cylinders | 4 |
| Engine configuration | Inline |
| Cylinder Bore | 72.5 mm 2.85 in. |
| Piston Stroke | 80.5 mm 3.17 in. |
| Compression ratio | 11.5:1 |
| Number of valves per cylinder | 4 |
| Fuel injection system | Multi-port manifold injection |
| Engine aspiration | Naturally aspirated engine |
| Valvetrain | DOHC – Dual VVT-i |
| Engine oil capacity | 3.5 l 3.7 US qt | 3.08 UK qt |
| Engine oil specification |  Log in to see. |
| Coolant | 4.7 l 4.97 US qt | 4.14 UK qt |
|
|
|
| Space, Volume and weights | |
| Kerb Weight | 930 kg 2050.3 lbs. |
| Max. weight | 1270 kg 2799.87 lbs. |
| Max load | 340 kg 749.57 lbs. |
| Trunk (boot) space – minimum | 26 l 0.92 cu. ft. |
| Trunk (boot) space – maximum | 363 l 12.82 cu. ft. |
| Fuel tank capacity | 32 l 8.45 US gal | 7.04 UK gal |
| Dimensions | |
| Length | 2985 mm 117.52 in. |
| Width | 1680 mm 66.14 in. |
| Height | 1500 mm 59.06 in. |
| Wheelbase | 2000 mm 78.74 in. |
| Front track | 1480 mm 58.27 in. |
| Rear (Back) track | 1460 mm 57.48 in. |
| Minimum turning circle (turning diameter) | 7.8 m 25.59 ft. |
| Drivetrain, brakes and suspension specs | |
| Drivetrain Architecture | The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
| Drive wheel | Front wheel drive |
| Number of gears and type of gearbox | 6 gears, manual transmission |
| Front suspension | Independent, type McPherson with coil spring and anti-roll bar |
| Rear suspension | Torsion |
| Front brakes | Ventilated discs |
| Rear brakes | Drum |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| What is the body type, Toyota iQ? | Hatchback, 3 Doors, 4 Seats |
|---|---|
| What is the fuel economy, Toyota iQ 1.33 Dual VVT-i (98 Hp)? | 4.9 l/100 km 48 US mpg 57.6 UK mpg 20.4 km/l |
| How ECO is the car, Toyota iQ 1.33 Dual VVT-i (98 Hp)? | Euro 5 |
| How fast is the car, 2009 iQ 1.33 Dual VVT-i (98 Hp)? | 170 km/h | 105.63 mph 0-100 km/h: 11.8 sec 0-60 mph: 11.2 sec |
| How much power, Toyota iQ Hatchback 2009 1.33 Dual VVT-i (98 Hp)? | 98 Hp, 123 Nm 90.72 lb.-ft. |
| What is the engine size, Toyota iQ Hatchback 2009 1.33 Dual VVT-i (98 Hp)? | 1.3 l 1329 cm3 81.1 cu. in. |
| How many cylinders, 2009 Toyota 1.33 Dual VVT-i (98 Hp)? | 4, Inline |
| What is the drivetrain, Toyota iQ Hatchback 2009 1.33 Dual VVT-i (98 Hp)? | Front wheel drive. Internal Combustion engine. The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
| How long is this vehicle, 2009 Toyota iQ Hatchback? | 2985 mm 117.52 in. |
| How wide is the vehicle, 2009 Toyota iQ Hatchback? | 1680 mm 66.14 in. |
| What is the curb weight, 2009 Toyota iQ 1.33 Dual VVT-i (98 Hp)? | 930 kg 2050.3 lbs. |
| What is the gross weight, 2009 Toyota iQ 1.33 Dual VVT-i (98 Hp)? | 1270 kg 2799.87 lbs. |
| How much trunk (boot) space, 2009 Toyota iQ Hatchback? | 26 – 363 l 0.92 – 12.82 cu. ft. |
| How many gears, What type is the gearbox, 2009 Toyota iQ 1.33 Dual VVT-i (98 Hp)? | 6, manual transmission |
