| General information | |
|---|---|
| Brand | Volkswagen |
| Model | Atlas |
| Generation | Atlas |
| Type (Engine) | 2.0 FSI (235 Hp) Automatic |
| Start of production | 2017 year |
| End of production | 2020 year |
| Powertrain Architecture | Internal Combustion engine |
| Body type | SUV |
| Seats | 7 |
| Doors | 5 |
| Performance specs | |
| Fuel Type | Petrol (Gasoline) |
| Weight-to-power ratio | 8.1 kg/Hp, 122.7 Hp/tonne |
| Weight-to-torque ratio | 5.5 kg/Nm, 182.8 Nm/tonne |
| Engine specs | |
| Power | 235 Hp @ 4500 rpm. |
| Power per litre | 118.4 Hp/l |
| Torque | 350 Nm @ 1600 rpm. 258.15 lb.-ft. @ 1600 rpm. |
| Engine layout | Front, Transverse |
| Engine Model/Code | DCGA |
| Engine displacement | 1984 cm3 121.07 cu. in. |
| Number of cylinders | 4 |
| Engine configuration | Inline |
| Cylinder Bore | 82.55 mm 3.25 in. |
| Piston Stroke | 92.71 mm 3.65 in. |
| Compression ratio | 9.6:1 |
| Number of valves per cylinder | 4 |
| Fuel injection system | Direct injection |
| Engine aspiration | Turbocharger, Intercooler |
| Engine oil capacity | 4.7 l 4.97 US qt | 4.14 UK qt |
| Engine oil specification |  Log in to see. |
| Coolant | 20 l 21.13 US qt | 17.6 UK qt |
| Engine systems | Start & Stop System |
|
|
|
| Space, Volume and weights | |
| Kerb Weight | 1915 kg 4221.85 lbs. |
| Max. weight | 2550 kg 5621.79 lbs. |
| Max load | 635 kg 1399.94 lbs. |
| Trunk (boot) space – minimum | 583 l 20.59 cu. ft. |
| Trunk (boot) space – maximum | 2741 l 96.8 cu. ft. |
| Fuel tank capacity | 70.4 l 18.6 US gal | 15.49 UK gal |
| Permitted trailer load with brakes (12%) | 907 kg 1999.59 lbs. |
| Dimensions | |
| Length | 5036 mm 198.27 in. |
| Width | 1989 mm 78.31 in. |
| Height | 1778 mm 70 in. |
| Wheelbase | 2979 mm 117.28 in. |
| Front track | 1708 mm 67.24 in. |
| Rear (Back) track | 1723 mm 67.83 in. |
| Ride height (ground clearance) | 203 mm 7.99 in. |
| Drag coefficient (Cd) | 0.34 |
| Minimum turning circle (turning diameter) | 11.6 m 38.06 ft. |
| Approach angle | 20.4° |
| Departure angle | 22.4° |
| Ramp-over (brakeover) angle | 17.5° |
| Drivetrain, brakes and suspension specs | |
| Drivetrain Architecture | The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
| Drive wheel | Front wheel drive |
| Number of gears and type of gearbox | 8 gears, automatic transmission |
| Front suspension | Independent coil spring |
| Rear suspension | Independent multi-link suspension |
| Front brakes | Ventilated discs, 335×30 mm |
| Rear brakes | Disc, 310×23 mm |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Power steering | Electric Steering |
| Tires size | 245/60 R18 |
| Wheel rims size | 8J x 18 |
| What is the body type, Volkswagen Atlas? | SUV, 5 Doors, 7 Seats |
|---|---|
| How much power, Volkswagen Atlas SUV 2017 2.0 FSI (235 Hp) Automatic? | 235 Hp, 350 Nm 258.15 lb.-ft. |
| What is the engine size, Volkswagen Atlas SUV 2017 2.0 FSI (235 Hp) Automatic? | 2.0 l 1984 cm3 121.07 cu. in. |
| How many cylinders, 2017 Volkswagen 2.0 FSI (235 Hp) Automatic? | 4, Inline |
| What is the drivetrain, Volkswagen Atlas SUV 2017 2.0 FSI (235 Hp) Automatic? | Front wheel drive. Internal Combustion engine. The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
| How long is this vehicle, 2017 Volkswagen Atlas SUV? | 5036 mm 198.27 in. |
| How wide is the vehicle, 2017 Volkswagen Atlas SUV? | 1989 mm 78.31 in. |
| What is the curb weight, 2017 Volkswagen Atlas 2.0 FSI (235 Hp) Automatic? | 1915 kg 4221.85 lbs. |
| What is the gross weight, 2017 Volkswagen Atlas 2.0 FSI (235 Hp) Automatic? | 2550 kg 5621.79 lbs. |
| How much trunk (boot) space, 2017 Volkswagen Atlas SUV? | 583 – 2741 l 20.59 – 96.8 cu. ft. |
| How many gears, What type is the gearbox, 2017 Volkswagen Atlas 2.0 FSI (235 Hp) Automatic? | 8, automatic transmission |
