| General information | |
|---|---|
| Brand | Volkswagen |
| Model | Fox |
| Generation | Fox 3Door Europe |
| Type (Engine) | 1.2 i (55 Hp) |
| Start of production | 2005 year |
| End of production | 2011 year |
| Powertrain Architecture | Internal Combustion engine |
| Body type | Hatchback |
| Seats | 4 |
| Doors | 3 |
| Performance specs | |
| Fuel consumption (economy) – urban | 7.8 l/100 km 30.2 US mpg 36.2 UK mpg 12.8 km/l |
| Fuel consumption (economy) – extra urban | 5.1 l/100 km 46.1 US mpg 55.4 UK mpg 19.6 km/l |
| Fuel consumption (economy) – combined | 6.1 l/100 km 38.6 US mpg 46.3 UK mpg 16.4 km/l |
| Fuel Type | Petrol (Gasoline) |
| Acceleration 0 – 100 km/h | 17.5 sec |
| Acceleration 0 – 62 mph | 17.5 sec |
| Acceleration 0 – 60 mph (Calculated by Auto-Data.net) | 16.6 sec |
| Maximum speed | 148 km/h 91.96 mph |
| Weight-to-power ratio | 18.1 kg/Hp, 55.1 Hp/tonne |
| Weight-to-torque ratio | 9.2 kg/Nm, 108.2 Nm/tonne |
| Engine specs | |
| Power | 55 Hp @ 4750 rpm. |
| Power per litre | 45.9 Hp/l |
| Torque | 108 Nm @ 3000 rpm. 79.66 lb.-ft. @ 3000 rpm. |
| Engine layout | Front, Transverse |
| Engine Model/Code | BMD, CHFB |
| Engine displacement | 1198 cm3 73.11 cu. in. |
| Number of cylinders | 3 |
| Engine configuration | Inline |
| Cylinder Bore | 76.5 mm 3.01 in. |
| Piston Stroke | 86.9 mm 3.42 in. |
| Compression ratio | 10.3:1 |
| Number of valves per cylinder | 2 |
| Fuel injection system | Multi-port manifold injection |
| Engine aspiration | Naturally aspirated engine |
| Engine oil capacity | 3 l 3.17 US qt | 2.64 UK qt |
| Engine oil specification |  Log in to see. |
| Coolant | 5.6 l 5.92 US qt | 4.93 UK qt |
|
|
|
| Space, Volume and weights | |
| Kerb Weight | 998 kg 2200.21 lbs. |
| Max. weight | 1480 kg 3262.84 lbs. |
| Max load | 482 kg 1062.63 lbs. |
| Trunk (boot) space – minimum | 260 l 9.18 cu. ft. |
| Trunk (boot) space – maximum | 1016 l 35.88 cu. ft. |
| Fuel tank capacity | 50 l 13.21 US gal | 11 UK gal |
| Dimensions | |
| Length | 3828 mm 150.71 in. |
| Width | 1660 mm 65.35 in. |
| Height | 1544 mm 60.79 in. |
| Wheelbase | 2465 mm 97.05 in. |
| Front track | 1428 mm 56.22 in. |
| Rear (Back) track | 1424 mm 56.06 in. |
| Drivetrain, brakes and suspension specs | |
| Drivetrain Architecture | The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
| Drive wheel | Front wheel drive |
| Number of gears and type of gearbox | 5 gears, manual transmission |
| Front suspension | Spring Strut |
| Rear suspension | Torsion |
| Front brakes | Ventilated discs |
| Rear brakes | Drum |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Tires size | 165/70 R14 T |
| Wheel rims size | 5J x 14 |
| What is the body type, Volkswagen Fox 3Door Europe? | Hatchback, 3 Doors, 4 Seats |
|---|---|
| What is the fuel economy, Volkswagen Fox 3Door Europe 1.2 i (55 Hp)? | 6.1 l/100 km 38.6 US mpg 46.3 UK mpg 16.4 km/l |
| How fast is the car, 2005 Fox 3Door Europe 1.2 i (55 Hp)? | 148 km/h | 91.96 mph 0-100 km/h: 17.5 sec 0-60 mph: 16.6 sec |
| How much power, Volkswagen Fox Hatchback 2005 1.2 i (55 Hp)? | 55 Hp, 108 Nm 79.66 lb.-ft. |
| What is the engine size, Volkswagen Fox Hatchback 2005 1.2 i (55 Hp)? | 1.2 l 1198 cm3 73.11 cu. in. |
| How many cylinders, 2005 Volkswagen 1.2 i (55 Hp)? | 3, Inline |
| What is the drivetrain, Volkswagen Fox 3Door Europe Hatchback 2005 1.2 i (55 Hp)? | Front wheel drive. Internal Combustion engine. The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
| How long is this vehicle, 2005 Volkswagen Fox Hatchback? | 3828 mm 150.71 in. |
| How wide is the vehicle, 2005 Volkswagen Fox Hatchback? | 1660 mm 65.35 in. |
| What is the curb weight, 2005 Volkswagen Fox 3Door Europe 1.2 i (55 Hp)? | 998 kg 2200.21 lbs. |
| What is the gross weight, 2005 Volkswagen Fox 3Door Europe 1.2 i (55 Hp)? | 1480 kg 3262.84 lbs. |
| How much trunk (boot) space, 2005 Volkswagen Fox Hatchback? | 260 – 1016 l 9.18 – 35.88 cu. ft. |
| How many gears, What type is the gearbox, 2005 Volkswagen Fox 3Door Europe 1.2 i (55 Hp)? | 5, manual transmission |
