| General information | |
|---|---|
| Brand | Volkswagen |
| Model | Caravelle |
| Generation | Caravelle (T7) Long |
| Type (Engine) | 2.0 TDI (170 Hp) 4MOTION Automatic |
| Start of production | August, 2024 year |
| Powertrain Architecture | Internal Combustion engine |
| Body type | Van |
| Seats | 8-9 |
| Doors | 4-5 |
| Performance specs | |
| Combined fuel consumption (WLTP) | 8.7 l/100 km 27 US mpg 32.5 UK mpg 11.5 km/l |
| CO2 emissions (WLTP) | 227-229 g/km |
| Fuel Type | Diesel |
| Acceleration 0 – 100 km/h | 14 sec |
| Acceleration 0 – 62 mph | 14 sec |
| Acceleration 0 – 60 mph (Calculated by Auto-Data.net) | 13.3 sec |
| Maximum speed | 175 km/h 108.74 mph |
| Emission standard | Euro 6e |
| Weight-to-power ratio | 13.5 kg/Hp, 73.9 Hp/tonne |
| Weight-to-torque ratio | 5.9 kg/Nm, 169.6 Nm/tonne |
| Engine specs | |
| Power | 170 Hp |
| Power per litre | 85.2 Hp/l |
| Torque | 390 Nm 287.65 lb.-ft. |
| Engine layout | Front, Transverse |
| Engine Model/Code | Panther |
| Engine displacement | 1996 cm3 121.8 cu. in. |
| Number of cylinders | 4 |
| Engine configuration | Inline |
| Cylinder Bore | 84.01 mm 3.31 in. |
| Piston Stroke | 90.03 mm 3.54 in. |
| Number of valves per cylinder | 4 |
| Fuel injection system | Diesel Commonrail |
| Engine aspiration | Turbocharger, Intercooler |
| Valvetrain | DOHC |
| Engine systems | Start & Stop System Particulate filter |
|
|
|
| Space, Volume and weights | |
| Kerb Weight | 2300-2360 kg 5070.63 – 5202.91 lbs. |
| Max. weight | 3300 kg 7275.25 lbs. |
| Max load | 940-1000 kg 2072.35 – 2204.62 lbs. |
| Fuel tank capacity | 55 l 14.53 US gal | 12.1 UK gal |
| AdBlue tank | 20 l 5.28 US gal | 4.4 UK gal |
| Max. roof load | 170 kg 374.79 lbs. |
| Permitted trailer load with brakes (12%) | 2400 kg 5291.09 lbs. |
| Permitted trailer load without brakes | 750 kg 1653.47 lbs. |
| Permitted towbar download | 100 kg 220.46 lbs. |
| Dimensions | |
| Length | 5450 mm 214.57 in. |
| Width | 2032 mm 80 in. |
| Width including mirrors | 2275 mm 89.57 in. |
| Height | 1979 mm 77.91 in. |
| Wheelbase | 3500 mm 137.8 in. |
| Front overhang | 958 mm 37.72 in. |
| Rear overhang | 992 mm 39.06 in. |
| Minimum turning circle (turning diameter) | 13.8 m 45.28 ft. |
| Approach angle | 17.2° |
| Departure angle | 16.4° |
| Ramp-over (brakeover) angle | 11.7° |
| Drivetrain, brakes and suspension specs | |
| Drivetrain Architecture | The Internal combustion engine (ICE) drives the front wheels permanently, and the rear wheels are driven through an electrically or mechanically operated clutch if necessary. |
| Drive wheel | All wheel drive (4×4) |
| Number of gears and type of gearbox | 8 gears, automatic transmission |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Power steering | Electric Steering |
| Tires size | 215/65 R16; 215/60 R17 |
| Wheel rims size | 6.5J x 16; 6.5J x 17 |
| What is the body type, Volkswagen Caravelle (T7) Long? | Van, 4-5 Doors, 8-9 Seats |
|---|---|
| What is the fuel economy, Volkswagen Caravelle (T7) Long 2.0 TDI (170 Hp) 4MOTION Automatic? | 8.7 l/100 km 27 US mpg 32.5 UK mpg 11.5 km/l |
| How ECO is the car, Volkswagen Caravelle 2.0 TDI (170 Hp) 4MOTION Automatic? | 227-229 g/km CO2 Euro 6e |
| How fast is the car, 2024 Caravelle (T7) Long 2.0 TDI (170 Hp) 4MOTION Automatic? | 175 km/h | 108.74 mph 0-100 km/h: 14 sec 0-60 mph: 13.3 sec |
| How much power, Volkswagen Caravelle Van 2024 2.0 TDI (170 Hp) 4MOTION Automatic? | 170 Hp, 390 Nm 287.65 lb.-ft. |
| What is the engine size, Volkswagen Caravelle Van 2024 2.0 TDI (170 Hp) 4MOTION Automatic? | 2.0 l 1996 cm3 121.8 cu. in. |
| How many cylinders, 2024 Volkswagen 2.0 TDI (170 Hp) 4MOTION Automatic? | 4, Inline |
| What is the drivetrain, Volkswagen Caravelle (T7) Long Van 2024 2.0 TDI (170 Hp) 4MOTION Automatic? | All wheel drive (4×4). Internal Combustion engine. The Internal combustion engine (ICE) drives the front wheels permanently, and the rear wheels are driven through an electrically or mechanically operated clutch if necessary. |
| How long is this vehicle, 2024 Volkswagen Caravelle Van? | 5450 mm 214.57 in. |
| How wide is the vehicle, 2024 Volkswagen Caravelle Van? | 2032 mm 80 in. |
| What is the curb weight, 2024 Volkswagen Caravelle (T7) Long 2.0 TDI (170 Hp) 4MOTION Automatic? | 2300-2360 kg 5070.63 – 5202.91 lbs. |
| What is the gross weight, 2024 Volkswagen Caravelle (T7) Long 2.0 TDI (170 Hp) 4MOTION Automatic? | 3300 kg 7275.25 lbs. |
| How many gears, What type is the gearbox, 2024 Volkswagen Caravelle (T7) Long 2.0 TDI (170 Hp) 4MOTION Automatic? | 8, automatic transmission |
