The Toyota Yaris II TS 1.8, produced between 2007 and 2009, represents a performance-oriented variant of the second-generation Yaris (known as the XP90 series). While the Yaris was not initially a major seller in the United States – Toyota primarily offered the larger Corolla and the Scion xB in this segment – the Yaris held significant popularity in Europe and other international markets as a subcompact hatchback. The TS 1.8 model aimed to provide a more engaging driving experience than the standard Yaris, appealing to enthusiasts seeking a fuel-efficient yet sporty vehicle.
Toyota Yaris II TS 1.8: A Sporty Subcompact
The Yaris II TS 1.8 was positioned as a warm hatch, bridging the gap between everyday practicality and spirited performance. It distinguished itself from the base models with a more powerful engine, subtle styling enhancements, and a focus on handling. The “TS” designation typically signified “Toyota Sport,” indicating a performance-tuned version of the standard model. This generation Yaris was known for its clever use of interior space and its relatively lightweight construction, contributing to its agility.
Engine & Performance
The heart of the Yaris II TS 1.8 is the 2ZR-FE 1.8-liter inline four-cylinder gasoline engine. This engine produces 133 horsepower at 6000 rpm and 173 Nm (127.6 lb.-ft.) of torque at 4400 rpm. The engine utilizes a multi-port fuel injection system and Toyota’s VVT-i (Variable Valve Timing-intelligent) technology to optimize performance and fuel efficiency. Power is delivered to the front wheels via a five-speed manual transmission. Acceleration from 0 to 100 km/h (0-62 mph) takes 9.3 seconds, while the 0-60 mph sprint is achieved in a calculated 8.8 seconds. The Yaris II TS 1.8 boasts a maximum speed of 194 km/h (120.55 mph). The engine’s power-to-weight ratio is 8.9 kg/Hp, and the torque-to-weight ratio is 6.9 kg/Nm, contributing to its responsive feel.
Design & Features
The Yaris II TS 1.8 is a five-door hatchback with a practical and functional design. Its compact dimensions – 3750 mm (147.64 in.) in length, 1695 mm (66.73 in.) in width, and 1530 mm (60.24 in.) in height – make it easy to maneuver in urban environments. The interior offers seating for five passengers and provides a surprisingly spacious cabin for its size. The rear seats can be folded down to expand the trunk space from a minimum of 275 liters (9.71 cu. ft.) to a maximum of 1183 liters (41.78 cu. ft.).
While not laden with luxury features, the TS 1.8 included standard equipment such as ABS (Anti-lock Braking System) for enhanced safety. The vehicle rides on 17-inch wheels with 205/50 R17V tires. The suspension features an independent McPherson strut setup at the front and a torsion beam arrangement at the rear, providing a balance between comfort and handling. The Yaris II TS 1.8’s kerb weight is 1190 kg (2623.5 lbs), and it has a maximum permissible weight of 1545 kg (3406.14 lbs). It can tow a braked trailer of up to 1050 kg (2314.85 lbs) and an unbraked trailer of up to 550 kg (1212.54 lbs).
Technical Specifications
| Brand | Toyota |
| Model | Yaris |
| Generation | Yaris II |
| Type (Engine) | TS 1.8 (133 Hp) |
| Start of production | 2007 |
| End of production | 2009 |
| Powertrain Architecture | Internal Combustion engine |
| Body type | Hatchback |
| Seats | 5 |
| Doors | 5 |
| Fuel consumption (urban) | 9.2 l/100 km (25.6 US mpg) |
| Fuel consumption (extra urban) | 6 l/100 km (39.2 US mpg) |
| Fuel consumption (combined) | 7.2 l/100 km (32.7 US mpg) |
| CO2 emissions | 170 g/km |
| Fuel Type | Petrol (Gasoline) |
| Acceleration 0 – 100 km/h | 9.3 sec |
| Acceleration 0 – 62 mph | 9.3 sec |
| Acceleration 0 – 60 mph | 8.8 sec |
| Maximum speed | 194 km/h (120.55 mph) |
| Emission standard | Euro 4 |
| Weight-to-power ratio | 8.9 kg/Hp |
| Weight-to-torque ratio | 6.9 kg/Nm |
| Power | 133 Hp @ 6000 rpm |
| Torque | 173 Nm @ 4400 rpm (127.6 lb.-ft. @ 4400 rpm) |
| Engine Model/Code | 2ZR-FE |
| Engine displacement | 1798 cm3 (109.72 cu. in.) |
| Number of cylinders | 4 |
| Engine configuration | Inline |
| Number of valves per cylinder | 4 |
| Fuel injection system | Multi-port manifold injection |
| Engine aspiration | Naturally aspirated |
| Engine oil capacity | 4.2 l (4.44 US qt | 3.7 UK qt) |
| Coolant capacity | 5 l (5.28 US qt | 4.4 UK qt) |
| Kerb Weight | 1190 kg (2623.5 lbs) |
| Max. weight | 1545 kg (3406.14 lbs) |
| Max load | 355 kg (782.64 lbs) |
| Trunk (boot) space – minimum | 275 l (9.71 cu. ft.) |
| Trunk (boot) space – maximum | 1183 l (41.78 cu. ft.) |
| Fuel tank capacity | 42 l (11.1 US gal | 9.24 UK gal) |
| Max. roof load | 70 kg (154.32 lbs) |
| Permitted trailer load with brakes (12%) | 1050 kg (2314.85 lbs) |
| Permitted trailer load without brakes | 550 kg (1212.54 lbs) |
| Permitted towbar download | 50 kg (110.23 lbs) |
| Length | 3750 mm (147.64 in.) |
| Width | 1695 mm (66.73 in.) |
| Height | 1530 mm (60.24 in.) |
| Wheelbase | 2460 mm (96.85 in.) |
| Minimum turning circle | 10.0 m (32.81 ft.) |
| Drivetrain | Front wheel drive |
| Number of gears | 5 |
| Gearbox type | Manual |
The Toyota Yaris II TS 1.8, while not a high-volume seller in the US market, offered a compelling package for those seeking a fuel-efficient, practical, and reasonably sporty subcompact hatchback. Its combination of a responsive engine, nimble handling, and clever interior packaging made it a popular choice in Europe and other regions where it was available.
