| General information | |
|---|---|
| Brand | Volkswagen |
| Model | Atlas |
| Generation | Atlas Cross Sport (facelift 2023) |
| Type (Engine) | 2.0 TSI (269 Hp) 4MOTION Tiptronic |
| Start of production | 2023 year |
| Powertrain Architecture | Internal Combustion engine |
| Body type | SUV |
| Seats | 5 |
| Doors | 5 |
| Performance specs | |
| Fuel consumption (economy) – urban (EPA) | 12.4 l/100 km 19 US mpg 22.8 UK mpg 8.1 km/l |
| Fuel consumption (economy) – extra urban (EPA) | 9 l/100 km 26.1 US mpg 31.4 UK mpg 11.1 km/l |
| Fuel consumption (economy) – combined (EPA) | 10.7 l/100 km 22 US mpg 26.4 UK mpg 9.3 km/l |
| Fuel Type | Petrol (Gasoline) |
| Weight-to-power ratio | 7.3 kg/Hp, 136.1 Hp/tonne |
| Weight-to-torque ratio | 5.3 kg/Nm, 187.2 Nm/tonne |
| Engine specs | |
| Power | 269 Hp @ 5500-6500 rpm. |
| Power per litre | 135.6 Hp/l |
| Torque | 370 Nm @ 1600-4750 rpm. 272.9 lb.-ft. @ 1600-4750 rpm. |
| Engine layout | Front, Transverse |
| Engine Model/Code | EA888 evo4 |
| Engine displacement | 1984 cm3 121.07 cu. in. |
| Number of cylinders | 4 |
| Engine configuration | Inline |
| Cylinder Bore | 82.5 mm 3.25 in. |
| Piston Stroke | 92.8 mm 3.65 in. |
| Compression ratio | 9.6:1 |
| Number of valves per cylinder | 4 |
| Fuel injection system | Direct injection |
| Engine aspiration | Turbocharger, Intercooler |
| Valvetrain | DOHC, VVT |
| Engine systems | Start & Stop System |
|
|
|
| Space, Volume and weights | |
| Kerb Weight | 1977 kg 4358.54 lbs. |
| Max. weight | 2620 kg 5776.11 lbs. |
| Max load | 643 kg 1417.57 lbs. |
| Trunk (boot) space – minimum | 1141 l 40.29 cu. ft. |
| Trunk (boot) space – maximum | 2197 l 77.59 cu. ft. |
| Fuel tank capacity | 70.4 l 18.6 US gal | 15.49 UK gal |
| Permitted trailer load with brakes (12%) | 2268 kg 5000.08 lbs. |
| Permitted trailer load without brakes | 750 kg 1653.47 lbs. |
| Dimensions | |
| Length | 4968 mm 195.59 in. |
| Width | 1990 mm 78.35 in. |
| Width including mirrors | 2249 mm 88.54 in. |
| Height | 1729 mm 68.07 in. |
| Wheelbase | 2980 mm 117.32 in. |
| Front track | 1702 mm 67.01 in. |
| Rear (Back) track | 1718 mm 67.64 in. |
| Ride height (ground clearance) | 159 mm 6.26 in. |
| Drag coefficient (Cd) | 0.34 |
| Minimum turning circle (turning diameter) | 12.2 m 40.03 ft. |
| Approach angle | 20.8° |
| Departure angle | 24.9° |
| Ramp-over (brakeover) angle | 17.6° |
| Drivetrain, brakes and suspension specs | |
| Drivetrain Architecture | The Internal combustion engine (ICE) drives the front wheels permanently, and the rear wheels are driven through an electrically or mechanically operated clutch if necessary. |
| Drive wheel | All wheel drive (4×4) |
| Number of gears and type of gearbox | 8 gears, automatic transmission Tiptronic |
| Front suspension | Independent, type McPherson with coil spring and anti-roll bar |
| Rear suspension | Independent multi-link spring suspension with stabilizer |
| Front brakes | Ventilated discs, 335×30 mm |
| Rear brakes | Ventilated discs, 310×22 mm |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Power steering | Electric Steering |
| Tires size | 245/60 R18; 255/50 R20; 265/45 R21 |
| Wheel rims size | 8J x 18; 20; 21 |
| What is the body type, Volkswagen Atlas Cross Sport (facelift 2023)? | SUV, 5 Doors, 5 Seats |
|---|---|
| What is the fuel economy, Volkswagen Atlas Cross Sport (facelift 2023) 2.0 TSI (269 Hp) 4MOTION Tiptronic? | 10.7 l/100 km 22 US mpg 26.4 UK mpg 9.3 km/l |
| How much power, Volkswagen Atlas SUV 2023 2.0 TSI (269 Hp) 4MOTION Tiptronic? | 269 Hp, 370 Nm 272.9 lb.-ft. |
| What is the engine size, Volkswagen Atlas SUV 2023 2.0 TSI (269 Hp) 4MOTION Tiptronic? | 2.0 l 1984 cm3 121.07 cu. in. |
| How many cylinders, 2023 Volkswagen 2.0 TSI (269 Hp) 4MOTION Tiptronic? | 4, Inline |
| What is the drivetrain, Volkswagen Atlas Cross Sport (facelift 2023) SUV 2023 2.0 TSI (269 Hp) 4MOTION Tiptronic? | All wheel drive (4×4). Internal Combustion engine. The Internal combustion engine (ICE) drives the front wheels permanently, and the rear wheels are driven through an electrically or mechanically operated clutch if necessary. |
| How long is this vehicle, 2023 Volkswagen Atlas SUV? | 4968 mm 195.59 in. |
| How wide is the vehicle, 2023 Volkswagen Atlas SUV? | 1990 mm 78.35 in. |
| What is the curb weight, 2023 Volkswagen Atlas Cross Sport (facelift 2023) 2.0 TSI (269 Hp) 4MOTION Tiptronic? | 1977 kg 4358.54 lbs. |
| What is the gross weight, 2023 Volkswagen Atlas Cross Sport (facelift 2023) 2.0 TSI (269 Hp) 4MOTION Tiptronic? | 2620 kg 5776.11 lbs. |
| How much trunk (boot) space, 2023 Volkswagen Atlas SUV? | 1141 – 2197 l 40.29 – 77.59 cu. ft. |
| How many gears, What type is the gearbox, 2023 Volkswagen Atlas Cross Sport (facelift 2023) 2.0 TSI (269 Hp) 4MOTION Tiptronic? | 8, automatic transmission Tiptronic |
