| General information | |
|---|---|
| Brand | Volkswagen |
| Model | Beetle |
| Generation | Beetle Convertible (A5) |
| Type (Engine) | 1.2 TSI (105 Hp) |
| Start of production | 2012 year |
| End of production | 2016 year |
| Powertrain Architecture | Internal Combustion engine |
| Body type | Cabriolet |
| Seats | 4 |
| Doors | 2 |
| Performance specs | |
| Fuel consumption (economy) – urban | 6.8 l/100 km 34.6 US mpg 41.5 UK mpg 14.7 km/l |
| Fuel consumption (economy) – extra urban | 4.8 l/100 km 49 US mpg 58.9 UK mpg 20.8 km/l |
| Fuel consumption (economy) – combined | 5.6 l/100 km 42 US mpg 50.4 UK mpg 17.9 km/l |
| CO2 emissions | 129 g/km |
| Fuel Type | Petrol (Gasoline) |
| Acceleration 0 – 100 km/h | 11.7 sec |
| Acceleration 0 – 62 mph | 11.7 sec |
| Acceleration 0 – 60 mph (Calculated by Auto-Data.net) | 11.1 sec |
| Maximum speed | 178 km/h 110.6 mph |
| Emission standard | Euro 6 |
| Weight-to-power ratio | 13.3 kg/Hp, 75.3 Hp/tonne |
| Weight-to-torque ratio | 8 kg/Nm, 125.4 Nm/tonne |
| Engine specs | |
| Power | 105 Hp @ 5000-5500 rpm. |
| Power per litre | 87.7 Hp/l |
| Torque | 175 Nm @ 1400-4000 rpm. 129.07 lb.-ft. @ 1400-4000 rpm. |
| Engine layout | Front, Transverse |
| Engine Model/Code | CBZB, CYVD |
| Engine displacement | 1197 cm3 73.05 cu. in. |
| Number of cylinders | 4 |
| Engine configuration | Inline |
| Cylinder Bore | 71 mm 2.8 in. |
| Piston Stroke | 75.6 mm 2.98 in. |
| Compression ratio | 10:1 |
| Number of valves per cylinder | 4 |
| Fuel injection system | Direct injection |
| Engine aspiration | Turbocharger, Intercooler |
| Engine oil capacity | 3.9 l 4.12 US qt | 3.43 UK qt |
| Engine oil specification |  Log in to see. |
|
|
|
| Space, Volume and weights | |
| Kerb Weight | 1395 kg 3075.45 lbs. |
| Max. weight | 1780 kg 3924.23 lbs. |
| Max load | 385 kg 848.78 lbs. |
| Trunk (boot) space – minimum | 225 l 7.95 cu. ft. |
| Fuel tank capacity | 55 l 14.53 US gal | 12.1 UK gal |
| Dimensions | |
| Length | 4278 mm 168.43 in. |
| Width | 1808 mm 71.18 in. |
| Width including mirrors | 2021 mm 79.57 in. |
| Height | 1473 mm 57.99 in. |
| Wheelbase | 2540 mm 100 in. |
| Front track | 1578 mm 62.13 in. |
| Rear (Back) track | 1554 mm 61.18 in. |
| Ride height (ground clearance) | 136 mm 5.35 in. |
| Minimum turning circle (turning diameter) | 10.8 m 35.43 ft. |
| Approach angle | 13.6° |
| Departure angle | 14.8° |
| Ramp-over (brakeover) angle | 11° |
| Drivetrain, brakes and suspension specs | |
| Drivetrain Architecture | The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
| Drive wheel | Front wheel drive |
| Number of gears and type of gearbox | 6 gears, manual transmission |
| Front suspension | Independent type McPherson |
| Rear suspension | Semi-independent, coil spring |
| Front brakes | Ventilated discs |
| Rear brakes | Disc |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Tires size | 215/60 R16; 235/45 R18 |
| Wheel rims size | 6.5J x 16; 8J x 18 |
| What is the body type, Volkswagen Beetle Convertible (A5)? | Cabriolet, 2 Doors, 4 Seats |
|---|---|
| What is the fuel economy, Volkswagen Beetle Convertible (A5) 1.2 TSI (105 Hp)? | 5.6 l/100 km 42 US mpg 50.4 UK mpg 17.9 km/l |
| How ECO is the car, Volkswagen Beetle 1.2 TSI (105 Hp)? | 129 g/km CO2 Euro 6 |
| How fast is the car, 2012 Beetle Convertible (A5) 1.2 TSI (105 Hp)? | 178 km/h | 110.6 mph 0-100 km/h: 11.7 sec 0-60 mph: 11.1 sec |
| How much power, Volkswagen Beetle Cabriolet 2012 1.2 TSI (105 Hp)? | 105 Hp, 175 Nm 129.07 lb.-ft. |
| What is the engine size, Volkswagen Beetle Cabriolet 2012 1.2 TSI (105 Hp)? | 1.2 l 1197 cm3 73.05 cu. in. |
| How many cylinders, 2012 Volkswagen 1.2 TSI (105 Hp)? | 4, Inline |
| What is the drivetrain, Volkswagen Beetle Convertible (A5) Cabriolet 2012 1.2 TSI (105 Hp)? | Front wheel drive. Internal Combustion engine. The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
| How long is this vehicle, 2012 Volkswagen Beetle Cabriolet? | 4278 mm 168.43 in. |
| How wide is the vehicle, 2012 Volkswagen Beetle Cabriolet? | 1808 mm 71.18 in. |
| What is the curb weight, 2012 Volkswagen Beetle Convertible (A5) 1.2 TSI (105 Hp)? | 1395 kg 3075.45 lbs. |
| What is the gross weight, 2012 Volkswagen Beetle Convertible (A5) 1.2 TSI (105 Hp)? | 1780 kg 3924.23 lbs. |
| How much trunk (boot) space, 2012 Volkswagen Beetle Cabriolet? | 225 l 7.95 cu. ft. |
| How many gears, What type is the gearbox, 2012 Volkswagen Beetle Convertible (A5) 1.2 TSI (105 Hp)? | 6, manual transmission |
