| General information | |
|---|---|
| Brand | Toyota |
| Model | Sequoia |
| Generation | Sequoia III (XK80) |
| Type (Engine) | 3.5 V6 i-FORCE MAX (437 Hp) Hybrid 2WD ECT-i |
| Start of production | June, 2022 year |
| Powertrain Architecture | FHEV (Full Hybrid Electric Vehicle) |
| Body type | SUV |
| Seats | 7-8 |
| Doors | 5 |
| Performance specs | |
| Fuel Type | Petrol (Gasoline) |
| Emission standard | LEV III |
| Weight-to-power ratio | 5.8 kg/Hp, 171.4 Hp/tonne |
| Weight-to-torque ratio | 3.2 kg/Nm, 309.9 Nm/tonne |
| Electric cars and hybrids specs | |
| Gross battery capacity | 1.87 kWh |
| Battery voltage | 288 V |
| Battery technology | Nickel-metal hydride (NiMH) |
| Electric motor 1 | |
| Electric motor power | 49 Hp |
| Electric motor Torque | 250 Nm
184.39 lb.-ft. |
| Electric motor location | Between the combustion engine and the transmission |
| Internal combustion engine specs | |
| Power | 437 Hp @ 5200 rpm. |
| Power per litre | 126.9 Hp/l |
| Torque | 790 Nm @ 2400 rpm. 582.67 lb.-ft. @ 2400 rpm. |
| Engine layout | Front, Longitudinal |
| Engine Model/Code | V35A-FTS |
| Engine displacement | 3445 cm3 210.23 cu. in. |
| Number of cylinders | 6 |
| Engine configuration | V-engine |
| Cylinder Bore | 85.5 mm 3.37 in. |
| Piston Stroke | 100 mm 3.94 in. |
| Compression ratio | 10.4:1 |
| Number of valves per cylinder | 4 |
| Fuel injection system | Direct injection and Multi-port manifold injection |
| Engine aspiration | Twin-Turbo, Intercooler |
| Valvetrain | DOHC, Dual VVT-i |
| Engine oil capacity | 7.3 l 7.71 US qt | 6.42 UK qt |
| Engine oil specification |  Log in to see. |
| Coolant | 14.5 l 15.32 US qt | 12.76 UK qt |
| Engine systems | Start & Stop System Particulate filter |
|
|
|
| Space, Volume and weights | |
| Kerb Weight | 2549-2672 kg 5619.58 – 5890.75 lbs. |
| Max. weight | 3366 kg 7420.76 lbs. |
| Max load | 694-817 kg 1530.01 – 1801.18 lbs. |
| Trunk (boot) space – minimum | 326-631 l 11.51 – 22.28 cu. ft. |
| Trunk (boot) space – maximum | 2461 l 86.91 cu. ft. |
| Fuel tank capacity | 85 l 22.45 US gal | 18.7 UK gal |
| Permitted trailer load with brakes (12%) | 4318 kg 9519.56 lbs. |
| Permitted towbar download | 432 kg 952.4 lbs. |
| Dimensions | |
| Length | 5286 mm 208.11 in. |
| Width | 2022 mm 79.61 in. |
| Height | 1885-1892 mm 74.21 – 74.49 in. |
| Wheelbase | 3099 mm 122.01 in. |
| Front track | 1742 mm 68.58 in. |
| Rear (Back) track | 1737 mm 68.39 in. |
| Front overhang | 965 mm 37.99 in. |
| Rear overhang | 1219 mm 47.99 in. |
| Ride height (ground clearance) | 218-221 mm 8.58 – 8.7 in. |
| Minimum turning circle (turning diameter) | 12.3 m 40.35 ft. |
| Approach angle | 15° |
| Departure angle | 20° |
| Drivetrain, brakes and suspension specs | |
| Drivetrain Architecture | The Internal combustion engine (ICE) and electric motor drive the rear wheels of the car with the ability to work in full electric or mixed mode. |
| Drive wheel | Rear wheel drive |
| Number of gears and type of gearbox | 10 gears, automatic transmission ECT-i |
| Front suspension | Double wishbone |
| Rear suspension | Independent multi-link suspension |
| Front brakes | Ventilated discs, 353.06 mm |
| Rear brakes | Ventilated discs, 345.44 mm |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Power steering | Electric Steering |
| Tires size | 265/70 R18; 265/60 R20; 265/50 R22 |
| Wheel rims size | 18; 20; 22 |
| What is the body type, Toyota Sequoia III (XK80)? | SUV, 5 Doors, 7-8 Seats |
|---|---|
| How ECO is the car, Toyota Sequoia 3.5 V6 i-FORCE MAX (437 Hp) Hybrid 2WD ECT-i? | LEV III |
| How much power, Toyota Sequoia SUV 2022 3.5 V6 i-FORCE MAX (437 Hp) Hybrid 2WD ECT-i? | 437 Hp, 790 Nm 582.67 lb.-ft. |
| What is the engine size, Toyota Sequoia SUV 2022 3.5 V6 i-FORCE MAX (437 Hp) Hybrid 2WD ECT-i? | 3.4 l 3445 cm3 210.23 cu. in. |
| How many cylinders, 2022 Toyota 3.5 V6 i-FORCE MAX (437 Hp) Hybrid 2WD ECT-i? | 6, V-engine |
| What is the drivetrain, Toyota Sequoia III (XK80) SUV 2022 3.5 V6 i-FORCE MAX (437 Hp) Hybrid 2WD ECT-i? | Rear wheel drive. FHEV (Full Hybrid Electric Vehicle). The Internal combustion engine (ICE) and electric motor drive the rear wheels of the car with the ability to work in full electric or mixed mode. |
| How long is this vehicle, 2022 Toyota Sequoia SUV? | 5286 mm 208.11 in. |
| How wide is the vehicle, 2022 Toyota Sequoia SUV? | 2022 mm 79.61 in. |
| What is the curb weight, 2022 Toyota Sequoia III (XK80) 3.5 V6 i-FORCE MAX (437 Hp) Hybrid 2WD ECT-i? | 2549-2672 kg 5619.58 – 5890.75 lbs. |
| What is the gross weight, 2022 Toyota Sequoia III (XK80) 3.5 V6 i-FORCE MAX (437 Hp) Hybrid 2WD ECT-i? | 3366 kg 7420.76 lbs. |
| How much trunk (boot) space, 2022 Toyota Sequoia SUV? | 326 – 2461 l 11.51 – 86.91 cu. ft. |
| How many gears, What type is the gearbox, 2022 Toyota Sequoia III (XK80) 3.5 V6 i-FORCE MAX (437 Hp) Hybrid 2WD ECT-i? | 10, automatic transmission ECT-i |
