The Toyota Yaris Cross (AC200) is a subcompact crossover SUV introduced by Toyota in 2023. Designed to bridge the gap between the standard Yaris hatchback and larger SUV offerings, the Yaris Cross caters to the growing demand for compact, fuel-efficient, and versatile vehicles. Primarily marketed in Europe and other international markets, it represents Toyota’s commitment to expanding its hybrid technology and offering a wider range of options within the popular B-segment crossover class. The 1.5 Hybrid variant, detailed here, combines a gasoline engine with an electric motor to deliver a balance of performance and economy.
Toyota Yaris Cross (AC200) 1.5 Hybrid: An Overview
The Yaris Cross AC200 is built upon the Toyota New Global Architecture (TNGA-B) platform, shared with the latest Yaris hatchback. This platform contributes to the vehicle’s improved rigidity, handling, and safety features. The 1.5 Hybrid model specifically utilizes Toyota’s fourth-generation hybrid technology, offering enhanced efficiency and a more refined driving experience. It’s positioned as a practical and economical choice for urban commuters and small families, offering a higher ride height and increased cargo space compared to the standard Yaris.
Engine & Performance
The heart of the Yaris Cross 1.5 Hybrid is a 1.5-liter, inline-four cylinder gasoline engine (model 2NR-VEX) producing 91 horsepower at 5500 rpm and 121 Nm (89.25 lb.-ft.) of torque between 4000-4800 rpm. This engine operates on a multi-port fuel injection system and features a Dual VVT-i valvetrain for optimized performance and efficiency. Crucially, this engine is paired with an electric motor that contributes an additional 80 horsepower and 141 Nm (104 lb.-ft.) of torque. The combined system output is 111 horsepower. Power is delivered to the front wheels via a continuously variable transmission (eCVT), which seamlessly blends the power from both the engine and the electric motor. The powertrain architecture is a Full Hybrid Electric Vehicle (FHEV), allowing for short periods of all-electric driving and regenerative braking to recharge the battery. A Start & Stop system further enhances fuel economy by automatically shutting off the engine when the vehicle is stationary.
Design & Features
The Toyota Yaris Cross boasts a contemporary SUV design, characterized by its bold front grille, sculpted body lines, and elevated ride height. As a five-door crossover, it offers practical access and ample interior space for passengers and cargo. The vehicle’s dimensions – 4310 mm (169.69 in.) in length, 1770 mm (69.69 in.) in width, and 1615 mm (63.58 in.) in height – position it squarely within the subcompact crossover segment. The interior is designed with functionality and comfort in mind, featuring a user-friendly infotainment system and quality materials. Safety is a key focus, with standard features including ABS (Anti-lock Braking System) and a comprehensive suite of driver-assistance technologies. The 210 mm (8.27 in.) ground clearance provides added confidence when navigating varied road conditions. The vehicle rides on 18-inch wheel rims with 215/55 R18 tires.
Technical Specifications
| General Information | |
| Brand | Toyota |
| Model | Yaris Cross |
| Generation | Yaris Cross (AC200) |
| Type (Engine) | 1.5 (111 Hp) Hybrid eCVT |
| Start of production | June, 2023 |
| Powertrain Architecture | FHEV (Full Hybrid Electric Vehicle) |
| Body type | SUV, Crossover |
| Seats | 5 |
| Doors | 5 |
| Performance Specs | |
| Fuel Type | Petrol (Gasoline) |
| Emission standard | Euro 4 |
| System Power | 111 Hp |
| Electric Specs | |
| Gross battery capacity | 0.7 kWh |
| Battery technology | Lithium-ion (Li-Ion) |
| Battery location | Under the rear seats |
| Electric motor power | 80 Hp |
| Electric motor Torque | 141 Nm / 104 lb.-ft. |
| Electric motor model/code | 1NM |
| Electric motor location | Integrated into the transmission |
| Electric motor type | Synchronous |
| Internal Combustion Engine Specs | |
| Power | 91 Hp @ 5500 rpm |
| Power per litre | 60.8 Hp/l |
| Torque | 121 Nm @ 4000-4800 rpm / 89.25 lb.-ft. @ 4000-4800 rpm |
| Engine layout | Front, Transverse |
| Engine Model/Code | 2NR-VEX |
| Engine displacement | 1496 cm3 / 91.29 cu. in. |
| Number of cylinders | 4 |
| Engine configuration | Inline |
| Cylinder Bore | 72.5 mm / 2.85 in. |
| Piston Stroke | 90.6 mm / 3.57 in. |
| Number of valves per cylinder | 4 |
| Fuel injection system | Multi-port manifold injection |
| Engine aspiration | Naturally aspirated engine |
| Valvetrain | DOHC, Dual VVT-i |
| Space, Volume and Weights | |
| Fuel tank capacity | 36 l / 9.51 US gal | 7.92 UK gal |
| Dimensions | |
| Length | 4310 mm / 169.69 in. |
| Width | 1770 mm / 69.69 in. |
| Height | 1615 mm / 63.58 in. |
| Wheelbase | 2620 mm / 103.15 in. |
| Front overhang | 860 mm / 33.86 in. |
| Rear overhang | 830 mm / 32.68 in. |
| Ride height (ground clearance) | 210 mm / 8.27 in. |
| Minimum turning circle (turning diameter) | 10.4 m / 34.12 ft. |
| Drivetrain, Brakes and Suspension | |
| Drivetrain Architecture | The Internal combustion engine (ICE) and electric motor drive the front wheels of the car with the ability to work in full electric or mixed mode. |
| Drive wheel | Front wheel drive |
| Number of gears and type of gearbox | automatic transmission eCVT |
| Front suspension | Independent type McPherson |
| Rear suspension | Torsion |
| Front brakes | Ventilated discs |
| Rear brakes | Disc |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Power steering | Electric Steering |
| Tires size | 215/55 R18 |
| Wheel rims size | 18 |
The Toyota Yaris Cross 1.5 Hybrid represents a compelling option in the subcompact crossover segment, offering a blend of fuel efficiency, practicality, and modern technology. Its hybrid powertrain and well-rounded features make it a suitable choice for a wide range of drivers, particularly those seeking an economical and versatile vehicle for urban environments.
