| General information | |
|---|---|
| Brand | Volkswagen |
| Model | Golf |
| Generation | Golf V (3-door) |
| Type (Engine) | 1.4 TSI (170 Hp) DSG |
| Start of production | 2005 year |
| End of production | 2008 year |
| Powertrain Architecture | Internal Combustion engine |
| Body type | Hatchback |
| Seats | 5 |
| Doors | 3 |
| Performance specs | |
| Fuel consumption (economy) – urban (NEDC) | 9.9-10 l/100 km 23.8 – 23.5 US mpg 28.5 – 28.2 UK mpg 10.1 – 10 km/l |
| Fuel consumption (economy) – extra urban (NEDC) | 5.8-5.9 l/100 km 40.6 – 39.9 US mpg 48.7 – 47.9 UK mpg 17.2 – 16.9 km/l |
| Fuel consumption (economy) – combined (NEDC) | 7.3-7.4 l/100 km 32.2 – 31.8 US mpg 38.7 – 38.2 UK mpg 13.7 – 13.5 km/l |
| CO2 emissions (NEDC) | 174-178 g/km |
| Fuel Type | Petrol (Gasoline) |
| Acceleration 0 – 100 km/h | 7.7 sec |
| Acceleration 0 – 62 mph | 7.7 sec |
| Acceleration 0 – 60 mph (Calculated by Auto-Data.net) | 7.3 sec |
| Maximum speed | 218 km/h 135.46 mph |
| Emission standard | Euro 4 |
| Weight-to-power ratio | 7.6 kg/Hp, 131.5 Hp/tonne |
| Weight-to-torque ratio | 5.4 kg/Nm, 185.6 Nm/tonne |
| Engine specs | |
| Power | 170 Hp @ 6000 rpm. |
| Power per litre | 122.3 Hp/l |
| Torque | 240 Nm @ 1750-5000 rpm. 177.01 lb.-ft. @ 1750-5000 rpm. |
| Engine layout | Front, Transverse |
| Engine Model/Code | BLG |
| Engine displacement | 1390 cm3 84.82 cu. in. |
| Number of cylinders | 4 |
| Engine configuration | Inline |
| Cylinder Bore | 76.5 mm 3.01 in. |
| Piston Stroke | 75.6 mm 2.98 in. |
| Compression ratio | 9.7:1 |
| Number of valves per cylinder | 4 |
| Fuel injection system | Direct injection |
| Engine aspiration | Turbocharging and Supercharger, Intercooler |
| Valvetrain | DOHC |
| Engine oil capacity | 3.6 l 3.8 US qt | 3.17 UK qt |
| Engine oil specification |  Log in to see. |
| Coolant | 5.6 l 5.92 US qt | 4.93 UK qt |
|
|
|
| Space, Volume and weights | |
| Kerb Weight | 1293-1451 kg 2850.58 – 3198.91 lbs. |
| Max. weight | 1870 kg 4122.64 lbs. |
| Max load | 419-577 kg 923.74 – 1272.07 lbs. |
| Trunk (boot) space – minimum | 350 l 12.36 cu. ft. |
| Trunk (boot) space – maximum | 1305 l 46.09 cu. ft. |
| Fuel tank capacity | 55 l 14.53 US gal | 12.1 UK gal |
| Max. roof load | 75 kg 165.35 lbs. |
| Permitted trailer load with brakes (8%) | 1700 kg 3747.86 lbs. |
| Permitted trailer load with brakes (12%) | 1400 kg 3086.47 lbs. |
| Permitted trailer load without brakes | 680 kg 1499.14 lbs. |
| Permitted towbar download | 75 kg 165.35 lbs. |
| Dimensions | |
| Length | 4204 mm 165.51 in. |
| Width | 1759 mm 69.25 in. |
| Width including mirrors | 2010 mm 79.13 in. |
| Height | 1479 mm 58.23 in. |
| Wheelbase | 2578 mm 101.5 in. |
| Front track | 1539 mm 60.59 in. |
| Rear (Back) track | 1528 mm 60.16 in. |
| Front overhang | 880 mm 34.65 in. |
| Rear overhang | 746 mm 29.37 in. |
| Minimum turning circle (turning diameter) | 10.9 m 35.76 ft. |
| Drivetrain, brakes and suspension specs | |
| Drivetrain Architecture | The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
| Drive wheel | Front wheel drive |
| Number of gears and type of gearbox | 6 gears, automatic transmission DSG |
| Front suspension | Independent, type McPherson with coil spring and anti-roll bar |
| Rear suspension | Independent multi-link spring suspension with stabilizer |
| Front brakes | Ventilated discs |
| Rear brakes | Disc |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Power steering | Electric Steering |
| Tires size | 225/45 R17; 225/40 R18 |
| Wheel rims size | 7J x 17; 7.5J x 18 |
| What is the body type, Volkswagen Golf V (3-door)? | Hatchback, 3 Doors, 5 Seats |
|---|---|
| What is the fuel economy, Volkswagen Golf V (3-door) 1.4 TSI (170 Hp) DSG? | 7.3-7.4 l/100 km 32.2 – 31.8 US mpg 38.7 – 38.2 UK mpg 13.7 – 13.5 km/l |
| How ECO is the car, Volkswagen Golf 1.4 TSI (170 Hp) DSG? | 174-178 g/km CO2 Euro 4 |
| How fast is the car, 2005 Golf V (3-door) 1.4 TSI (170 Hp) DSG? | 218 km/h | 135.46 mph 0-100 km/h: 7.7 sec 0-60 mph: 7.3 sec |
| How much power, Volkswagen Golf Hatchback 2005 1.4 TSI (170 Hp) DSG? | 170 Hp, 240 Nm 177.01 lb.-ft. |
| What is the engine size, Volkswagen Golf Hatchback 2005 1.4 TSI (170 Hp) DSG? | 1.4 l 1390 cm3 84.82 cu. in. |
| How many cylinders, 2005 Volkswagen 1.4 TSI (170 Hp) DSG? | 4, Inline |
| What is the drivetrain, Volkswagen Golf V (3-door) Hatchback 2005 1.4 TSI (170 Hp) DSG? | Front wheel drive. Internal Combustion engine. The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
| How long is this vehicle, 2005 Volkswagen Golf Hatchback? | 4204 mm 165.51 in. |
| How wide is the vehicle, 2005 Volkswagen Golf Hatchback? | 1759 mm 69.25 in. |
| What is the curb weight, 2005 Volkswagen Golf V (3-door) 1.4 TSI (170 Hp) DSG? | 1293-1451 kg 2850.58 – 3198.91 lbs. |
| What is the gross weight, 2005 Volkswagen Golf V (3-door) 1.4 TSI (170 Hp) DSG? | 1870 kg 4122.64 lbs. |
| How much trunk (boot) space, 2005 Volkswagen Golf Hatchback? | 350 – 1305 l 12.36 – 46.09 cu. ft. |
| How many gears, What type is the gearbox, 2005 Volkswagen Golf V (3-door) 1.4 TSI (170 Hp) DSG? | 6, automatic transmission DSG |
